WORCESTER
HEATSLAVE 18/25 EXT (FEB 2007 ONWARDS) 7716100118 - (Sterling Burner)
Appliance Code: 7716100118

Appliance Diagram


Sterling Burner diagram for Worcester Heatslave 18/25 Ext (Feb 2007 Onwards) 7716100118Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number 87161565340, MOTOR/PUMP COUPLING MOTOR/PUMP COUPLING
Worcester part no. 87161565340		 £14.81
0   COUPLING FLEX DRIVE
Worcester part no. 87161565650		 £56.08
0 Part number 87161466200, LEAD FOR BFP11L3 OIL PUMP LEAD FOR BFP11L3 OIL PUMP
Worcester part no. 87161466200		 £18.56
0 Part number 87161427780, PUMP ARMATURE FOR DANFOSS BFP PUMP ARMATURE FOR DANFOSS BFP
Worcester part no. 87161427780		 £97.97
0 Part number 87161427690, WASHER COPPER 1/4" WASHER COPPER 1/4"
Worcester part no. 87161427690		 £2.45
0 Part number 87161427610, CABLE TRANSFORMER SUPPLY-(DANFOSS EBI) CABLE TRANSFORMER SUPPLY-(DANFOSS EBI)
Worcester part no. 87161427610		 £19.10
0 Part number 87161427530, ELECTRODE HOLDER ELECTRODE HOLDER
Worcester part no. 87161427530		 £9.43
0 Part number 87161427520, IGNITION ELECTRODE 11593701 IGNITION ELECTRODE 11593701
Worcester part no. 87161427520		 £15.30
0 Part number 87161427370, COIL SOLENOID VALVE BFP21L3 COIL SOLENOID VALVE BFP21L3
Worcester part no. 87161427370		 £87.36
0 Part number 87161427360, PUMP BFP11L3 OIL (LEFT HAND) PUMP BFP11L3 OIL (LEFT HAND)
Worcester part no. 87161427360		 £191.15
0   PRESSURE GAUGE EXTENSION BAR
Worcester part no. 87161566520		 £13.60
0   AIR DAMPER - STERLING 35/40/50
Worcester part no. 87161566540		 £13.87
0   ADJUSTMENT SCREW AIR REGULATION
Worcester part no. 87161566550		 £5.45
0   SCALE AIR REGULATION - STERLING 35/40/50
Worcester part no. 87161566560		 £12.50
0   COVER PLATE AIR REGULATION
Worcester part no. 87161566570		 £5.94
0 Part number 87161566580, NOZZLE HOLDER CHECK VALVE DANFOSS NOZZLE HOLDER CHECK VALVE DANFOSS
Worcester part no. 87161566580		 £30.93
0   O-RING 121X1.6
Worcester part no. 87161566590		 £4.85
0   GASKET- BURNER BODY FRONT PLATE
Worcester part no. 87161566610		 £10.85
0 Part number 87161566620, TRANSFORMER HOLDING SPRING-DANFOSS EBI TRANSFORMER HOLDING SPRING-DANFOSS EBI
Worcester part no. 87161566620		 £7.35
0 Part number 87161566650, 3 UF CAPACITOR FOR AEG MOTOR [+/-5%] 3 UF CAPACITOR FOR AEG MOTOR [+/-5%]
Worcester part no. 87161566650		 £24.56
0 Part number 87161566710, NOZZLE DANFOSS 0.55 80 DEG EH NOZZLE DANFOSS 0.55 80 DEG EH
Worcester part no. 87161566710		 £19.89
0   NOZZLE DANFOSS 0.50 80 DEG EH
Worcester part no. 87161566720		 £22.48
0   NOZZLE ADJUSTMENT COVER PLATE-STERLING
Worcester part no. 87161566840		 £14.23
0   PIPE - TWO CONVERSION SCREW - SUNTEC AS4
Worcester part no. 87161570160		 £10.85
0 Part number 87161570140, PUMP SUNTEC AS47C PUMP SUNTEC AS47C
Worcester part no. 87161570140		 £183.44
0   MOTOR CABLE - AEG(FHP)
Worcester part no. 87161570120		 £12.30
0   FAN HOUSING SHIELD PLATE ST120
Worcester part no. 87161566950		 £44.00
0   FAN HOUSING FRONT PLATE ST120
Worcester part no. 87161566940		 £28.49
0   BURNER MAIN BODY - STERLING 35/40/50
Worcester part no. 87161566930
0 Part number 87161566920, SATRONIC MZ770S PHOTOCELL C/W FLANGE&LEAD SATRONIC MZ770S PHOTOCELL C/W FLANGE&LEAD
Worcester part no. 87161566920		 £47.02
0 Part number 87161566910, SATRONIC MZ770S PHOTOCELL LEAD ONLY SATRONIC MZ770S PHOTOCELL LEAD ONLY
Worcester part no. 87161566910		 £14.11
0   DRIVE COUPLING - STERLING 35/40/50
Worcester part no. 87161566900		 £7.95
0   REAR COVER PLATE - STERLING 35/40/50
Worcester part no. 87161566890		 £15.58
0   NOZZLE HOLDER - STERLING 50
Worcester part no. 87161566880		 £67.21
0   BUSHING - STERLING 35/40/50
Worcester part no. 87161566860		 £11.38
0   NOZZLE ADJUSTMENT SCREW STERLING35/40/50
Worcester part no. 87161566850		 £15.42
0   HARNESS 5 - WAY
Worcester part no. 87161053740		 £19.82
0 Part number 87161085700, BURNER STERLING 50 BURNER STERLING 50
Worcester part no. 87161085700
0 Part number 87161085730, BLAST TUBE PL8/5/19/8-E BLAST TUBE PL8/5/19/8-E
Worcester part no. 87161085730		 £78.29
0   ELECTRODE LEADS(PAIR)-STERLING133/146
Worcester part no. 87161100330		 £22.12
0   NOZZLE DANFOSS 0.65 80 DEG EH
Worcester part no. 87161103620		 £21.16
0   AIR REGULATION PLATE 118 522 01
Worcester part no. 87161103630		 £14.82
0   FAN WHEEL
Worcester part no. 87161103640		 £22.40
0   BRACKET-MOTOR
Worcester part no. 87161103650		 £19.07
0   STERLING 50 OIL-PIPE GREENSTAR
Worcester part no. 87161142060		 £16.00
0 Part number 87161153110, OIL HOSE HNBR 700MM OIL HOSE HNBR 700MM
Worcester part no. 87161153110		 £28.88
0 Part number 8716118364, SATRONIC CONTROL BOX DKO972 SATRONIC CONTROL BOX DKO972
Worcester part no. 8716118364		 £194.72
0 Part number 87161405540, NIPPLE 1/4" CONICAL X 1/4" CONICAL NIPPLE 1/4" CONICAL X 1/4" CONICAL
Worcester part no. 87161405540		 £19.47
0 Part number 87161427300, EBI 052F0004 TRANSFORMER EBI 052F0004 TRANSFORMER
Worcester part no. 87161427300		 £141.94
0   REAR COVER PLATE SCREW
Worcester part no. 87161566500		 £7.25
0 Part number 87161566450, AEG 90W BURNER MOTOR EOGB MO2-1-90-11 AEG 90W BURNER MOTOR EOGB MO2-1-90-11
Worcester part no. 87161566450		 £254.48
0 Part number 87161565210, SHROUD FOR EBI TRANSFORMER SHROUD FOR EBI TRANSFORMER
Worcester part no. 87161565210		 £4.91
