WORCESTER
GREENSTAR 15 I SYSTEM ERP LPG - (Wall Mounting Frame)
Appliance Code: 41-406-26

Appliance Diagram


Wall Mounting Frame diagram for Worcester Greenstar 15 i System ERP LPGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 8716117409, WALL FRAME BARE SPARE WALL FRAME BARE SPARE
Worcester part no. 8716117409
£70.94
2 Part number 87161567550, VALVE - C.H. (UK) VALVE - C.H. (UK)
Worcester part no. 87161567550
£16.37
4 Part number 87161094290, GAS COCK GAS COCK
Worcester part no. 87161094290
£17.38
7 Part number 29144114200, SCREW (10X) M5X12 SCREW (10X) M5X12
Worcester part no. 29144114200
£2.95
8 Part number 87101030430, FIBRE WASHER 23.9 X 17.2 X 1.5 FIBRE WASHER 23.9 X 17.2 X 1.5
Worcester part no. 87101030430
£2.84
8 Part number 87161156740, WASHER 23.9 X 17.2 X 1.5 (X1) BEFORE FD991 WASHER 23.9 X 17.2 X 1.5 (X1) BEFORE FD991
Worcester part no. 87161156740
£2.84
14 Part number 87161067140, SLIDE CONNECTOR SLIDE CONNECTOR
Worcester part no. 87161067140
£22.12
15 Part number 87161165490, O-RING 13,87X3,53 (10X) O-RING 13,87X3,53 (10X)
Worcester part no. 87161165490
£3.13
16 Part number 8716117056, CLIP WALL FRAME CLIP WALL FRAME
Worcester part no. 8716117056
£2.11
17 Part number 87101031610, WASHER 18,3X24,3 (10X) WASHER 18,3X24,3 (10X)
Worcester part no. 87101031610
£8.27
18 Part number 87186810480, Grommet AFTER FD887 GROMMET AFTER FD887
Worcester part no. 87186810480
£1.71
