VAILLANT
MAG 9/1 XZ 1999-2011 - (07 Casing Parts)
Appliance Code: 9/1 XZ

Appliance Diagram


07 Casing Parts diagram for Vaillant Mag 9/1 XZ 1999-2011Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   COWLING
Vaillant part no. 072979

2 Part number 292232, Ring RING
Vaillant part no. 292232
£6.66
3 Part number 292233, Ring (PK2) RING (PK2)
Vaillant part no. 292233
£6.66
4 Part number 076168, Cover COVER
Vaillant part no. 076168
£7.61
5 Part number 077931, Covering plate COVERING PLATE
Vaillant part no. 077931
£13.29
6 Part number 114281, Knob KNOB
Vaillant part no. 114281
£6.66
7   BACK PANEL
Vaillant part no. 074411
£14.45
8 Part number 075084, Draft diverter DRAFT DIVERTER
Vaillant part no. 075084
£36.87
9 Part number 139702, Spring clamp SPRING CLAMP
Vaillant part no. 139702
£8.97
10   SPRING CLAMP (PK10)
Vaillant part no. 126187
£6.66
11 Part number 105832, Screw (PK10) SCREW (PK10)
Vaillant part no. 105832
£6.66
