WORCESTER
WR8P 31 7701431556 - (Water Valve)
Appliance Code: 7701431556

Appliance Diagram


Water Valve diagram for Worcester WR8P 31 7701431556Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   WATER VALVE (OVAL DIAPHRAGM)
Worcester part no. 8738710127
2   COVER
Worcester part no. 87055001050
£17.06
3   SCREW (10X)
Worcester part no. 87034010840
£3.78
4   PUSHROD (10X)
Worcester part no. 87032040510
£23.54
5   DIAPHRAGM E OVAL
Worcester part no. 87005030850
6   WIRE FORM SPRING (10X)
Worcester part no. 87047050290
£3.71
7   INLET WATER CONNECTION
Worcester part no. 87003061100
£15.42
8   O-RING (10X)
Worcester part no. 87402050040
£1.36
9   RETAINING CLIP
Worcester part no. 87047050240
£1.37
10   SELECTOR SCREW
Worcester part no. 87085003320
11 Part number 87002050230, O-RING (10X) O-RING (10X)
Worcester part no. 87002050230
£1.55
12   CALIBRATION SCREW
Worcester part no. 87035020390
£7.57
13 Part number 87005070590, INLET FILTER INLET FILTER
Worcester part no. 87005070590
£5.66
14   O-RING (10X)
Worcester part no. 87002051280
£5.89
15   VOLUMETRIC WATER GOVERNOR
Worcester part no. 87057050340
£47.80
16   O-RING (10X)
Worcester part no. 87002051150
£0.59
17   VENTURI (23S)
Worcester part no. 87082052790
£4.86
18 Part number 87002050070, O-RING (10X) O-RING (10X)
Worcester part no. 87002050070
£1.37
19   NOW USE 8738714121 FILTER PLUG
Worcester part no. 87003061480

19   FILTER PLUG
Worcester part no. 8738714121
£4.53
20   COVER WR (FOR OVAL DIAPHRAGM)
Worcester part no. 8738710131
£19.58
21   DIAPHRAGM E OVAL
Worcester part no. 8738710130
