WORCESTER
WR325-5AM1E31S0506 (MARCH 2000 ONWARDS) 7702411028 - (Burner)
Appliance Code: 7702411028

Appliance Diagram


Burner diagram for Worcester WR325-5AM1E31S0506 (March 2000 Onwards) 7702411028Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   BURNER NG
Worcester part no. 87081203350
£147.83
2   CONNECTOR
Worcester part no. 87052090140
£23.85
3   WASHER (10X)
Worcester part no. 87010030100
£0.72
4   NOZZLE (115) (10X)
Worcester part no. 87082021150
£1.50
5   SCREW (10X)
Worcester part no. 87034040890
£0.78
6   SCREW M4 X 12 PHILLIPS (10X)
Worcester part no. 29109521220
£0.67
7   SCREW M3,5X10 (10X)
Worcester part no. 87034010690
£0.59
8 Part number 87033051910, PRESSURE TAPPING PRESSURE TAPPING
Worcester part no. 87033051910
£2.45
9   CROSS IGNITION BRIDGE
Worcester part no. 87113043050
£15.42
10 Part number 87101030600, WASHER 1" (10X) WASHER 1" (10X)
Worcester part no. 87101030600
£3.04
11   ANGLE BRACKET
Worcester part no. 87113042870
£5.45
12   SCREW (10X)
Worcester part no. 29106194090
£0.59
13   NOW USE 87181070500 IGNITION ELECTRODE
Worcester part no. 87081070080

13 Part number 87181070500, SET OF ELECTRODES SET OF ELECTRODES
Worcester part no. 87181070500
£32.92
14 Part number 87181070500, SET OF ELECTRODES SET OF ELECTRODES
Worcester part no. 87181070500
£32.92
14   NOW USE 87181070500 SENSING ELECTRODE
Worcester part no. 87081070090

15   THROTTLE DISC (6,2)
Worcester part no. 87001001910
£1.36
