You can then pinch & zoom to adjust the size.
| 0 |  |
AIR-VENT AUTOMATIC 3/8 (SS KIT) Worcester part no. 87161405000 |
£11.25 | |
| 0 |  |
OBSOLETE VESSEL-EXPANSION-10LT(387X120) Worcester part no. 87161425130 |
||
| 0 | OBSOLETE KIT - SEALED SYSTEM Worcester part no. ZMMIS061 |
|||
| 1 | OBSOLETE DATA BADGE Worcester part no. ZKLAB093 |
|||
| 3 | OBSOLETE HEAT EXCHANGER Worcester part no. 87161204320 |
|||
| 3 | OBSOLETE HEAT EXCHANGER Worcester part no. 87161204330 |
|||
| 4 | OBSOLETE Worcester part no. 87161005970 |
|||
| 6 |  |
NOW USE 87161480110 CAP NUT 22MM Worcester part no. ZCCMP018 |
||
| 6 |  |
CAP NUT 22MM Worcester part no. 87161480110 |
£1.18 | |
| 7 | OBSOLETE FRONT SUPPORT RAIL Worcester part no. SMPBOIL29140/3 |
|||
| 8 | OBSOLETE MACHINE SCREW M5 X 25 SLOTTED PAN HEAD Worcester part no. ZGSCR085 |
|||
| 10 | OBSOLETE ROPE SEAL 9 DIA X 690MM LONG - THERMOSEAL TYP Worcester part no. ZEROP004 |
|||
| 12 | NOW USE 29151911040 WING NUT Worcester part no. ZGNUT036 |
|||
| 12 | NUT M4 MS WING ZN PL TABLE 1 Worcester part no. 29151911040 |
|||
| 14 | OBSOLETE HEAT SHIELD - REAR Worcester part no. SD023BOIL2189 |
|||
| 17 | OBSOLETE FULL NUT M5 HEXAGON STEEL GRADE 8 BS3692 Worcester part no. 123400 |
|||
| 19 | OBSOLETE HEAT SHIELD - BOILER FRONT COVER Worcester part no. SD023BOIL2132 |
|||
| 20 | OBSOLETE SCREW M5X35MM HEX/SLOTTED HEAD Worcester part no. ZGSCR087 |
|||
| 20 | OBSOLETE SCREW M5X35MM HEX/SLOTTED HEAD Worcester part no. 29111311680 |
|||
| 22 | OBSOLETE SIGHT GLASS Worcester part no. 87161562040 |
|||
| 23 | OBSOLETE SQUARE SPY-GLASS HOUSING Worcester part no. 87161003990 |
|||
| 24 | OBSOLETE MACHINE SCREW M3 X 5 SLOTTED CHEESE HEAD Worcester part no. ZGSCR065 |
|||
| 25 | OBSOLETE BURNER-FURIGAS SBH 7017/3/30 Worcester part no. 87161426330 |
|||
| 26 | OBSOLETE LINT FILTER - FURIGAS 518 001 001 Worcester part no. ZFGAS002 |
|||
| 27 | OBSOLETE END PLATE - FURIGAS 001 413 002 Worcester part no. ZFGAS003 |
|||
| 28 | OBSOLETE GASKET-END PLT FUR 538.300.002 Worcester part no. 87161407320 |
|||
| 29 | OBSOLETE BURNER SECTION C/W PILOT BRACKET Worcester part no. ZFGAS004 |
|||
| 30 | INJECTOR 1/8 120DEG X 3MM DIA Worcester part no. 87161563440 |
|||
| 30 | OBSOLETE INJECTOR 2MM - 015-004-000 - LPG Worcester part no. 87161423330 |
|||
| 31 | OBSOLETE GAS INLET MANIFOLD Worcester part no. ZBGAS024 |
|||
| 32 |  |
O-RING 3.53 X 25.8 I/D H-NITRILE Worcester part no. 87161408210 |
||
| 33 | HEAT EXCHANGER FINAL ASSY RSLPJU12/14 Worcester part no. 87161211580 |
£915.09 | ||
| 35 | OBSOLETE GAS VALVE Worcester part no. ZAGAS011 |
|||
| 35 | OBSOLETE GAS VALVE 1/2" BSP COMPACT SOFTLITE Worcester part no. 68250902 |
|||
| 37 | OBSOLETE Worcester part no. ZDELE082 |
|||
| 38 | OBSOLETE CABLE 800MM LONG 3 CORE PVC INSULATED - MAINS Worcester part no. ZDELE043 |
|||
| 41 | OBSOLETE MACHINE SCREW M6 X 10 SLOTTED PAN HEAD Worcester part no. ZGSCR088 |
|||
| 42 | OBSOLETE THERMOSTAT Worcester part no. 87161423480 |
|||
| 42 |  |
OBSOLETE T/STAT RANCO L5-P1042 Worcester part no. 87161423430 |
||
| 45 |  |
SPARK IGNITOR Worcester part no. 87161421260 |
||
| 46 | OBSOLETE LEAD ASSY 0.7 PTFE CABLEX500MM Worcester part no. 87161466430 |
|||
| 52 |  |
PILOT BURNER Q359A1041 Worcester part no. 87161426350 |
||
| 53 |  |
INJECTOR(PILOT) Worcester part no. 87161563000 |
£3.20 | |
| 53 |  |
INJECTOR(PILOT)LPG Worcester part no. 87161481530 |
£5.49 | |
| 54 | OBSOLETE Worcester part no. 87161563290 |
|||
| 55 | OBSOLETE Worcester part no. ZFGAS005 |
|||
| 56 | OBSOLETE THERMOCOUPLE 600MM LONG - HONEYWELL Q309A2739 Worcester part no. 35009315 |
|||
| 57 | OBSOLETE Worcester part no. ZGSCR070 |
|||
| 58 | OBSOLETE CAPILLARY COVER Worcester part no. SD023BOIL2220 |
|||
| 59 | OBSOLETE CAPILLARY PAD SPONGE RUBBER STRIP Worcester part no. SD023BOIL2221 |
|||
| 62 | OBSOLETE CLIP - SPRING DRG.NO 32465 Worcester part no. 87161483340 |
|||
| 64 | OBSOLETE FULL NUT M3 HEXAGON STEEL GRADE 8 BS3692 Worcester part no. ZGNUT039 |
|||
| 71 | OBSOLETE MACHINE SCREW M5 X 16 SLOTTED PAN HEAD Worcester part no. 2003400 |
|||
| 78 | OBSOLETE Worcester part no. 87161430440 |
|||
| 82 | OBSOLETE FLOW REGULATOR TYPE E-W 7 LITRE GREEN Worcester part no. 87161411450 |
|||
| 83 | OBSOLETE FLOW REG. TYPE E 5 LITRE YELL Worcester part no. ZBUNC113 |
|||
| 83 | OBSOLETE FLOW REG. TYPE E 5 LITRE YELL Worcester part no. 87161411440 |
|||
| 84 | OBSOLETE INSULATION JACKET H/S JUN TANK Worcester part no. 87161422230 |
|||
| 86 |  |
AIR VENT 1/8 BSP Worcester part no. 87161402380 |
£17.04 | |
| 87 | OBSOLETE DRAIN COCK TYPE A BUSHED 1/2 Worcester part no. ZCUNC013 |
|||
| 87 | OBSOLETE DRAIN COCK TYPE A BUSHED 1/2 Worcester part no. 87161405220 |
|||
| 93 | OBSOLETE BACK PLATE Worcester part no. SH123CABT2404 |
|||
| 94 | OBSOLETE WALL BRACKET Worcester part no. SH123CABT2403 |
|||
| 95 | OBSOLETE FULL NUT M6 HEXAGON STEEL GRADE 8 BS3692 Worcester part no. 123500 |
|||
| 96 | OBSOLETE SMALL BRIGHT WASHER FOR 1/4IN SCREWS Worcester part no. ZGWSH002 |
|||
| 97 | OBSOLETE FULL NUT M8 HEXAGON - STEEL GRADE 8.8 BS3692 Worcester part no. 123600 |
|||
| 98 | OBSOLETE WASHER M8 MILD STEEL Worcester part no. ZGWSH016 |
|||
| 99 | OBSOLETE WALL MOUNTING TEMPLATE - PAPER Worcester part no. 0/2456 |
|||
| 100 | OBSOLETE Worcester part no. ZGSCR159 |
|||
| 101 | OBSOLETE Worcester part no. ZGPLG001 |
|||
| 102 | OBSOLETE SPACER - BACK PLATE Worcester part no. SH123CABT2458 |
|||
| 103 | OBSOLETE PUMP BRACKET Worcester part no. SH123PLUM2433 |
|||
| 110 | OBSOLETE PUMP 130MM - SMC COMET 2 Worcester part no. ZAMAJ033 |
|||
| 111 |  |
VALVE 22MM X 1-1/2 Worcester part no. 87161424170 |
£25.73 | |
| 112 | PUMP GASKET 1-1/4 Worcester part no. 87161409040 |
£5.72 | ||
| 113 | OBSOLETE VALVE DIVERTER 22MM V4044C1288 Worcester part no. 87161424850 |
|||
| 115 |  |
NOW USE 87161402960 RING-COMPRESSION 22MM Worcester part no. ZCCMP019 |
||
| 115 |  |
RING-COMPRESSION 22MM Worcester part no. 87161402960 |
£4.31 | |
| 116 | OBSOLETE BOILER FLOW PIPE Worcester part no. SH123PLUM2676 |
|||
| 117 | OBSOLETE PUMP TO DIVERTER VALVE ASSEMBLY Worcester part no. SH123PLUM2678 |
|||
| 118 | OBSOLETE FLOW PIPE Worcester part no. SH123PLUM2680 |
|||
| 119 | OBSOLETE Worcester part no. ZCCMP004 |
|||
| 119 | OBSOLETE Worcester part no. 87161402670 |
|||
| 120 | OBSOLETE RETURN PIPE Worcester part no. SH123PLUM2682 |
|||
| 121 | OBSOLETE COUPLER - STRAIGHT - 22MM MALE X 3/4IN FEMALE Worcester part no. ZCCMP003 |
|||
| 122 | OBSOLETE FLOW PIPE Worcester part no. SH123PLUM2684 |
|||
| 128 | OBSOLETE ELECTRICAL COVER AND FACIA ASSEMBLY COMPLETE Worcester part no. SH121ELEC24341 |
|||
| 129 | OBSOLETE ELECTRICAL COVER ASSEMBLY Worcester part no. SH123ELEC2435 |
|||
| 130 | OBSOLETE THERMOSTAT AND SWITCH BRACKET Worcester part no. SH123ELEC2442 |
|||
| 131 | OBSOLETE ELECTRICAL COVER TOP PLATE Worcester part no. SH123ELEC2443 |
|||
| 132 | OBSOLETE RELAY BRACKET Worcester part no. SH123ELEC2444 |
|||
| 133 | OBSOLETE INSULATING STRIP Worcester part no. SH123ELEC2445 |
|||
| 134 | OBSOLETE LABEL - TERMINAL STRIP Worcester part no. ZKLAB081 |
|||
| 135 | NOW USE 87161462230 T/BLOCK 12WAY 5AMP (TENBY 715) Worcester part no. ZDELE025 |
|||
| 135 | T/BLOCK 12WAY 5AMP (TENBY 715) Worcester part no. 87161462230 |
£18.44 | ||
| 137 | OBSOLETE GROMMET 19MM DIA BLACK RUBBER Worcester part no. ZDELE013 |
|||
| 138 | OBSOLETE STRAIGHT THROUGH CORD STRAIN RELIEF - HEYCO S Worcester part no. ZDELE045 |
|||
| 139 | OBSOLETE STRAIGHT-THRU STRAIN RELIEF BUSHING BLACK NYL Worcester part no. 68201112 |
|||
| 140 |  |
PLUG HOLE HEYCO DP500 Worcester part no. 87161411030 |
£3.88 | |
| 141 | OBSOLETE FILTER SUPPRESSOR Worcester part no. 87161462490 |
|||
| 142 | OBSOLETE Worcester part no. ZDELE007 |
|||
| 142 | OBSOLETE Worcester part no. 87161411630 |
|||
| 143 | OBSOLETE SOCKET(MINI-RELAY)2515/4SOLDER Worcester part no. 87161461240 |
|||
| 144 | OBSOLETE RELAY-MINI PLUG-IN MY4 230V AC Worcester part no. 87161461250 |
|||
| 145 | OBSOLETE THERMOSTAT Worcester part no. 87161423220 |
|||
| 146 |  |
OBSOLETE T/STAT RANCO CL6-P0128 Worcester part no. 87161423440 |
||
| 146 | OBSOLETE T/STAT RANCO CL6-P0106-001. Worcester part no. 87161423280 |
|||
| 147 | T/STAT RANCO CL6-P0118 (PRIOR) Worcester part no. 87161423290 |
£30.68 | ||
| 148 |  |
NOW USE 87161411010 CLAMP CABLE Worcester part no. ZDELE071 |
||
| 148 |  |
CLAMP CABLE TYPE KB2 INSULOID Worcester part no. 87161411010 |
£17.44 | |
| 150 | OBSOLETE KNOB Worcester part no. 87161411200 |
|||
| 153 |  |
NUT CAPTIVE NO:8 Worcester part no. 87161482040 |
£4.24 | |
| 156 | OBSOLETE Worcester part no. ZGNUT035 |
|||
| 157 | OBSOLETE BRIGHT WASHER M3 FORM A (3.2 X 7 X 0.5) Worcester part no. ZGWSH015 |
|||
| 158 | OBSOLETE MACHINE SCREW M4 X 20 SLOTTED PAN HEAD Worcester part no. ZGSCR071 |
|||
| 159 | OBSOLETE WASHER Worcester part no. ZGWSH021 |
|||
| 161 | OBSOLETE FULL NUT M4 HEXAGON - BRASS BS3692 SELF COLOU Worcester part no. ZGNUT037 |
|||
| 162 | NOW USE 29100011180 M4X8MM Worcester part no. ZGSCR157 |
|||
| 162 | SCREW M4X8MM ROUND HEAD ZP Worcester part no. 29100011180 |
|||
| 163 | OBSOLETE Worcester part no. ZGNUT025 |
|||
| 164 | OBSOLETE SCREW M4 X 15 ROUND HEAD CADMIUM PLATED Worcester part no. ZGSCR155 |
|||
| 165 | OBSOLETE BRIGHT WASHER M4 FORM A (4.3 X 9 X 0.8) Worcester part no. ZGWSH027 |
|||
| 166 | OBSOLETE TAPPING SCREW ISO NO8AB X 9.5 RECESSED PAN HE Worcester part no. ZGSCR008 |
|||
| 167 | OBSOLETE SCREW NO8 X 16 CSK DOMED HEAD CHROME PLATED Worcester part no. ZGSCR041 |
|||
| 168 | OBSOLETE SCREW M4 X 10 TAPTITE RECESSED PAN HEAD Worcester part no. 766290 |
|||
| 169 | OBSOLETE BRIGHT WASHER M4 FORM A - 4.3 X 9 X 0.8 Worcester part no. 163300 |
|||
| 171 | OBSOLETE SWITCH Worcester part no. 87161461300 |
|||
| 176 | OBSOLETE SWITCH Worcester part no. 87161461290 |
|||
| 177 | OBSOLETE BRACKET - PROGRAMMER Worcester part no. SH123ELEC2440 |
|||
| 179 | OBSOLETE SCREW M4 X 12MM PAN HEAD ZINC PLATED Worcester part no. ZGSCR156 |
|||
| 186 | OBSOLETE SIDE PLATE - LH Worcester part no. SH123CABT2421 |
|||
| 187 | OBSOLETE SIDE PLATE - RH Worcester part no. SH123CABT2422 |
|||
| 188 | OBSOLETE TOP PLATE Worcester part no. SH123CABT2423 |
|||
| 189 | OBSOLETE COVER - BASE Worcester part no. SH123CABT2425 |
|||
| 190 | OBSOLETE PANEL - FRONT Worcester part no. SH123CABT2424 |
|||
| 192 |  |
STUD 2BA BRASS BALL NEW DESIGN BEFORE FD991 Worcester part no. 87161405120 |
£3.03 | |
| 193 |  |
NUT 2BA FLAT BLACK M/S BEFORE FD991 Worcester part no. 87161550020 |
£2.57 | |
| 206 | OBSOLETE KIT - FIXING Worcester part no. GC368307 |
|||
| 210 | OBSOLETE Worcester part no. ZHTAP016 |
|||
| 214 | OBSOLETE LABEL Worcester part no. ZKLAB048 |
|||
| 215 | OBSOLETE LABEL Worcester part no. ZKLAB024 |
|||
| 216 | OBSOLETE LABEL - WHEN FILLING SYSTEM - SELF ADHESIVE Worcester part no. ZKLAB020 |
|||
| 218 | OBSOLETE LABEL - ELECTRICAL WARNING - SELF ADHESIVE Worcester part no. ZKLAB061 |
|||
| 219 | OBSOLETE LABEL - SELF ADHESIVE - HEATING DRAIN Worcester part no. ZKLAB077 |
|||
| 220 | OBSOLETE LABEL - PRIMARY FEED - SELF ADHESIVE Worcester part no. ZKLAB030 |
|||
| 221 | OBSOLETE LABEL - PRIMARY VENT - SELF ADHESIVE Worcester part no. ZKLAB078 |
|||
| 222 | OBSOLETE LABEL - CENTRAL HEATING FLOW - SELF ADHESIVE Worcester part no. ZKLAB027 |
|||
| 224 | OBSOLETE LABEL - DOMESTIC HOT WATER OUTLET - SELF ADHE Worcester part no. ZKLAB028 |
|||
| 225 | OBSOLETE INSTALLATION INSTRUCTIONS Worcester part no. ZKLIT058 |
|||
| 226 | OBSOLETE MAINTENANCE INSTRUCTIONS Worcester part no. ZKLIT082 |
|||
