WORCESTER
GREENSTAR 34 CDI CLASSIC LPG - (Tubes)
Appliance Code: 47-406-37

Appliance Diagram


Tubes diagram for Worcester Greenstar 34 CDI Classic LPGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

8 Part number 87167711670, RETAINING SPRING 10MM (10X) RETAINING SPRING 10MM (10X)
Worcester part no. 87167711670		 £2.50
9 Part number 87107353180, PIPE PIPE
Worcester part no. 87107353180		 £24.73
10 Part number 87161067480, O-RING 12,5X3 WRAS / KTW (1X) AFTER FD992 O-RING 12,5X3 WRAS / KTW (1X) AFTER FD992
Worcester part no. 87161067480		 £2.95
10 Part number 87161074370, O-RING 12.5X3 WRAS / KTW (10X) O-RING 12.5X3 WRAS / KTW (10X)
Worcester part no. 87161074370		 £2.79
10 Part number 87161156790, NOW USE 87161067480 O RING NOW USE 87161067480 O RING
Worcester part no. 87161156790
11 Part number 87107353060, FLOW PIPE FLOW PIPE
Worcester part no. 87107353060		 £31.00
12 Part number 87101030460, WASHER 1" (10X) WASHER 1" (10X)
Worcester part no. 87101030460		 £2.95
12 Part number 87161156820, WASHER 1" (1X) WASHER 1" (1X)
Worcester part no. 87161156820		 £2.95
13 Part number 87161122590, WASHER BONDED 19.9MM WASHER BONDED 19.9MM
Worcester part no. 87161122590		 £7.80
13 Part number 87161156730, WASHER (X1) WASHER (X1)
Worcester part no. 87161156730		 £3.88
13 Part number 87167712590, NOW USE 87161122590 WASHER NOW USE 87161122590 WASHER
Worcester part no. 87167712590
14 Part number 87107353240, RETURN PIPE RETURN PIPE
Worcester part no. 87107353240		 £32.48
15 Part number 87167711540, O-RING 17X4 (10X) AFTER FD992 O-RING 17X4 (10X) AFTER FD992
Worcester part no. 87167711540		 £2.63
16 Part number 87112000240, CLIP (10X) 18 AFTER FD992 CLIP (10X) 18 AFTER FD992
Worcester part no. 87112000240		 £12.94
17 Part number 87107353050, CONNECTING PIPE COLD CONNECTING PIPE COLD
Worcester part no. 87107353050		 £24.73
18 Part number 87161165490, O-RING 13,87X3,53 (10X) O-RING 13,87X3,53 (10X)
Worcester part no. 87161165490		 £3.13
18 Part number 87167711550, NOW USE 87161165490 O-RING 13,87X3,53 (10X) NOW USE 87161165490 O-RING 13,87X3,53 (10X)
Worcester part no. 87167711550
19 Part number 87161064280, CH FLOW PIPE ASSEMBLY with clips CH FLOW PIPE ASSEMBLY WITH CLIPS
Worcester part no. 87161064280		 £19.62
20 Part number 87101030430, FIBRE WASHER 23.9 X 17.2 X 1.5 FIBRE WASHER 23.9 X 17.2 X 1.5
Worcester part no. 87101030430		 £2.84
20 Part number 87161156740, WASHER 23.9 X 17.2 X 1.5 (X1) BEFORE FD991 WASHER 23.9 X 17.2 X 1.5 (X1) BEFORE FD991
Worcester part no. 87161156740		 £2.84
21 Part number 87161164280, PRESSURE GAUGE AFTER FD985 PRESSURE GAUGE AFTER FD985
Worcester part no. 87161164280		 £21.38
22 Part number 87161408100, O-RING 2.62 X 6.02 ID EPDM (10X) O-RING 2.62 X 6.02 ID EPDM (10X)
Worcester part no. 87161408100		 £2.68
23 Part number 87161064270, DHW PIPE ASSEMBLY DHW PIPE ASSEMBLY
Worcester part no. 87161064270		 £17.25
24 Part number 87101030450, WASHER 18.6 X 13.5 X 1.5 (10X) WASHER 18.6 X 13.5 X 1.5 (10X)
Worcester part no. 87101030450		 £2.95
24 Part number 87161156800, WASHER 18.6 X 13.5 X 1.5 (1X) WASHER 18.6 X 13.5 X 1.5 (1X)
Worcester part no. 87161156800		 £0.86
26 Part number 87182256360, SIPHON SIPHON
Worcester part no. 87182256360		 £83.86
26 Part number 87186913190, SIPHON SIPHON
Worcester part no. 87186913190		 £31.08
27 Part number 87182256370, CORRUGATED PIPE CORRUGATED PIPE
Worcester part no. 87182256370		 £7.66
28 Part number 87161138280, CONNECTOR-OVERFLOW PIPE CONNECTOR-OVERFLOW PIPE
Worcester part no. 87161138280		 £2.03
29   CLIP
Worcester part no. 87182261360		 £0.50
30 Part number 87102050980, O-RING 26,34 X 5,33 (5X) O-RING 26,34 X 5,33 (5X)
Worcester part no. 87102050980		 £18.43
31 Part number 87377026440, O-RING-SET O-RING-SET
Worcester part no. 87377026440		 £3.57
32 Part number 87105062730, COVER COVER
Worcester part no. 87105062730		 £6.49
