COMBITEK F23E - (Exploded View)
Appliance Code: COM_STI_210_1

Appliance Diagram


Exploded View diagram for Ariston Comfort STI 210 Edition 1Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 969040, NOW USE 406953 T + P VALVE NOW USE 406953 T + P VALVE
Ariston part no. 969040

1 Part number 406953, VALVE T&P VALVE T&P
Ariston part no. 406953
£108.76
2 Part number 919054-01, ANODE MG D:26 L320 PTFE ANODE MG D:26 L320 PTFE
Ariston part no. 919054-01
£24.18
2 Part number 919054, NOW USE 919054-01 ANODE D:26 L:320 + PLUG M1 NOW USE 919054-01 ANODE D:26 L:320 + PLUG M1
Ariston part no. 919054

3 Part number 926136, FOOT (100 MM) FOOT (100 MM)
Ariston part no. 926136
£25.58
4 Part number 924087, HEATING ELEMENT GASKET HEATING ELEMENT GASKET
Ariston part no. 924087
£15.16
5 Part number 396146, ELEMENT POCKET (2 1/4 ) ELEMENT POCKET (2 1/4 )
Ariston part no. 396146
£94.61
6   FIXING PLATE (HEATING ELEMENT)
Ariston part no. 323404
£8.98
7   SCREW (M5X30)
Ariston part no. 318613
£0.13
8 Part number 396147, NOW USE 396010-01 HEATING ELEMENT (STEATITE - 30 NOW USE 396010-01 HEATING ELEMENT (STEATITE - 30
Ariston part no. 396147

8 Part number 396010-01, HEATING ELEMENT (3000W) HEATING ELEMENT (3000W)
Ariston part no. 396010-01
£82.39
9 Part number 921049, THERMOSTAT (THERMAL CUT-OUT) THERMOSTAT (THERMAL CUT-OUT)
Ariston part no. 921049
£22.73
10   THERMOSTAT SUPPORT BRACKET
Ariston part no. 935190
£15.15
11   THERMOSTAT CUT-OUT (FIRT)
Ariston part no. 921050
£11.20
12 Part number 921048, THERMOSTAT (REGULATION) THERMOSTAT (REGULATION)
Ariston part no. 921048
£34.07
13 Part number 921047, THERMOSTAT (REGULATION - DIREC THERMOSTAT (REGULATION - DIREC
Ariston part no. 921047
£17.63
14 Part number 935189, CABLE + TERMINAL BLOCK KIT CABLE + TERMINAL BLOCK KIT
Ariston part no. 935189
£5.03
15 Part number 925275, THERMOSTAT + WIRING ASSEMBLY C THERMOSTAT + WIRING ASSEMBLY C
Ariston part no. 925275
£111.29
16   COVER
Ariston part no. 926276
£29.21
17 Part number 902188, THERMOSTAT POCKET THERMOSTAT POCKET
Ariston part no. 902188
£14.78
