WORCESTER
GREENSTAR 36 CDI COMPACT LPG - (Burner Heat Exchanger)
Appliance Code: 47-406-49

Appliance Diagram


Burner Heat Exchanger diagram for Worcester Greenstar 36 CDI Compact LPGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 871860113A0, SPRING ASSEMBLY SPRING ASSEMBLY
Worcester part no. 871860113A0		 £8.36
2 Part number 871860117A0, LOCK CLIP LOCK CLIP
Worcester part no. 871860117A0		 £2.16
3 Part number 871860519A0, STUD M6 X 45 STUD M6 X 45
Worcester part no. 871860519A0		 £5.91
4 Part number 871860178A0, HOUSING BURNER HOUSING BURNER
Worcester part no. 871860178A0		 £40.91
5 Part number 871860024A0, SEAL BURNER SEAL BURNER
Worcester part no. 871860024A0		 £7.37
6 Part number 871860023B0, BURNER WB7 BURNER WB7
Worcester part no. 871860023B0		 £81.65
7 Part number T00220054A0, CLIP CLIP
Worcester part no. T00220054A0		 £2.97
8 Part number T00500087A0, AIR_VENT AIR_VENT
Worcester part no. T00500087A0		 £8.13
9 Part number 87186863240, BRACKET HEAT CELL BRACKET HEAT CELL
Worcester part no. 87186863240		 £3.90
10   NUT HEX. FLANGE DIN6923 M6
Worcester part no. T70427140600		 £2.25
11 Part number 871860028A0, ELECTRODE ELECTRODE
Worcester part no. 871860028A0		 £23.92
12 Part number 871861523A0, SEAL IGNITION ASSY SEAL IGNITION ASSY
Worcester part no. 871861523A0		 £2.97
13 Part number 871860492A0, HEAT EXCHANGER ASSEMBLY HEAT EXCHANGER ASSEMBLY
Worcester part no. 871860492A0		 £539.03
14 Part number 87186854830, SENSOR NTC MAX SENSOR NTC MAX
Worcester part no. 87186854830		 £6.68
15 Part number 87186863360, SCREW EJOT ALTRACS PLUS PAN HD TORX M5x9 SCREW EJOT ALTRACS PLUS PAN HD TORX M5X9
Worcester part no. 87186863360		 £2.32
16 Part number 87186855560, BRACKET GAS VALVE SUPPORT BRACKET GAS VALVE SUPPORT
Worcester part no. 87186855560		 £3.45
17 Part number 87186818990, SCREW EJOT ALTRACS (X8) SCREW EJOT ALTRACS (X8)
Worcester part no. 87186818990		 £3.66
18 Part number 871860005A0, SEAL CONDENSATE COLLECTOR SEAL CONDENSATE COLLECTOR
Worcester part no. 871860005A0		 £3.94
19 Part number 873791301A0, COLLECTOR CONDENSATE COLLECTOR CONDENSATE
Worcester part no. 873791301A0		 £23.54
20 Part number 87186839040, ADAPTER STRAIGHT ADAPTER STRAIGHT
Worcester part no. 87186839040		 £11.25
21 Part number 87186884490, SEAL CASE LOWER SEAL CASE LOWER
Worcester part no. 87186884490		 £2.60
22 Part number 87186861800, NUT HEATCELL RETAINING NUT HEATCELL RETAINING
Worcester part no. 87186861800		 £2.70
23 Part number 87186880150, TRANSFORMER IGNITION TRANSFORMER IGNITION
Worcester part no. 87186880150		 £36.02
24 Part number 87186847420, SEAL SIPHON SEAL SIPHON
Worcester part no. 87186847420		 £3.66
25 Part number 87186825340, PIPE CONDENSATE DRAIN PIPE CONDENSATE DRAIN
Worcester part no. 87186825340		 £4.11
26 Part number 87186824780, SIPHON LCS SIPHON LCS
Worcester part no. 87186824780		 £8.81
27   NOW USE 87167711540 O-RING 17X4 (10X)
Worcester part no. 87161074380
27 Part number 87167711540, O-RING 17X4 (10X) AFTER FD992 O-RING 17X4 (10X) AFTER FD992
Worcester part no. 87167711540		 £2.63
28 Part number 87161408230, O-RING 3.53 SEC X 23.4 I/D E.P O-RING 3.53 SEC X 23.4 I/D E.P
Worcester part no. 87161408230		 £2.84
30 Part number 87186865940, SCREW EJOT ALTRACS PLUS PAN HD TORX M5X12 SCREW EJOT ALTRACS PLUS PAN HD TORX M5X12
Worcester part no. 87186865940		 £2.32
32 Part number 29124511520, SCREW M5 X 10 PAN HEAD POZI ZP BEFORE FD005 SCREW M5 X 10 PAN HEAD POZI ZP BEFORE FD005
Worcester part no. 29124511520		 £2.63
