IDEAL
TURBO 12 - (Burner Assembly)
Appliance Code: 41-415-18

Appliance Diagram


Burner Assembly diagram for Ideal Turbo 12Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 052888, HT LEAD ASSY 460mm LG RS/MEXSL HT LEAD ASSY 460MM LG RS/MEXSL
Ideal part no. 052888
£3.54
0   OBSOLETE CROSS TRIM E16161:TURBO 12
Ideal part no. 130778

0   OBSOLETE RH SIDE TRIM:TURBO 12
Ideal part no. 130777

0   OBSOLETE L.H SIDE TRIM E1616G:TURBO 12
Ideal part no. 130776

1   OBSOLETE BLR BODY ASS:TURBO 12.
Ideal part no. 130518

3   OBSOLETE TUBE PACK ASS:TURBO 12
Ideal part no. 130525

4   OBSOLETE HEADER ASS:TURBO 12
Ideal part no. 130527

4   OBSOLETE COVER PLATE +GASKETS TURBO12
Ideal part no. 079621

5   OBSOLETE HT EXCHANGER COWL+DEFLECTOR
Ideal part no. 079623

6   OBSOLETE HT EXCHANGER/BNR BOX GASKETS
Ideal part no. 079622

7   OBSOLETE HEAT EXCH GSKT TURBO MK1
Ideal part no. 079574

8   OBSOLETE T/STAT POCKET LW7150 AGZ466016010
Ideal part no. 003572

9   OBSOLETE FLOW PIPE ASSY TURBO 1
Ideal part no. 130595

11 Part number 130542, OBSOLETE FAN ASSY TURBO 12 OBSOLETE FAN ASSY TURBO 12
Ideal part no. 130542

13 Part number 003205, OBSOLETE INJECTOR BNR BRAY CAT 10 SIZE 1150 OBSOLETE INJECTOR BNR BRAY CAT 10 SIZE 1150
Ideal part no. 003205

14   OBSOLETE BNR BOX ASS:TURBO 12
Ideal part no. 130519

15   OBSOLETE BNR TILE ASS TURBO 12
Ideal part no. 130553

16   OBSOLETE BNR SUPP BOX S/ASS:TURBO 12
Ideal part no. 130552

17   OBSOLETE BNR BOX INSULATION SET
Ideal part no. 079624

18   OBSOLETE SIGHT GLASS ASSY - BNR BOX
Ideal part no. 079333

20 Part number 003825, INJECTOR PILOT HONEYWELL 45900421-029 INJECTOR PILOT HONEYWELL 45900421-029
Ideal part no. 003825
£5.68
21   OBSOLETE FLAME SENSING ELECTRODE.
Ideal part no. 004219

22 Part number 003278, OBSOLETE ELECTRODE TO DRG 003278A03 OBSOLETE ELECTRODE TO DRG 003278A03
Ideal part no. 003278

23   OBSOLETE PILOT PIPE TURBO 12
Ideal part no. 079562

24   OBSOLETE FLAME SENSING LEAD:TURBO 12
Ideal part no. 130605

25   OBSOLETE SUMP ASS TURBO 12
Ideal part no. 130520

26   OBSOLETE SUMP/HT EXCHANGER GASKET
Ideal part no. 079453

27   OBSOLETE DRAIN ASS TURBO 12
Ideal part no. 130604

28   OBSOLETE BLR FLUE DUCT ASSY TURBO 12
Ideal part no. 130594

28   OBSOLETE SUMP TO FLUE DUCT GASKET TURBO12
Ideal part no. 130602

30   OBSOLETE T/STAT RAK 21.4/3152
Ideal part no. 004610

33   OBSOLETE SOCKET + BK NUT 3 POLE SA2024
Ideal part no. 003435

34   OBSOLETE PLUG-BULGIN PX0587/ASHLY C4000
Ideal part no. 003069

35   OBSOLETE WIRE ENDED NEON
Ideal part no. 013357

37   OBSOLETE SPARK GENTR ASS TURBO 12
Ideal part no. 130574

39   OBSOLETE SATRONIC CTRL BOX DKG 972 MOD 10
Ideal part no. 002999

40   OBSOLETE CTRLS M/BRKT ASS:TURBO 12
Ideal part no. 130572

41   OBSOLETE HIGH STAT ESSEX TYPE.
Ideal part no. 013097

42   OBSOLETE SOLENOID VALVE W/ROGERS 91/373
Ideal part no. 065237

43   OBSOLETE PRESSURE SWITCH 80SR 439 B/T GAS
Ideal part no. 013363

44   OBSOLETE HIGH PRESSURE PIPE:TURBO 12
Ideal part no. 130609

45   OBSOLETE LOW PRESS PIPE:TURBO 12
Ideal part no. 130608

47   OBSOLETE GAS PIPE-VLVE/BNR MAF TURBO12
Ideal part no. 079611

48   OBSOLETE GLASS FASCIA:TURBO 12
Ideal part no. 130775

48   OBSOLETE BOILER CASING TURBO 12.
Ideal part no. 130522

50   OBSOLETE CTRL CSG DOOR PTD ASS WLX
Ideal part no. 132314

51   OBSOLETE BK PNL/AIR DUCT ASS:TURBO 12
Ideal part no. 130517

52   OBSOLETE PUSH-ON S/PLATE ASS:TURBO 12
Ideal part no. 130613

54   OBSOLETE SEALING PACK TURBO 12
Ideal part no. 079573

55   OBSOLETE WALL MTG PLT ASS:TURBO 12
Ideal part no. 130612

56   OBSOLETE C PACK TERMINAL GRILLE TURBO
Ideal part no. 130512

57   OBSOLETE B PACK TERMINAL GRILLE TURBO
Ideal part no. 130513

58   OBSOLETE B1 PACK LONG FLUE:TURBO 12
Ideal part no. 130514

59   OBSOLETE O/HAUL GSKT SET TURBO 12 (KIT)
Ideal part no. 079171

60   OBSOLETE LEAKAGE CORRECT N KIT:TURBO 12
Ideal part no. 133164
