WORCESTER
HIU - (Mounting Plate)
Appliance Code: 7733600141

Appliance Diagram


Mounting Plate diagram for Worcester HiuClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   VALVE BRACKET ASSEMBLY
Worcester part no. 8716118073
2   BRACKET
Worcester part no. 8716118094
£8.68
3   WASHER PFTE
Worcester part no. 8716118454
4   PRV VALVE
Worcester part no. 8716118074
£9.43
5   VALVE FILLING LINK 16 BAR
Worcester part no. 8716118075
6   VALVE
Worcester part no. 8716118076
7 Part number 87186439890, SAFETY VALVE SAFETY VALVE
Worcester part no. 87186439890
£10.36
8 Part number 87186846990, CLIP WIRE 18MM (10X) CLIP WIRE 18MM (10X)
Worcester part no. 87186846990
£2.78
9 Part number 29144114030, NOW USE 87182242510 SCREW M5X12MM TAPTITE ZC PL P/H (10X) NOW USE 87182242510 SCREW M5X12MM TAPTITE ZC PL P/H (10X)
Worcester part no. 29144114030

9 Part number 87182242510, SCREW M5 X 10MM SCREW M5 X 10MM
Worcester part no. 87182242510
£1.56
10 Part number 87167711540, O-RING 17X4 (10X) AFTER FD992 O-RING 17X4 (10X) AFTER FD992
Worcester part no. 87167711540
£2.63
11 Part number 87186892750, CHARGING LINK KEYLESS CHARGING LINK KEYLESS
Worcester part no. 87186892750
£72.36
12   MOUNTING BRACKET
Worcester part no. 8716118083
13 Part number 29101411160, SCREW SOCKET HEAD CAP M4X6MM SCREW SOCKET HEAD CAP M4X6MM
Worcester part no. 29101411160
£1.19
14   WASHER - M4 LOCK (10X)
Worcester part no. 8716118137
15 Part number 87101031610, WASHER 18,3X24,3 (10X) WASHER 18,3X24,3 (10X)
Worcester part no. 87101031610
£8.27
