VOKERA
MYNUTE 20 VHE REV 15 (02/2017) - (Hydraulics 1)
Appliance Code: 41-094-70 REV 15

Appliance Diagram


Hydraulics 1 diagram for Vokera Mynute 20 VHE Rev 15 (02/2017)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

25   PIPE
Vokera part no. 10029590
£15.49
27   PIPE
Vokera part no. 10029592
£10.93
36   PIPE
Vokera part no. 10029591
£14.85
200 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023
£0.43
580   CONNECTION
Vokera part no. 10029526
£10.87
