WORCESTER
CWI47 NG - (Water Valve FD301-2013/01)
Appliance Code: 7703311082

Appliance Diagram


Water Valve FD301-2013/01 diagram for Worcester Cwi47 NGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 87085050240, WATER VALVE WITH ENGINE WATER VALVE WITH ENGINE
Worcester part no. 87085050240
£140.29
2 Part number 87002051470, O-RING (10X) O-RING (10X)
Worcester part no. 87002051470
£15.23
3 Part number 87007153940, COLD WATER PIPE COLD WATER PIPE
Worcester part no. 87007153940
£26.50
4 Part number 87012010280, CLIP (10X) CLIP (10X)
Worcester part no. 87012010280
£13.68
5   PIPE HOT WATER
Worcester part no. 87007154690
£22.04
6 Part number 87004000150, TEMPERATURE SENSOR TEMPERATURE SENSOR
Worcester part no. 87004000150
£39.52
7   SOCKET CONNECTION
Worcester part no. 87033053630
£31.03
8 Part number 87101030450, WASHER 18.6 X 13.5 X 1.5 (10X) WASHER 18.6 X 13.5 X 1.5 (10X)
Worcester part no. 87101030450
£2.95
9 Part number 87013000250, CLIP (10X) CLIP (10X)
Worcester part no. 87013000250
£10.72
10   SOCKET CONNECTION
Worcester part no. 87033053620
£35.29
11   O-RING (10X)
Worcester part no. 87002051570
£6.94
12 Part number 87161026070, NOW USE 87186880230 CLAMP SPRING NOW USE 87186880230 CLAMP SPRING
Worcester part no. 87161026070

12 Part number 87186880230, CLIP CLIP
Worcester part no. 87186880230
£3.33
13 Part number 87005070010, WATER STRAINER (10X) WATER STRAINER (10X)
Worcester part no. 87005070010
£2.45
14 Part number 87023030270, INSULATION (145X60) INSULATION (145X60)
Worcester part no. 87023030270
£2.63
15   TEMPERATURE SENSOR
Worcester part no. 87004000420
£27.26
16   O-RING (10X)
Worcester part no. 87002053100
£3.61
