WORCESTER
WR8P 31 7701431556 - (Burner)
Appliance Code: 7701431556

Appliance Diagram


Burner diagram for Worcester WR8P 31 7701431556Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   MAIN BURNER
Worcester part no. 87081205730
3   NOZZLE 65
Worcester part no. 87082021660
4   SCREW M3,5X10 (10X)
Worcester part no. 87034010690
£0.59
5   SCREW M4 X 12 PHILLIPS (10X)
Worcester part no. 29109521220
£0.67
6   CONNECTOR
Worcester part no. 87052090620
£23.54
7   WASHER (10X)
Worcester part no. 87010030100
£0.72
8   O-RING (10X)
Worcester part no. 87002051360
£3.78
9   CLIP (10X)
Worcester part no. 87012010190
£7.57
11   PILOT GAS PIPE
Worcester part no. 87007073690
£9.18
12   TUBE (10X)
Worcester part no. 87406090020
£4.35
