GLOWWORM
XTRAMAX - (06 Harness)
Appliance Code: 47-047-15

Appliance Diagram


06 Harness diagram for Glowworm XtramaxClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

24 Part number S5744000, Air Pressure Switch AIR PRESSURE SWITCH
Glowworm part no. S5744000

25   OBSOLETE FAN HARNESS ISOFAST F28E
Glowworm part no. 05724100

27 Part number S5739800, Temperature sensor TEMPERATURE SENSOR
Glowworm part no. S5739800
£23.87
28 Part number 05722000, OBSOLETE SWITCH ISOFAST F28E OBSOLETE SWITCH ISOFAST F28E
Glowworm part no. 05722000

29 Part number 05721000, Display module DISPLAY MODULE
Glowworm part no. 05721000

30 Part number S5739800, Temperature sensor TEMPERATURE SENSOR
Glowworm part no. S5739800
£23.87
31   OBSOLETE CVI HARNESS ISOFAST F28E
Glowworm part no. 05724300

32 Part number 05707900, Spark generator SPARK GENERATOR
Glowworm part no. 05707900

33 Part number 05724800, Printed circuit board PRINTED CIRCUIT BOARD
Glowworm part no. 05724800

34 Part number S5408100, OBSOLETE Fuse 125mA (PK5) OBSOLETE FUSE 125MA (PK5)
Glowworm part no. S5408100

35 Part number 05721900, OBSOLETE 3-WAY VALVE HARNESS F28E OBSOLETE 3-WAY VALVE HARNESS F28E
Glowworm part no. 05721900

36 Part number 05721200, Temperature limiter TEMPERATURE LIMITER
Glowworm part no. 05721200

37   OBSOLETE MECHANICAL CLOCK
Glowworm part no. 05724500

38   OBSOLETE CLOCK HARNESS ISOFAST F28E
Glowworm part no. 05724600

100   OBSOLETE WIRING HARNESS
Glowworm part no. 05737500
