WORCESTER
CWI47 NG - (Control Box)
Appliance Code: 7703311082

Appliance Diagram


Control Box diagram for Worcester Cwi47 NGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

  GAS CONVERSION KIT 23>31/G27
Worcester part no. 87190024600
£5.72
1 Part number 87387206720, CONTROL UNIT CONTROL UNIT
Worcester part no. 87387206720
£237.24
2 Part number 19045213420, FUSING ELEMENT T2,5A (10X) FUSING ELEMENT T2,5A (10X)
Worcester part no. 19045213420
£21.29
3 Part number 87006090080, FUSING ELEMENT T1,6A (5X20 MM) FUSING ELEMENT T1,6A (5X20 MM)
Worcester part no. 87006090080
£2.14
4   POWER SUPPLY CABLES
Worcester part no. 87044013710
£10.34
5   CABLE FOR POWER SUPPLY
Worcester part no. 87044013800
£13.68
6 Part number 87387044600, FAN CABLE FAN CABLE
Worcester part no. 87387044600
£27.26
7 Part number 87044013480, CABLE HARNESS CABLE HARNESS
Worcester part no. 87044013480
£62.00
9   ELECTRODE CABLES
Worcester part no. 87044013460
£19.15
10 Part number 87004000320, TEMPERATURE SENSOR TEMPERATURE SENSOR
Worcester part no. 87004000320
£22.04
11 Part number 7736500272, INTELLIGENT CASCADING KIT EUR INTELLIGENT CASCADING KIT EUR
Worcester part no. 7736500272
£55.95
12 Part number 7709003709, ACCESSORY ANTI-FREEZE ACCESSORY ANTI-FREEZE
Worcester part no. 7709003709
13   REMOTE_CONTROL WORCESTER
Worcester part no. 87387212800
£156.88
14   SHAPED SEAL
Worcester part no. 87002010120
£13.68
15   SCREW
Worcester part no. 87034011090
£12.32
16 Part number 87083001120, PRINTED CIRCUIT (TRANSCEIVER) PRINTED CIRCUIT (TRANSCEIVER)
Worcester part no. 87083001120
£281.22
17   TRANSCEIVER CABLE
Worcester part no. 87044012440
£7.79
