WORCESTER
W350-1KV1B31S0595 (APRIL 1998-JUNE 1998) 7702431824 - (Front Cover)
Appliance Code: 7702431824

Appliance Diagram


Front Cover diagram for Worcester W350-1KV1B31S0595 (April 1998-June 1998) 7702431824Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   FRONT SHELL
Worcester part no. 87054017080
£123.28
2   OBSOLETE TRADE MARK BADGE
Worcester part no. 87011030500

6 Part number 87020002190, WATER FLOW SELECTOR HANDLE WATER FLOW SELECTOR HANDLE
Worcester part no. 87020002190
£14.19
7 Part number 87020001110, WATER FLOW SELECTOR HANDLE WATER FLOW SELECTOR HANDLE
Worcester part no. 87020001110
£3.94
8   DRAUGHT DIVERTER
Worcester part no. 87055053070
£24.76
9   EXHAUST PIPE UNION D:130
Worcester part no. 87055040390
£3.71
10   SCREW (10X)
Worcester part no. 29181404170

11   ANGLE BRACKET
Worcester part no. 87080030420
£2.46
12 Part number 87034030120, NOW USE 87134030390SCREW M4,8X9,5 (10X) NOW USE 87134030390SCREW M4,8X9,5 (10X)
Worcester part no. 87034030120

12 Part number 87134030390, SCREW 4.8 X 30MM SET OF 3 SCREW 4.8 X 30MM SET OF 3
Worcester part no. 87134030390
£4.61
