WORCESTER
W135KV1B31S2805 7700431976 - (Casing)
Appliance Code: 7700431976

Appliance Diagram


Casing diagram for Worcester W135KV1B31S2805 7700431976Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   FRONT SHELL
Worcester part no. 87054116950		 £36.87
3   TRADE MARK BADGE
Worcester part no. 87011030470		 £2.81
6 Part number 87020002190, WATER FLOW SELECTOR HANDLE WATER FLOW SELECTOR HANDLE
Worcester part no. 87020002190		 £14.19
7 Part number 87020001110, WATER FLOW SELECTOR HANDLE WATER FLOW SELECTOR HANDLE
Worcester part no. 87020001110		 £3.94
8   DRAUGHT DIVERTER
Worcester part no. 87055053820
9 Part number 87034030120, NOW USE 87134030390SCREW M4,8X9,5 (10X) NOW USE 87134030390SCREW M4,8X9,5 (10X)
Worcester part no. 87034030120
9 Part number 87134030390, SCREW 4.8 X 30mm SET OF 3 SCREW 4.8 X 30MM SET OF 3
Worcester part no. 87134030390		 £4.61
10   COVERING SHEET
Worcester part no. 87180030320		 £1.81
11   SCREW (10X)
Worcester part no. 29106421520
