WORCESTER
CAMRAY QUARTET SYSTEM 60/80 JUNE 1995-JAN 1999 7716139058 - (Heat Exchanger)
Appliance Code: 7716139058

Appliance Diagram


Heat Exchanger diagram for Worcester Camray Quartet System 60/80 June 1995-Jan 1999 7716139058Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2 Part number 87161094960, BAFFLE TOP ASSEMBLY 60/80 BAFFLE TOP ASSEMBLY 60/80
Worcester part no. 87161094960

3 Part number 87161094940, OBSOLETE BAFFLE NO2 AND 4 ASSEMBLY 60/80 OBSOLETE BAFFLE NO2 AND 4 ASSEMBLY 60/80
Worcester part no. 87161094940

4 Part number 87161095020, OBSOLETE BAFFLE NO 3 60/80 OBSOLETE BAFFLE NO 3 60/80
Worcester part no. 87161095020

5 Part number 87161094940, OBSOLETE BAFFLE NO2 AND 4 ASSEMBLY 60/80 OBSOLETE BAFFLE NO2 AND 4 ASSEMBLY 60/80
Worcester part no. 87161094940

6   INSPECTION COVER COMPLETE
Worcester part no. 87161071470
£31.86
7   INSPECTION COVER
Worcester part no. 87161099630
£7.03
8   HEAT SHIELD
Worcester part no. 87161071590
£2.54
9   C/F PLATE
Worcester part no. 87161091050
£28.34
10   RIELLO BURNER COMPACT 50-70
Worcester part no. 87161110090
