VOKERA
VISION 25C ERP REV 1 (04/2015),
VISION 25C ERP REV 10 (01/2019),
VISION 25C ERP REV 13 (09/2019),
VISION 25C ERP REV 18 (11/2020) - (Casing Electrics)
Appliance Code: 47-364-25 REV 10

Appliance Diagram


Casing Electrics diagram for Vokera Vision 25C ERP Rev 10 (01/2019)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

2   FRAME ASSEMBLY
Vokera part no. 20049618
£43.62
12 Part number 20049617, QUICK PRIMER PRESSURE GAUGE QUICK PRIMER PRESSURE GAUGE
Vokera part no. 20049617
£17.20
18   CONTROL PANEL COVER (REAR)
Vokera part no. 20057326
£7.14
20 Part number 20069541, Printed circuit board Replaced 20055454 & 20025735 (UP TO SERIAL NO. 20116906N0752248 OR 2012089N0950180) PRINTED CIRCUIT BOARD REPLACED 20055454 & 20025735 (UP TO SERIAL NO. 20116906N0752248 OR 2012089N0950180)
Vokera part no. 20069541
£152.69
20 Part number 20145176, PCB (FROM SERIAL NO. 20116906N0752249 OR 20120894N0950181) PCB (FROM SERIAL NO. 20116906N0752249 OR 20120894N0950181)
Vokera part no. 20145176
£113.50
26   FRONT PANEL
Vokera part no. 20057331
£18.40
27 Part number 20057330, KNOB KNOB
Vokera part no. 20057330
£4.78
31   CASE
Vokera part no. 20132153
£70.03
75 Part number 20055455, TIMER/DISPLAY MODULE TIMER/DISPLAY MODULE
Vokera part no. 20055455
£143.60
90 Part number 3478, 3 Amp Fuse (individual) 3 AMP FUSE (INDIVIDUAL)
Vokera part no. 3478
£2.05
724   SCREW DRIVER
Vokera part no. 2455
£0.90
