WORCESTER
MULTIPOINT BF ERP 7702311041 - (Heating Body)
Appliance Code: 7702311041

Appliance Diagram


Heating Body diagram for Worcester Multipoint BF ERP 7702311041Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   HEAT EXCHANGER
Worcester part no. 87054062930
2   WASHER 25OD X 21ID X 2MM (10X)
Worcester part no. 87001031250
£1.84
3   LOCKNUT G 1/2" (10X)
Worcester part no. 87133000180
£2.70
4   CONNECTING PIPE COLD
Worcester part no. 87007056440
5 Part number 87101030450, WASHER 18.6 X 13.5 X 1.5 (10X) WASHER 18.6 X 13.5 X 1.5 (10X)
Worcester part no. 87101030450
£2.95
6   RETAINING CLIP (10X)
Worcester part no. 87047050250
£0.79
7 Part number 87002050230, O-RING (10X) O-RING (10X)
Worcester part no. 87002050230
£1.55
8   DRAIN OFF VALVE
Worcester part no. 87085050040
£46.43
9   WASHER
Worcester part no. 87001030060
£0.78
10 Part number 87072061320, NOW USE 8738717111 TEMPERATURE LIMIT 110 DEC C. NOW USE 8738717111 TEMPERATURE LIMIT 110 DEC C.
Worcester part no. 87072061320

10   TEMPERATURE LIMITER
Worcester part no. 8738717111
£19.22
11   SCREW X10
Worcester part no. 29106411150
12   ACCESSORY NR.805
Worcester part no. 7709003131
