Appliance Code: 32-810-59

Appliance Diagram


Fire Front diagram for Valor Gas Fire VenetianClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2   OBSOLETE SPIGOT PLATE
Valor Gas Fire part no. 0513659
3   NOW USE 0511569 8X3/8 SCREW
Valor Gas Fire part no. 511569
3   8X3/8 SCREW
Valor Gas Fire part no. 0511569
4   OBSOLETE BACK PANEL ASS
Valor Gas Fire part no. 0513669
5   OBSOLETE HEAT EXCHANGER ASS
Valor Gas Fire part no. 0513679
7   OBSOLETE RAD BOX & RIVET BUSHESSUB-ASSY
Valor Gas Fire part no. 0513689
8   OBSOLETE GASKET
Valor Gas Fire part no. 0513699
9   OBSOLETE GASKET
Valor Gas Fire part no. 0513709
11   OBSOLETE SUPPORT STRAP
Valor Gas Fire part no. 0513719
13   OBSOLETE BUSH RAD BOX TOP SUB-
Valor Gas Fire part no. 0513729
15 Part number 0534629, SCREW SCREW
Valor Gas Fire part no. 0534629
15   NOW USE 0534629 SCREW
Valor Gas Fire part no. 534629
16   OBSOLETE WINDOW & FRAME ASS
Valor Gas Fire part no. 0513739
17   OBSOLETE L/H GLASS FRAME RET
Valor Gas Fire part no. 0513749
20   OBSOLETE BURNER BRACKET
Valor Gas Fire part no. 0513769
21   OBSOLETE CERAMICS RETAINER
Valor Gas Fire part no. 0513779
23   OBSOLETE BURNER
Valor Gas Fire part no. 0513789
25   OBSOLETE MANIFOLD
Valor Gas Fire part no. 0513809
26   OBSOLETE M4X6MM PN D POZI S/ST
Valor Gas Fire part no. 0513819
28   OBSOLETE MANIFOLD REST- TOR
Valor Gas Fire part no. 0513829
30   OBSOLETE FLICKER TUBE
Valor Gas Fire part no. 0513839
31   OBSOLETE FLICKER TUBE
Valor Gas Fire part no. 0513849
32   OBSOLETE OLIVE
Valor Gas Fire part no. 0513859
34   OBSOLETE FLAME EFFECT BURNER
Valor Gas Fire part no. 0513879
35 Part number 635506, NUT M5 FULL BRASS NUT M5 FULL BRASS
Valor Gas Fire part no. 635506
36   OBSOLETE WASHER
Valor Gas Fire part no. 0515509
36   OBSOLETE WASHER
Valor Gas Fire part no. 515509
37   OBSOLETE BASE BOARD
Valor Gas Fire part no. 0513889
38   OBSOLETE COALS BACK SUPPORT
Valor Gas Fire part no. 0513899
42   OBSOLETE TAP(SOURDILLON- KIT)
Valor Gas Fire part no. 0513909
42 Part number 0513919, NLA GAS TAP REF TE SA 961 NLA GAS TAP REF TE SA 961
Valor Gas Fire part no. 0513919
43   NOW USE 0502739 LOCK NUT
Valor Gas Fire part no. 502739
43   LOCK NUT
Valor Gas Fire part no. 0502739
44   OBSOLETE THERMOCOUPLE BRACKET
Valor Gas Fire part no. 0513929
48 Part number 534149, OBSOLETE SPARK ELECTRODE OBSOLETE SPARK ELECTRODE
Valor Gas Fire part no. 534149
48 Part number 0534149, OBSOLETE ELECTRODE ASS. OBSOLETE ELECTRODE ASS.
Valor Gas Fire part no. 0534149
51   OBSOLETE TAP-MAIN BURNER UPPER
Valor Gas Fire part no. 0513939
51   OBSOLETE TAP MAIN BURNER UPPER
Valor Gas Fire part no. 0513949
52   OBSOLETE TAP MAIN BURNER LOWER
Valor Gas Fire part no. 0513969
52   OBSOLETE TAP BURNER LOWER
Valor Gas Fire part no. 0513959
53   OBSOLETE TAP/T.PCE-CEN. BRNRSP
Valor Gas Fire part no. 0513989
53   OBSOLETE TAP/T.PCE-CEN. BRNRSP
Valor Gas Fire part no. 0513979
54   OBSOLETE TEE FITTING
Valor Gas Fire part no. 0513999
55   OBSOLETE T.PCE-CENTRE DEC BRNR
Valor Gas Fire part no. 0514009
56   OBSOLETE CONNECTION & RESTRICTOR AS
Valor Gas Fire part no. 0514669
57   OBSOLETE T.PCE-CENTRE MANIFOLD
Valor Gas Fire part no. 0514019
58   OBSOLETE TAP/.PCE-OUTER MANFLDP
Valor Gas Fire part no. 0514029
58   OBSOLETE TAP/T.PCE-OUTER MANIFOLD
Valor Gas Fire part no. 0514039
59   OBSOLETE TEE FITTING
Valor Gas Fire part no. 0514049
60   OBSOLETE T.PCE-LH MANIFOLD PIPE
Valor Gas Fire part no. 0514059
61   OBSOLETE T.PCE-R/HAND MANIFOLD PIPE
Valor Gas Fire part no. 0514069
62   OBSOLETE L/H INLET PIPE
Valor Gas Fire part no. 0514079
62   OBSOLETE L/H INLET PIPE
Valor Gas Fire part no. 0514089
63   OBSOLETE R/H INLET PIPE
Valor Gas Fire part no. 0514099
63   OBSOLETE R/H INLET PIPE
Valor Gas Fire part no. 0514109
65   OBSOLETE INLET ELBOW
Valor Gas Fire part no. 0514119
67   NOW USE 0513359 SCREW
Valor Gas Fire part no. 513359
67   SCREW
Valor Gas Fire part no. 0513359
68   OBSOLETE L/H CASE SIDE BAFFLE
Valor Gas Fire part no. 0514129
69   OBSOLETE R/H CASE SIDE BAFFLE
Valor Gas Fire part no. 0514139
71   OBSOLETE R/H REAR SIDE PANEL
Valor Gas Fire part no. 0514149
72   OBSOLETE L/H REAR SIDE PANEL
Valor Gas Fire part no. 0514159
74   OBSOLETE TOP BAFFLE
Valor Gas Fire part no. 0514169
76   OBSOLETE CASING TOP ASSEMBLY
Valor Gas Fire part no. 0514179
78   OBSOLETE R/H FRONT SIDE PANEL
Valor Gas Fire part no. 0514189
79   OBSOLETE L/H FRONT SIDE PANEL
Valor Gas Fire part no. 0514209
80   OBSOLETE L/H TIE BRACKET
Valor Gas Fire part no. 0514199
83   OBSOLETE CROSS MEMBER & FEET ASSEMBLY
Valor Gas Fire part no. 0514219
84   OBSOLETE PIEZO BRACKET
Valor Gas Fire part no. 0514229
87 Part number 554909, OBSOLETE PIEZO + NUT OBSOLETE PIEZO + NUT
Valor Gas Fire part no. 554909
87 Part number 0554909, OBSOLETE PIEZO & NUT ASSY OBSOLETE PIEZO & NUT ASSY
Valor Gas Fire part no. 0554909
91   OBSOLETE R/HAND GUSSET
Valor Gas Fire part no. 0514239
92   OBSOLETE L/HAND GUSSET
Valor Gas Fire part no. 0514249
94   OBSOLETE TOP CASTING
Valor Gas Fire part no. 0514259
95   OBSOLETE TOP OUTLET GRILLE
Valor Gas Fire part no. 0514269
98   OBSOLETE HOUSING/BULB HLDR BRK
Valor Gas Fire part no. 0514279
99   OBSOLETE CORD GRIP BRACKET
Valor Gas Fire part no. 0514289
103   OBSOLETE MAINS LEAD
Valor Gas Fire part no. 0514299
111   OBSOLETE BLACK PV748GROMME
Valor Gas Fire part no. 0514309
112   OBSOLETE LAMP HOLDER
Valor Gas Fire part no. 0514319
113   OBSOLETE SCREW
Valor Gas Fire part no. 0514329
114   OBSOLETE NUT
Valor Gas Fire part no. 0514339
116   OBSOLETE TERM BLOCK-LAMP HOLDE
Valor Gas Fire part no. 0514349
117   OBSOLETE INSULATION SLEEVE
Valor Gas Fire part no. 0514359
120   OBSOLETE FRONT COVER CASTING
Valor Gas Fire part no. 0514369
121   OBSOLETE FRONT COVER GRILLE
Valor Gas Fire part no. 0514379
123   OBSOLETE DRESS GUARD
Valor Gas Fire part no. 0514389
124   OBSOLETE FRONT CASTING SUB-ASS
Valor Gas Fire part no. 0514399
125   OBSOLETE LOWER GRILLE SUB-ASSY
Valor Gas Fire part no. 0514409
127   OBSOLETE UPPER GRILLE
Valor Gas Fire part no. 0514419
129   OBSOLETE LOWER GUARD
Valor Gas Fire part no. 0514429
133   OBSOLETE LOWER FRONT CASTING H
Valor Gas Fire part no. 0514689
134   OBSOLETE CENTRAL SWAG
Valor Gas Fire part no. 0514469
135   OBSOLETE R/H DECORATIVE SWAG
Valor Gas Fire part no. 0514479
136   OBSOLETE L/H DECORATIVE SWAG
Valor Gas Fire part no. 0514489
137   NOW USE 0534419 FIX
Valor Gas Fire part no. 534419
137   FIX
Valor Gas Fire part no. 0534419
139   OBSOLETE BEZEL
Valor Gas Fire part no. 0514499
142   OBSOLETE COAL SUPPORT
Valor Gas Fire part no. 0514509
143   OBSOLETE FLOOR PLATE
Valor Gas Fire part no. 0514519
144   OBSOLETE CLOSURE PLATE ASS
Valor Gas Fire part no. 0514529
145   OBSOLETE CLOSURE PLATE BAFFLE
Valor Gas Fire part no. 0517709
147   OBSOLETE CLOSURE PLATE COVER
Valor Gas Fire part no. 0514539
149   OBSOLETE R/H SIDE CHEEK
Valor Gas Fire part no. 0514549
150 Part number 0514559, OBSOLETE L/H SIDE CHEEK OBSOLETE L/H SIDE CHEEK
Valor Gas Fire part no. 0514559
151   OBSOLETE NO.1 COAL
Valor Gas Fire part no. 0514569
152   OBSOLETE NO.2 & 7 COALS PACK
Valor Gas Fire part no. 0514579
152   OBSOLETE COAL NO.2
Valor Gas Fire part no. 0518499
153   OBSOLETE NO.3 & 6 COALS PACK
Valor Gas Fire part no. 0514589
153   OBSOLETE COAL NO.3
Valor Gas Fire part no. 0518509
154   OBSOLETE NO.4 COAL
Valor Gas Fire part no. 0514599
155   OBSOLETE NO.5 COAL
Valor Gas Fire part no. 0514609
156   OBSOLETE COAL 3 & 6
Valor Gas Fire part no. 0514619
156   OBSOLETE COAL NO.6
Valor Gas Fire part no. 0518519
157   OBSOLETE COAL NO.7
Valor Gas Fire part no. 0518529
157   OBSOLETE COAL 2 & 7
Valor Gas Fire part no. 0514629
158   OBSOLETE NO.8 COAL
Valor Gas Fire part no. 0514639
159   OBSOLETE USERS 497 INSTRUCTIONS
Valor Gas Fire part no. 0514649
160   OBSOLETE INSTALLATION 497 INSTRUCTIONS
Valor Gas Fire part no. 0514659


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
