/111/180306105029645987 "Tank Expansion Vessel diagram for Worcester Heatslave HE 18/25 Internal(Aug 2005 Onwards) 7716100098")
You can then pinch & zoom to adjust the size.
| INSULATION JACKET TANK Worcester part no. 87161089330 |
£36.37 | |||
| INSULATION TANK FRONT Worcester part no. 87161089350 |
£13.96 | |||
| 1 | TANK ASSEMBLY PAINTED BEFORE FD991 Worcester part no. 87161097440 |
|||
| 1 | TANK ASSEMBLY PAINTED AFTER FD992 AND BEFORE FD111 Worcester part no. 87186853140 |
£1,186.35 | ||
| 1 | TANK ASSEMBLY PAINTED AFTER FD112 Worcester part no. 87186886200 |
£549.34 | ||
| 2 |  |
DRAIN COCK 1/4 Worcester part no. 87161424310 |
£2.64 | |
| 3 |  |
SCREW (10X) 8X1/2" AFTER FD992 Worcester part no. 87161153060 |
£3.70 | |
| 4 |  |
THERMOSTAT POCKET BEFORE FD988 Worcester part no. 87161402430 |
||
| 4 |  |
POCKET THERMOSTAT AFTER FD989 Worcester part no. 87186852370 |
£19.00 | |
| 5 |  |
NOW USE 8716122564 HEAT EXCHANGER Worcester part no. 87154069750 |
||
| 5 | HEAT EXCHANGER Worcester part no. 8716122564 |
£448.62 | ||
| 6 |  |
WASHER FIBRE SELF ADHESIVE 30X22.5X1.5MM Worcester part no. 87161052180 |
£1.89 | |
| 7 | PIPE CH FLOW/RETURN BEFORE FD991 Worcester part no. 87161087260 |
£6.98 | ||
| 8 | PIPE DIVERTER VALVE TO ISOLATING VALVE BEFORE FD991 Worcester part no. 87161087270 |
£4.33 | ||
| 8 | PIPE DIVERTER VALVE TO ISOLATING VALVE AFTER FD992 Worcester part no. 87186845830 |
£28.59 | ||
| 9 | PIPE HEAT EXCHANGER TO PUMP BEFORE FD991 Worcester part no. 87161082470 |
|||
| 9 | PIPE HEAT EXCHANGER TO PUMP AFTER FD992 Worcester part no. 87186840540 |
£33.18 | ||
| 10 |  |
AIR-VENT AUTOMATIC 3/8 (SS KIT) Worcester part no. 87161405000 |
£11.59 | |
| 11 |  |
NOW USE 8716120459 PUMP Worcester part no. 87161082460 |
||
| 11 | PUMP ASSEMBLY UPMO 7M END.S Worcester part no. 8716120459 |
£231.91 | ||
| 12 | NO 8 OPEN CAPTIVE NUT - BRONZE Worcester part no. 87161405140 |
£17.67 | ||
| 13 |  |
STEEL SPLIT PIN 45MM X 1.5MM Worcester part no. 87161550470 |
£3.04 | |
| 14 | TANK DIP TUBE ASSEMBLY BEFORE FD991 Worcester part no. 87161082510 |
£55.60 | ||
| 15 |  |
DIVERTER VALVE ACTUATOR ASSEMBLY Worcester part no. 87161087230 |
£116.25 | |
| 16 | PIPE PUMP TO DIVERTER VALVE BEFORE FD991 Worcester part no. 87161082480 |
£5.17 | ||
| 16 | PIPE PUMP TO DIVERTER VALVE AFTER FD992 Worcester part no. 87186843340 |
£24.18 | ||
| 17 |  |
WASHER 30.5X22.2X1.5 Worcester part no. 87161409200 |
£3.53 | |
| 18 | PIPE WATER - WATER HT EX TO CHECK VALVE BEFORE FD991 Worcester part no. 87161087290 |
£6.59 | ||
| 18 | PIPE W-WHT EX TO ISO VALVE AFTER FD992 Worcester part no. 87186850660 |
£37.66 | ||
| 19 |  |
DIVERTER VALVE BODY ASSEMBLY BEFORE FD991 Worcester part no. 87161087220 |
£88.49 | |
| 19 |  |
DIVERTER VALVE BODY AFTER FD992 Worcester part no. 87186822900 |
£91.91 | |
| 20 |  |
PLUG 1/8 TAPER Worcester part no. 87161402110 |
£3.64 | |
| 21 |  |
WASHER FIBRE 24 X 12 X 1.5 Worcester part no. 87161023480 |
£2.24 | |
| 22 |  |
FLOW SWITCH ASSEMBLY Worcester part no. 87161114060 |
£73.48 | |
| 23 | FILTER ASSEMBLY Worcester part no. 87186869810 |
£9.42 | ||
| 24 | ISOLATING VALVE - DCW Worcester part no. 87161082410 |
£20.92 | ||
| 25 | PIPE DCW INLET Worcester part no. 87161082430 |
£2.71 | ||
| 26 |  |
ISOLATING VALVE - CH Worcester part no. 87161082560 |
£21.64 | |
| 27 | PIPE PRESSURE RELIEF VALVE DISCHARGE BEFORE FD991 Worcester part no. 87161082770 |
£29.98 | ||
| 27 | PIPE PRV ASSEMBLY AFTER FD992 Worcester part no. 87186855050 |
£53.46 | ||
| 28 | PIPE WATER-WATER HEAT EXCHANGER TO TANK BEFORE FD991 Worcester part no. 87161087250 |
£4.73 | ||
| 28 | PIPE WATER-WATER HEAT EXCHANGER TO TANK AFTER FD992 Worcester part no. 87186851660 |
£20.01 | ||
| 29 |  |
FIBRE WASHER 23.9 X 17.2 X 1.5 Worcester part no. 87101030430 |
£2.92 | |
| 29 |  |
WASHER 23.9 X 17.2 X 1.5 (X1) BEFORE FD991 Worcester part no. 87161156740 |
£2.92 | |
| 29 |  |
O-RING 2.62 X 17.86 AFTER FD992 Worcester part no. 87161408060 |
£2.88 | |
| 30 |  |
EXPANSION VESSEL 12 LITRE Worcester part no. 87161076600 |
£106.05 | |
| 31 | PIPE W-W HEAT EX TO FLOW SWITCH Worcester part no. 87161082420 |
£4.00 | ||
| 32 |  |
WASHER 18.6 X 13.5 X 1.5 (10X) Worcester part no. 87101030450 |
£3.04 | |
| 32 |  |
WASHER 18.6 X 13.5 X 1.5 (1X) Worcester part no. 87161156800 |
£0.88 | |
| 33 |  |
PRESSURE RELIEF ASSEMBLY Worcester part no. 87161104070 |
£29.13 | |
| 34 |  |
WASHER FIBRE 15.0 X 10.0 X 1.0 Worcester part no. 87161409210 |
£3.29 | |
| 35 |  |
FLEXIBLE HOSE Worcester part no. 87161103040 |
£19.47 | |
| 36 | PIPE SECONDARY HT EX TO CHECK VALVE BEFORE FD991 Worcester part no. 87161087280 |
£10.69 | ||
| 37 | CHECK VALVE FITTING ASSY BEFORE FD991 Worcester part no. 87161020320 |
£36.45 | ||
| 37 | CHECK VALVE FITTING ASSEMBLY AFTER FD992 Worcester part no. 87186851640 |
£22.38 | ||
| 38 | PIPE-CH FLOW Worcester part no. 87161113970 |
£13.02 | ||
| 39 | PIPE DOMESTIC OUTLET Worcester part no. 87161082550 |
£2.13 | ||
| 40 | WASHER AFM34 19 X 11 X 1.5 Worcester part no. 87161135120 |
£2.78 | ||
| 41 |  |
WASHER Worcester part no. 87161409120 |
£2.71 | |
| 42 |  |
PRESSURE GAUGE Worcester part no. 87161076380 |
£18.99 | |
| 43 |  |
O-RING 17X4 (10X) AFTER FD992 Worcester part no. 87167711540 |
£2.71 | |
| 44 |  |
CLIP (10X) 18 AFTER FD992 Worcester part no. 87112000240 |
£13.34 | |
| 45 |  |
AUTO AIR VENT 3/8" AFTER FD992 Worcester part no. 87186844010 |
£15.80 | |
| 46 | PROTECTIVE CAP AFTER FD992 Worcester part no. 87186846690 |
£5.07 | ||
| 47 | |
WASHER FIBRE 24 X 12 X 1.5 Worcester part no. 87161023480 |
£2.24 | |
| 48 | THERMOSTAT ASSEMBLY - PRIMARY RETURN AFTER FD110 Worcester part no. 87186892630 |
£33.69 | ||
