WORCESTER
12/22 ROO GB CON HE II (FEB 2003 ONWARDS) 7716100092 - (Condenser)
Appliance Code: 7716100092

Appliance Diagram


Condenser diagram for Worcester 12/22 Roo GB CON HE II (Feb 2003 Onwards) 7716100092Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   FLUE SEAL VITON D 80
Worcester part no. 87168300120
£15.62
1   CONDENSER COVER PLATE
Worcester part no. 87168085090
£27.89
2   NOW USE 87168335150 CONDENSER COVER SEAL
Worcester part no. 87161032800

2   SEAL- TOP RING CONDENSER
Worcester part no. 87168335150
£19.24
3   CONDENSER COVER FIXING SCREW
Worcester part no. 87168268260
£10.18
4   CONDENSER ASSEMBLY
Worcester part no. 87161032820

5   SEAL AFM34 D. 18,6 X 12 2 MM DEPTH
Worcester part no. 87168068920
£3.68
6   O-RING D. 50X4 NITRILE
Worcester part no. 87168087760
£5.37
7   CONDENSER CLEANING CAP ASSEMBLY
Worcester part no. 87168282410
£50.58
8   WASHER
Worcester part no. 87168038890

9   PIPE - RETURN
Worcester part no. 87161054070

10   CONDENSER INSULATION
Worcester part no. 87161032940
£100.41
11   PIPE - BOILER SHELL RETURN
Worcester part no. 87168267860
£19.06
12   AIR/FLUE ADAPTER D. 80 X 125
Worcester part no. 87168295450
£149.40
13   WASHER
Worcester part no. 87168387530
£22.27
14   U - TRAP
Worcester part no. 87161054090
£66.66
15   DRAIN VALVE
Worcester part no. 87168115900
£23.73
16   CONDENSER BAFFLE
Worcester part no. 87168120960
£3.01
