WORCESTER
W125V2P31S0506T1 (FEB 2000 ONWARDS) 7700452908 - (Heating Body)
Appliance Code: 7700452908

Appliance Diagram


Heating Body diagram for Worcester W125V2P31S0506T1 (Feb 2000 Onwards) 7700452908Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   HEAT EXCHANGER
Worcester part no. 87054062480		 £274.31
3   SCREW M6X13 PHILLIPS STEEL CROSS
Worcester part no. 29106194540		 £1.55
4   CARDBOARD WASHER
Worcester part no. 29160128940		 £0.50
5   WIRE FORM SPRING
Worcester part no. 87047050260		 £0.79
6 Part number 87002050010, O-RING (10X) O-RING (10X)
Worcester part no. 87002050010		 £2.25
7 Part number 87072061320, NOW USE 8738717111 TEMPERATURE LIMIT 110 DEC C. NOW USE 8738717111 TEMPERATURE LIMIT 110 DEC C.
Worcester part no. 87072061320
7   TEMPERATURE LIMITER
Worcester part no. 8738717111		 £19.22
8   SCREW M4X6MM STEEL PHILLIPS PAN HD
Worcester part no. 29109511160		 £0.59
