VAILLANT
FLEXOTHERM VWF 197/4 2015 ONWARDS - (08C Flexotherm 19/4 NC)
Appliance Code: 0010016697

Appliance Diagram


08C Flexotherm 19/4 NC diagram for Vaillant Flexotherm VWF 197/4 2015 OnwardsClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 0020210690, Heat exchanger HEAT EXCHANGER
Vaillant part no. 0020210690
£107.78
2 Part number 0020210640, Front panel FRONT PANEL
Vaillant part no. 0020210640
£41.47
3 Part number 0020210643, Housing HOUSING
Vaillant part no. 0020210643
£107.78
4 Part number 0020093237, Screw, EPP SCREW, EPP
Vaillant part no. 0020093237
£7.88
5 Part number 0020032008, Valve VALVE
Vaillant part no. 0020032008
£99.14
6 Part number 0020046109, Motor, actuator mixer MOTOR, ACTUATOR MIXER
Vaillant part no. 0020046109
£126.23
7 Part number 0020038758, Motor, actuator MOTOR, ACTUATOR
Vaillant part no. 0020038758
£178.31
8 Part number 0020210660, Wiring harness WIRING HARNESS
Vaillant part no. 0020210660
£28.26
9 Part number 981140, Sealing ring, 3/4 (PK10) SEALING RING, 3/4 (PK10)
Vaillant part no. 981140
£7.05
10 Part number 0020222912, Tube TUBE
Vaillant part no. 0020222912
£32.34
11 Part number 0020222912, Tube TUBE
Vaillant part no. 0020222912
£32.34
12 Part number 0020222913, Tube, bottom left TUBE, BOTTOM LEFT
Vaillant part no. 0020222913
£37.22
13 Part number 0020222914, Tube TUBE
Vaillant part no. 0020222914
£36.12
14 Part number 0020222884, Tube, diagonal TUBE, DIAGONAL
Vaillant part no. 0020222884
£28.26
15 Part number 0020222915, Tube, by-pass TUBE, BY-PASS
Vaillant part no. 0020222915
£46.22
16 Part number 981154, O-ring, (PK10) O-RING, (PK10)
Vaillant part no. 981154
£6.69
17 Part number 0020107694, Clip, (PK5) CLIP, (PK5)
Vaillant part no. 0020107694
£7.03
18 Part number 0020222885, Fastening kit, VWZ NC FASTENING KIT, VWZ NC
Vaillant part no. 0020222885
£38.74
