WORCESTER
CAMRAY 18/25 ROO GB (FEB 2007 ONWARDS) 7716100106 - (Manifold)
Appliance Code: 7716100106

Appliance Diagram


Manifold diagram for Worcester Camray 18/25 Roo GB (Feb 2007 Onwards) 7716100106Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   MANIFOLD ASSEMBLY
Worcester part no. 87161152500		 £310.73
2   RS AIR DUCT ASSEMBLY
Worcester part no. 87161149860		 £51.53
3 Part number 87161076970, THERMOSTAT POCKET ASSEMBLY THERMOSTAT POCKET ASSEMBLY
Worcester part no. 87161076970		 £41.50
4 Part number 87161550470, STEEL SPLIT PIN 45mm X 1.5mm STEEL SPLIT PIN 45MM X 1.5MM
Worcester part no. 87161550470		 £2.95
5   FLUE SERVICE COVER
Worcester part no. 87161131750		 £137.49
6 Part number 87161075360, SEAL - SERVICE COVER SEAL - SERVICE COVER
Worcester part no. 87161075360		 £12.91
7 Part number 87161131770, CAP ANALYSING POINT CAP ANALYSING POINT
Worcester part no. 87161131770		 £4.70
8 Part number 87161130660, SCREW HEX Z M6 X 25 8.8 ZP AFTER FD783 SCREW HEX Z M6 X 25 8.8 ZP AFTER FD783
Worcester part no. 87161130660		 £3.00
9 Part number 87161129540, SEAL SHE 16 TUBES AFTER FD783 SEAL SHE 16 TUBES AFTER FD783
Worcester part no. 87161129540		 £76.24
10 Part number 87110043020, NOW USE 8716119867 FLUE SEAL NOW USE 8716119867 FLUE SEAL
Worcester part no. 87110043020
10   FLUE SEAL
Worcester part no. 8716119867		 £3.53
11 Part number 87161075350, GASKET RS AIR DUCT S/AD GASKET RS AIR DUCT S/AD
Worcester part no. 87161075350		 £1.12
12 Part number 87161073620, RS AIR DUCT RS AIR DUCT
Worcester part no. 87161073620		 £23.54
13 Part number 29124511520, SCREW M5 X 10 PAN HEAD POZI ZP BEFORE FD005 SCREW M5 X 10 PAN HEAD POZI ZP BEFORE FD005
Worcester part no. 29124511520		 £2.63
14 Part number 87161082800, HOSE CLIP 60mm-80mm HOSE CLIP 60MM-80MM
Worcester part no. 87161082800		 £4.41
15   BURNER AIR DUCT ASSEMBLY
Worcester part no. 87161124240		 £31.41
16   RETAINER-SECONDARY BAFFLE
Worcester part no. 87161100920		 £10.63
17 Part number 87186842710, GASKET FIBBER GASKET FIBBER
Worcester part no. 87186842710		 £5.13
18 Part number 87161134500, COWL SPACER COWL SPACER
Worcester part no. 87161134500		 £10.00
19 Part number 29160110140, WASHER 6mm ID FLAT Z/P M/S WASHER 6MM ID FLAT Z/P M/S
Worcester part no. 29160110140		 £1.99
20 Part number 87161132780, CONDENSATE TRAP KIT CONDENSATE TRAP KIT
Worcester part no. 87161132780		 £127.79
20 Part number 87186828300, TRAP CONDENSATE ASSEMBLY AFTER FD992 TRAP CONDENSATE ASSEMBLY AFTER FD992
Worcester part no. 87186828300		 £17.56
21 Part number 87186828320, PIPE ASSEMBLY CONDENSATE TRAP AFTER FD992 PIPE ASSEMBLY CONDENSATE TRAP AFTER FD992
Worcester part no. 87186828320		 £20.29
22   ELBOW ASSEMBLY CONDENSATE
Worcester part no. 87186829450		 £14.03
23 Part number 87186824840, CONNECTOR FLEXIBLE AFTER FD992 CONNECTOR FLEXIBLE AFTER FD992
Worcester part no. 87186824840		 £6.39
24 Part number 87161067480, O-RING 12,5X3 WRAS / KTW (1X) AFTER FD992 O-RING 12,5X3 WRAS / KTW (1X) AFTER FD992
Worcester part no. 87161067480		 £2.95
