VAILLANT
VWL 55/2 A 230V 2014 ONWARDS - (06B Hydraulics)
Appliance Code: 0010014566

Appliance Diagram


06B Hydraulics diagram for Vaillant VWL 55/2 A 230V 2014 OnwardsClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020148022, Sensor, temperature SENSOR, TEMPERATURE
Vaillant part no. 0020148022
£12.76
2 Part number 0020192793, Tube, pump TUBE, PUMP
Vaillant part no. 0020192793
£69.55
3 Part number 981311, O-ring (PK10) O-RING (PK10)
Vaillant part no. 981311
£7.05
4 Part number 0020192794, Tube, heating inlet TUBE, HEATING INLET
Vaillant part no. 0020192794
£111.29
5 Part number 0020175872, Pump PUMP
Vaillant part no. 0020175872
£231.25
6 Part number 0020175873, Wiring harness, pump WIRING HARNESS, PUMP
Vaillant part no. 0020175873
£16.91
7 Part number 0020192795, Tube, Heating outlet TUBE, HEATING OUTLET
Vaillant part no. 0020192795
£105.35
8 Part number 0020192806, PLUG PLUG
Vaillant part no. 0020192806
£5.46
9 Part number 0020166927, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 0020166927
£6.71
10 Part number 0020107589, O-ring (PK5) O-RING (PK5)
Vaillant part no. 0020107589
£6.53
11 Part number 0020175867, Clip, and insulation NTC CLIP, AND INSULATION NTC
Vaillant part no. 0020175867
£6.71
12 Part number 0020174526, Clip (PK10) CLIP (PK10)
Vaillant part no. 0020174526
£6.71
