VAILLANT
MAG 125/11 XZ 1997-1999 - (02 Gas Section)
Appliance Code: 125/11 XZ

Appliance Diagram


02 Gas Section diagram for Vaillant Mag 125/11 XZ 1997-1999Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 981162, Sealing ring (PK10) SEALING RING (PK10)
Vaillant part no. 981162
£5.13
1A   OBSOLETE CONNECTION PIECE, CPL.
Vaillant part no. 084955

2 Part number 118936, Cheese head screw KS/S CHEESE HEAD SCREW KS/S
Vaillant part no. 118936
£5.13
3   OBSOLETE SUPPORT
Vaillant part no. 086950

3A Part number 118956, flat head screw FLAT HEAD SCREW
Vaillant part no. 118956
£5.13
4   PAN HEAD SCREW
Vaillant part no. 118889

5   OBSOLETE SPRING
Vaillant part no. 104151

6 Part number 021703, water deficcieny valve WATER DEFICCIENY VALVE
Vaillant part no. 021703
£13.50
7 Part number 980618, Gasket GASKET
Vaillant part no. 980618

8   OBSOLETE PIN
Vaillant part no. 128198

9   OBSOLETE GAS SECTION
Vaillant part no. 053324

10 Part number 118956, flat head screw FLAT HEAD SCREW
Vaillant part no. 118956
£5.13
11   SCREW
Vaillant part no. 040038

12 Part number 105804, cylinder screw CYLINDER SCREW
Vaillant part no. 105804
£5.13
13 Part number 170368, magneto MAGNETO
Vaillant part no. 170368
£20.13
14   PACKING RING
Vaillant part no. 981747
£3.91
15 Part number 020679, main gas valve MAIN GAS VALVE
Vaillant part no. 020679
£13.50
16   OBSOLETE SPRING
Vaillant part no. 104316

17 Part number 980617, Gasket GASKET
Vaillant part no. 980617

19 Part number 118936, Cheese head screw KS/S CHEESE HEAD SCREW KS/S
Vaillant part no. 118936
£5.13
20 Part number 091060, piezo ignition PIEZO IGNITION
Vaillant part no. 091060
£20.13
21   TAPPING SCREW (ST 4,8X13)
Vaillant part no. 235732
£5.13
22   OBSOLETE SUPPORT
Vaillant part no. 086504

23   PAN HEAD SCREW
Vaillant part no. 118889
