WORCESTER
24I JUNIOR RSF LPG - (Fan)
Appliance Code: 47-311-71

Appliance Diagram


Fan diagram for Worcester 24i Junior RSF LPGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

  BRACKET APS
Worcester part no. 87161054420
£3.28
1 Part number 87161056520, FAN FAN
Worcester part no. 87161056520
£80.65
2 Part number 87161044610, AIR PRESSURE SWITCH HUBA AIR PRESSURE SWITCH HUBA
Worcester part no. 87161044610
£35.44
3 Part number 87161153060, SCREW (10X) 8X1/2" AFTER FD992 SCREW (10X) 8X1/2" AFTER FD992
Worcester part no. 87161153060
£3.59
4 Part number 87161057690, SILICONE TUBE 125mm SILICONE TUBE 125MM
Worcester part no. 87161057690
£2.63
5 Part number 87161057700, SILICONE TUBE RED 340mm SILICONE TUBE RED 340MM
Worcester part no. 87161057700
£3.03
6 Part number 87161550570, SCREW HUBA AIR PRESS SWITCH 2.5X6 POZI 1 SCREW HUBA AIR PRESS SWITCH 2.5X6 POZI 1
Worcester part no. 87161550570
£4.19
7 Part number 87161007010, SAMPLING TUBE SAMPLING TUBE
Worcester part no. 87161007010
£4.52
8 Part number 87161012640, APS TUBE NEGATIVE APS TUBE NEGATIVE
Worcester part no. 87161012640
£2.50
9 Part number 87161412050, T PIECE MOULDING REF 416TEEP T PIECE MOULDING REF 416TEEP
Worcester part no. 87161412050
£3.36
