VOKERA
VERVE REV 3 (07/2013) - (Burner)
Appliance Code: 41-094-75 REV 3

Appliance Diagram


Burner diagram for Vokera Verve Rev 3 (07/2013)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

3 Part number 10028456, Fan (up to serial n.<20065834J1959999) FAN (UP TO SERIAL N.<20065834J1959999)
Vokera part no. 10028456		 £309.51
4 Part number 20028763, BURNER ASSEMBLY BURNER ASSEMBLY
Vokera part no. 20028763		 £115.18
5 Part number 20074728, Spark/Ignition electrode Replaced 10027620 SPARK/IGNITION ELECTRODE REPLACED 10027620
Vokera part no. 20074728		 £21.43
6 Part number 10026316, Sensing electrode SENSING ELECTRODE
Vokera part no. 10026316		 £12.30
12   PIPE
Vokera part no. 20028738		 £33.43
13 Part number 20039202, Gas valve Rep 10028538 & 10027187 & 20025752 GAS VALVE REP 10028538 & 10027187 & 20025752
Vokera part no. 20039202		 £170.04
14   PIPE
Vokera part no. 20028749		 £22.28
15   GAS COCK
Vokera part no. 7330		 £38.20
16 Part number 20040675, Gas Valve Solenoid (Fits 20039202/20035533) GAS VALVE SOLENOID (FITS 20039202/20035533)
Vokera part no. 20040675		 £79.58
19 Part number 10026328, Glass assembly GLASS ASSEMBLY
Vokera part no. 10026328		 £8.31
31   STUB PIPE
Vokera part no. 20028745		 £39.79
35 Part number 10028420, Air gas conveyor AIR GAS CONVEYOR
Vokera part no. 10028420		 £49.54
36   CONVEYOR
Vokera part no. 20028739		 £71.09
46   NG INJECTOR
Vokera part no. 20028762		 £11.67
58 Part number 20025757, Copper Tail 22mm COPPER TAIL 22MM
Vokera part no. 20025757		 £8.07
67 Part number 10026322, Washer WASHER
Vokera part no. 10026322		 £21.67
68   FLANGE AND INSULATION
Vokera part no. 20046837		 £32.68
69 Part number 20046839, Tryton and Screws TRYTON AND SCREWS
Vokera part no. 20046839		 £17.09
72   MIXER
Vokera part no. 20028741		 £67.91
79 Part number 10028422, Flame detection electrode FLAME DETECTION ELECTRODE
Vokera part no. 10028422		 £21.15
88 Part number 20006411, Fan baffle FAN BAFFLE
Vokera part no. 20006411		 £8.46
92   SUCTION PIPE
Vokera part no. 20028759		 £85.94
200 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023		 £0.43
486 Part number 10026325, O ring O RING
Vokera part no. 10026325		 £2.52
497 Part number 10026796, Fan Gasket FAN GASKET
Vokera part no. 10026796		 £7.18
613 Part number 20001563, NOW USE 20002969 IGNITION TRANSFORMER NOW USE 20002969 IGNITION TRANSFORMER
Vokera part no. 20001563
613 Part number 20002969, Ignition transformer with wires Rep 10026237 & 20001563 IGNITION TRANSFORMER WITH WIRES REP 10026237 & 20001563
Vokera part no. 20002969		 £42.16
696 Part number 20028744, O RING O RING
Vokera part no. 20028744		 £1.77
697   WASHER
Vokera part no. 20028737		 £2.98
698 Part number 20028746, WASHER WASHER
Vokera part no. 20028746		 £8.44
700 Part number 10026558, TSC1 (ignition transformer) to Spark electrode Wiring TSC1 (IGNITION TRANSFORMER) TO SPARK ELECTRODE WIRING
Vokera part no. 10026558		 £10.79
701   CN3 - FAN WIRING HARNESS
Vokera part no. 20040987		 £39.79
702   CN1 - IGN TRANSFORMER + FA1 WIRING HARNESS
Vokera part no. 20040982		 £28.65
703   CN10 - FAN WIRING HARNESS
Vokera part no. 20040983		 £22.81
800   LPG TO NG CONVERSION KIT
Vokera part no. 20032150		 £13.87
801   NG TO LPG CONVERSION KIT
Vokera part no. 20032155		 £14.33
