VAILLANT
MAG 9/1 XZ 1999-2011 - (01 Water Valve)
Appliance Code: 9/1 XZ

Appliance Diagram


01 Water Valve diagram for Vaillant Mag 9/1 XZ 1999-2011Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 011283, water valve WATER VALVE
Vaillant part no. 011283		 £169.96
2 Part number 013034, Water valve, upper part WATER VALVE, UPPER PART
Vaillant part no. 013034		 £36.15
3 Part number 012156, stuffing box STUFFING BOX
Vaillant part no. 012156		 £7.24
4 Part number 981144, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981144		 £6.86
5 Part number 010216, slow ignition valve SLOW IGNITION VALVE
Vaillant part no. 010216
6 Part number 010050, screw SCREW
Vaillant part no. 010050		 £6.86
7 Part number 010003, Screw - Diaphragm SCREW - DIAPHRAGM
Vaillant part no. 010003		 £6.86
8 Part number 010009, spring SPRING
Vaillant part no. 010009		 £6.86
9 Part number 010006, diaphragm disc DIAPHRAGM DISC
Vaillant part no. 010006		 £7.25
10 Part number 0020107707, DIAPHRAGM DIAPHRAGM
Vaillant part no. 0020107707		 £7.24
11 Part number 010013, venturi VENTURI
Vaillant part no. 010013		 £10.44
12 Part number 981144, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981144		 £6.86
13 Part number 981141, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981141		 £6.86
14 Part number 010052, water filter WATER FILTER
Vaillant part no. 010052		 £6.86
15 Part number 981174, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981174		 £6.86
16 Part number 010138, Screw - Adjusting SCREW - ADJUSTING
Vaillant part no. 010138		 £6.86
17 Part number 010141, disc DISC
Vaillant part no. 010141		 £6.86
18 Part number 010144, sleeve nut SLEEVE NUT
Vaillant part no. 010144		 £6.86
19 Part number 981143, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981143		 £6.86
20 Part number 210943, outlet OUTLET
Vaillant part no. 210943
21 Part number 144016, water quantity regulator WATER QUANTITY REGULATOR
Vaillant part no. 144016		 £6.86
22 Part number 144016, water quantity regulator WATER QUANTITY REGULATOR
Vaillant part no. 144016		 £6.86
23 Part number 144016, water quantity regulator WATER QUANTITY REGULATOR
Vaillant part no. 144016		 £6.86
24 Part number 144016, water quantity regulator WATER QUANTITY REGULATOR
Vaillant part no. 144016		 £6.86
25 Part number 981164, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981164		 £6.86
26 Part number 012772, Tap spindle set TAP SPINDLE SET
Vaillant part no. 012772		 £21.92
27 Part number 981148, Gasket (PK10) GASKET (PK10)
Vaillant part no. 981148		 £6.86
28 Part number 012009, handle set (blue and red) HANDLE SET (BLUE AND RED)
Vaillant part no. 012009		 £12.26
29 Part number 010085, spring SPRING
Vaillant part no. 010085		 £6.86
30   SPRING BOLT
Vaillant part no. 010083		 £6.86
31 Part number 010094, spindle SPINDLE
Vaillant part no. 010094		 £9.24
32 Part number 981160, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981160		 £6.86
33 Part number 0020078914, BUSH BUSH
Vaillant part no. 0020078914		 £6.86
34 Part number 492112, SPRING WASHER SPRING WASHER
Vaillant part no. 492112		 £6.86
35 Part number 060009, Screw SCREW
Vaillant part no. 060009		 £6.86
36 Part number 114280, Knob KNOB
Vaillant part no. 114280		 £6.86
