IDEAL
TURBO 12 - (Burner Control Ass 1)
Appliance Code: 41-415-18

Appliance Diagram


Burner Control Ass 1 diagram for Ideal Turbo 12Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE CROSS TRIM E16161:TURBO 12
Ideal part no. 130778
0   OBSOLETE RH SIDE TRIM:TURBO 12
Ideal part no. 130777
0   OBSOLETE L.H SIDE TRIM E1616G:TURBO 12
Ideal part no. 130776
0 Part number 052888, HT LEAD ASSY 460mm LG RS/MEXSL HT LEAD ASSY 460MM LG RS/MEXSL
Ideal part no. 052888		 £3.54
1   OBSOLETE BLR BODY ASS:TURBO 12.
Ideal part no. 130518
3   OBSOLETE TUBE PACK ASS:TURBO 12
Ideal part no. 130525
4   OBSOLETE HEADER ASS:TURBO 12
Ideal part no. 130527
4   OBSOLETE COVER PLATE +GASKETS TURBO12
Ideal part no. 079621
5   OBSOLETE HT EXCHANGER COWL+DEFLECTOR
Ideal part no. 079623
6   OBSOLETE HT EXCHANGER/BNR BOX GASKETS
Ideal part no. 079622
7   OBSOLETE HEAT EXCH GSKT TURBO MK1
Ideal part no. 079574
8   OBSOLETE T/STAT POCKET LW7150 AGZ466016010
Ideal part no. 003572
9   OBSOLETE FLOW PIPE ASSY TURBO 1
Ideal part no. 130595
11 Part number 130542, OBSOLETE FAN ASSY TURBO 12 OBSOLETE FAN ASSY TURBO 12
Ideal part no. 130542
13 Part number 003205, OBSOLETE INJECTOR BNR BRAY CAT 10 SIZE 1150 OBSOLETE INJECTOR BNR BRAY CAT 10 SIZE 1150
Ideal part no. 003205
14   OBSOLETE BNR BOX ASS:TURBO 12
Ideal part no. 130519
15   OBSOLETE BNR TILE ASS TURBO 12
Ideal part no. 130553
16   OBSOLETE BNR SUPP BOX S/ASS:TURBO 12
Ideal part no. 130552
17   OBSOLETE BNR BOX INSULATION SET
Ideal part no. 079624
18   OBSOLETE SIGHT GLASS ASSY - BNR BOX
Ideal part no. 079333
20 Part number 003825, INJECTOR PILOT HONEYWELL 45900421-029 INJECTOR PILOT HONEYWELL 45900421-029
Ideal part no. 003825		 £5.68
21   OBSOLETE FLAME SENSING ELECTRODE.
Ideal part no. 004219
22 Part number 003278, OBSOLETE ELECTRODE TO DRG 003278A03 OBSOLETE ELECTRODE TO DRG 003278A03
Ideal part no. 003278
23   OBSOLETE PILOT PIPE TURBO 12
Ideal part no. 079562
24   OBSOLETE FLAME SENSING LEAD:TURBO 12
Ideal part no. 130605
25   OBSOLETE SUMP ASS TURBO 12
Ideal part no. 130520
26   OBSOLETE SUMP/HT EXCHANGER GASKET
Ideal part no. 079453
27   OBSOLETE DRAIN ASS TURBO 12
Ideal part no. 130604
28   OBSOLETE BLR FLUE DUCT ASSY TURBO 12
Ideal part no. 130594
28   OBSOLETE SUMP TO FLUE DUCT GASKET TURBO12
Ideal part no. 130602
30   OBSOLETE T/STAT RAK 21.4/3152
Ideal part no. 004610
33   OBSOLETE SOCKET + BK NUT 3 POLE SA2024
Ideal part no. 003435
34   OBSOLETE PLUG-BULGIN PX0587/ASHLY C4000
Ideal part no. 003069
35   OBSOLETE WIRE ENDED NEON
Ideal part no. 013357
37   OBSOLETE SPARK GENTR ASS TURBO 12
Ideal part no. 130574
39   OBSOLETE SATRONIC CTRL BOX DKG 972 MOD 10
Ideal part no. 002999
40   OBSOLETE CTRLS M/BRKT ASS:TURBO 12
Ideal part no. 130572
41   OBSOLETE HIGH STAT ESSEX TYPE.
Ideal part no. 013097
42   OBSOLETE SOLENOID VALVE W/ROGERS 91/373
Ideal part no. 065237
43   OBSOLETE PRESSURE SWITCH 80SR 439 B/T GAS
Ideal part no. 013363
44   OBSOLETE HIGH PRESSURE PIPE:TURBO 12
Ideal part no. 130609
45   OBSOLETE LOW PRESS PIPE:TURBO 12
Ideal part no. 130608
47   OBSOLETE GAS PIPE-VLVE/BNR MAF TURBO12
Ideal part no. 079611
48   OBSOLETE GLASS FASCIA:TURBO 12
Ideal part no. 130775
48   OBSOLETE BOILER CASING TURBO 12.
Ideal part no. 130522
50   OBSOLETE CTRL CSG DOOR PTD ASS WLX
Ideal part no. 132314
51   OBSOLETE BK PNL/AIR DUCT ASS:TURBO 12
Ideal part no. 130517
52   OBSOLETE PUSH-ON S/PLATE ASS:TURBO 12
Ideal part no. 130613
54   OBSOLETE SEALING PACK TURBO 12
Ideal part no. 079573
55   OBSOLETE WALL MTG PLT ASS:TURBO 12
Ideal part no. 130612
56   OBSOLETE C PACK TERMINAL GRILLE TURBO
Ideal part no. 130512
57   OBSOLETE B PACK TERMINAL GRILLE TURBO
Ideal part no. 130513
58   OBSOLETE B1 PACK LONG FLUE:TURBO 12
Ideal part no. 130514
59   OBSOLETE O/HAUL GSKT SET TURBO 12 (KIT)
Ideal part no. 079171
60   OBSOLETE LEAKAGE CORRECT N KIT:TURBO 12
Ideal part no. 133164
