WORCESTER
WH1-FXN-GBNATGASRSF (SEPT 2001-JAN 2002) 7702311037 - (Heating Body)
Appliance Code: 7702311037

Appliance Diagram


Heating Body diagram for Worcester WH1-FXN-GBNATGASRSF (Sept 2001-Jan 2002) 7702311037Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 87054061980, HEATING BODY HEATING BODY
Worcester part no. 87054061980
£358.55
2   WASHER 25OD X 21ID X 2MM (10X)
Worcester part no. 87001031250
£1.84
3   LOCKNUT G 1/2" (10X)
Worcester part no. 87133000180
£2.70
4   NOW USE 8738717110 TEMPERATURE LIMIT 120 DEG C
Worcester part no. 87072061510

4   TEMPERATURE LIMITER
Worcester part no. 8738717110
£19.22
6   PIPE - COLD WATER
Worcester part no. 87007056450
£57.52
7 Part number 87101030450, WASHER 18.6 X 13.5 X 1.5 (10X) WASHER 18.6 X 13.5 X 1.5 (10X)
Worcester part no. 87101030450
£2.95
8   RETAINING CLIP (10X)
Worcester part no. 87047050250
£0.79
9 Part number 87002050230, O-RING (10X) O-RING (10X)
Worcester part no. 87002050230
£1.55
10   DRAIN OFF VALVE
Worcester part no. 87085050040
£46.43
11   WASHER
Worcester part no. 87001030060
£0.78
