WORCESTER
GREENSTAR COMBI 30 CDI HE LPG - (Tubes & Connections)
Appliance Code: 47-406-15

Appliance Diagram


Tubes & Connections diagram for Worcester Greenstar Combi 30 CDI HE LPGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 87105062540, NOW USE 87182256360 SIPHON NOW USE 87182256360 SIPHON
Worcester part no. 87105062540
1 Part number 87182256360, SIPHON SIPHON
Worcester part no. 87182256360		 £83.86
2 Part number 87154051890, PROTECTIVE CAP PROTECTIVE CAP
Worcester part no. 87154051890		 £6.55
3   COVER
Worcester part no. 87154051880		 £6.55
4 Part number 87155045240, CORRUGATED PIPE CORRUGATED PIPE
Worcester part no. 87155045240		 £2.00
5 Part number 87107032200, HOSE HOSE
Worcester part no. 87107032200		 £3.13
6 Part number 87102050970, SET OF O-RINGS SET OF O-RINGS
Worcester part no. 87102050970		 £9.24
8 Part number 87167711670, RETAINING SPRING 10MM (10X) RETAINING SPRING 10MM (10X)
Worcester part no. 87167711670		 £2.50
9 Part number 87107353180, PIPE PIPE
Worcester part no. 87107353180		 £24.73
10 Part number 87161074370, O-RING 12.5X3 WRAS / KTW (10X) O-RING 12.5X3 WRAS / KTW (10X)
Worcester part no. 87161074370		 £2.79
10 Part number 87161156790, NOW USE 87161067480 O RING NOW USE 87161067480 O RING
Worcester part no. 87161156790
10 Part number 87161067480, O-RING 12,5X3 WRAS / KTW (1X) AFTER FD992 O-RING 12,5X3 WRAS / KTW (1X) AFTER FD992
Worcester part no. 87161067480		 £2.95
11 Part number 87107353060, FLOW PIPE FLOW PIPE
Worcester part no. 87107353060		 £31.00
12 Part number 87101030460, WASHER 1" (10X) WASHER 1" (10X)
Worcester part no. 87101030460		 £2.95
12 Part number 87161156820, WASHER 1" (1X) WASHER 1" (1X)
Worcester part no. 87161156820		 £2.95
13 Part number 87167712590, NOW USE 87161122590 WASHER NOW USE 87161122590 WASHER
Worcester part no. 87167712590
13 Part number 87161156730, WASHER (X1) WASHER (X1)
Worcester part no. 87161156730		 £3.88
13 Part number 87161122590, WASHER BONDED 19.9MM WASHER BONDED 19.9MM
Worcester part no. 87161122590		 £7.80
14 Part number 87107353240, RETURN PIPE RETURN PIPE
Worcester part no. 87107353240		 £32.48
15 Part number 87167711540, O-RING 17X4 (10X) AFTER FD992 O-RING 17X4 (10X) AFTER FD992
Worcester part no. 87167711540		 £2.63
16 Part number 87112000240, CLIP (10X) 18 AFTER FD992 CLIP (10X) 18 AFTER FD992
Worcester part no. 87112000240		 £12.94
17 Part number 87107353050, CONNECTING PIPE COLD CONNECTING PIPE COLD
Worcester part no. 87107353050		 £24.73
18 Part number 87167711550, NOW USE 87161165490 O-RING 13,87X3,53 (10X) NOW USE 87161165490 O-RING 13,87X3,53 (10X)
Worcester part no. 87167711550
18 Part number 87161165490, O-RING 13,87X3,53 (10X) O-RING 13,87X3,53 (10X)
Worcester part no. 87161165490		 £3.13
19 Part number 87161064280, CH FLOW PIPE ASSEMBLY with clips CH FLOW PIPE ASSEMBLY WITH CLIPS
Worcester part no. 87161064280		 £19.62
21 Part number 87161164280, PRESSURE GAUGE AFTER FD985 PRESSURE GAUGE AFTER FD985
Worcester part no. 87161164280		 £21.38
22 Part number 87161408100, O-RING 2.62 X 6.02 ID EPDM (10X) O-RING 2.62 X 6.02 ID EPDM (10X)
Worcester part no. 87161408100		 £2.68
23 Part number 87161064270, DHW PIPE ASSEMBLY DHW PIPE ASSEMBLY
Worcester part no. 87161064270		 £17.25
24 Part number 87101030450, WASHER 18.6 X 13.5 X 1.5 (10X) WASHER 18.6 X 13.5 X 1.5 (10X)
Worcester part no. 87101030450		 £2.95
25   FIXING BRACKET MANOMETER
Worcester part no. 87182207020		 £0.56
