GLOWWORM
XTRAMAX - (04 Burner)
Appliance Code: 47-047-15

Appliance Diagram


04 Burner diagram for Glowworm XtramaxClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

14 Part number 05719500, Ignition electrode IGNITION ELECTRODE
Glowworm part no. 05719500

15   NOW USE S5490600 SCREW PACK (PK50)
Glowworm part no. 05490600

15 Part number S5490600, Screw (pk50) SCREW (PK50)
Glowworm part no. S5490600
£14.38
16 Part number 05735800, IGNITION ELECTRODE IGNITION ELECTRODE
Glowworm part no. 05735800

17 Part number 05737700, OBSOLETE BURNER G20 Type F OBSOLETE BURNER G20 TYPE F
Glowworm part no. 05737700

18 Part number 05232100, Burner chamber group (PK4) BURNER CHAMBER GROUP (PK4)
Glowworm part no. 05232100
£18.94
19 Part number S5485200, Sealing ring (PK100) SEALING RING (PK100)
Glowworm part no. S5485200
£13.40
26 Part number S5296900, Injector G20 (PK16) INJECTOR G20 (PK16)
Glowworm part no. S5296900

26 Part number S5299200, OBSOLETE Injector 0.77 OBSOLETE INJECTOR 0.77
Glowworm part no. S5299200
