WORCESTER
W350-1KV1B31S0595 (APRIL 1998-JUNE 1998) 7702431824 - (Heating Body)
Appliance Code: 7702431824

Appliance Diagram


Heating Body diagram for Worcester W350-1KV1B31S0595 (April 1998-June 1998) 7702431824Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   HEATING BODY
Worcester part no. 87054063760
£274.51
2 Part number 87072061320, NOW USE 8738717111 TEMPERATURE LIMIT 110 DEC C. NOW USE 8738717111 TEMPERATURE LIMIT 110 DEC C.
Worcester part no. 87072061320

2   TEMPERATURE LIMITER
Worcester part no. 8738717111
£19.22
4   CONNECTING PIPE COLD
Worcester part no. 87007056270
£17.06
5   CONNECTION UNION
Worcester part no. 87033010810
£8.37
6   SET OF WASHERS
Worcester part no. 87001036920
£1.38
7 Part number 87002050230, O-RING (10X) O-RING (10X)
Worcester part no. 87002050230
£1.55
8   RETAINING CLIP (10X)
Worcester part no. 87047050250
£0.79
9   DRAIN OFF VALVE
Worcester part no. 87085050040
£46.43
10   WASHER
Worcester part no. 87001030060
£0.78
13 Part number 87101030430, FIBRE WASHER 23.9 X 17.2 X 1.5 FIBRE WASHER 23.9 X 17.2 X 1.5
Worcester part no. 87101030430
£2.84
16   TEMPERATURE LIMITER/ECO
Worcester part no. 87072064350
£6.07
17   CLIP FOR ECO (10X)
Worcester part no. 87013000150
£9.18
