VAILLANT
VWL 155/2 A 230V 2014 ONWARDS - (07C Casing)
Appliance Code: 0010014567

Appliance Diagram


07C Casing diagram for Vaillant VWL 155/2 A 230V 2014 OnwardsClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   BACK PANEL
Vaillant part no. 0020192751
£255.73
2 Part number 0020192752, Grille GRILLE
Vaillant part no. 0020192752
£205.64
3 Part number 0020192753, Side panel, left SIDE PANEL, LEFT
Vaillant part no. 0020192753
£138.92
4 Part number 0020192755, Casing, top CASING, TOP
Vaillant part no. 0020192755
£220.00
4 Part number 0020192754, Casing, bottom CASING, BOTTOM
Vaillant part no. 0020192754
£128.96
5 Part number 0020192756, Side panel SIDE PANEL
Vaillant part no. 0020192756
£95.27
6 Part number 0020192757, Side panel, right SIDE PANEL, RIGHT
Vaillant part no. 0020192757
£161.06
7   GRILLE
Vaillant part no. 0020192758
£359.53
8 Part number 0020170443, Cover plate COVER PLATE
Vaillant part no. 0020170443
£571.21
9 Part number 0020175806, Panel, Connection PANEL, CONNECTION
Vaillant part no. 0020175806
£28.23
10 Part number 0020175810, Screw (PK10) SCREW (PK10)
Vaillant part no. 0020175810
£6.53
11 Part number 0020175807, Damper DAMPER
Vaillant part no. 0020175807
£16.11
12 Part number 0020085444, Fastening kit, Clips Bush/Stud (PK10) FASTENING KIT, CLIPS BUSH/STUD (PK10)
Vaillant part no. 0020085444
£18.42
13 Part number 0020175808, Stuffing box, M20-10 STUFFING BOX, M20-10
Vaillant part no. 0020175808
£6.71
14 Part number 0020175809, Stuffing box, M25-17 STUFFING BOX, M25-17
Vaillant part no. 0020175809
£6.85
15 Part number 0020183483, Insulation INSULATION
Vaillant part no. 0020183483
£6.71
16 Part number 0020186354, Connection kit CONNECTION KIT
Vaillant part no. 0020186354

17 Part number 0020060808, Hose (supply air, long) HOSE (SUPPLY AIR, LONG)
Vaillant part no. 0020060808
£6.66
