VOKERA
UNICA 28 HE REV 13 (09/2013) LPG - (Hydraulics 1)
Appliance Code: 47-094-83 REV 13 LPG

Appliance Diagram


Hydraulics 1 diagram for Vokera Unica 28 HE Rev 13 (09/2013) LPGClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 8037, Domestic Heat Exchanger DOMESTIC HEAT EXCHANGER
Vokera part no. 8037		 £137.98
2 Part number 10030114, NOW USE 10024640 Connection NOW USE 10024640 CONNECTION
Vokera part no. 10030114
2 Part number 10024640, Connection CONNECTION
Vokera part no. 10024640		 £11.50
3 Part number 10028141, NOW USE 20003181 Water Pressure switch NOW USE 20003181 WATER PRESSURE SWITCH
Vokera part no. 10028141
3 Part number 20003181, Water pressure switch - Replaced 10028141 WATER PRESSURE SWITCH - REPLACED 10028141
Vokera part no. 20003181		 £9.83
4 Part number 10025056, Non return valve NON RETURN VALVE
Vokera part no. 10025056		 £5.11
6 Part number 10024641, By-pass casing BY-PASS CASING
Vokera part no. 10024641		 £14.95
7 Part number 2047, Heating bypass valve HEATING BYPASS VALVE
Vokera part no. 2047		 £6.21
9 Part number 10026508, Htg manifold & cartridge (3 P V kit) 1ST VERSION HTG MANIFOLD & CARTRIDGE (3 P V KIT) 1ST VERSION
Vokera part no. 10026508		 £77.17
9 Part number 20034037, 3 way htg manifold with cartridge (10026508) & motorised valve (20024841) Complete 3 WAY HTG MANIFOLD WITH CARTRIDGE (10026508) & MOTORISED VALVE (20024841) COMPLETE
Vokera part no. 20034037		 £79.05
10 Part number 10025305, 3 way valve cartridge (1ST VERSION) 3 WAY VALVE CARTRIDGE (1ST VERSION)
Vokera part no. 10025305		 £67.91
10 Part number 20034037, 3 way htg manifold with cartridge (10026508) & motorised valve (20024841) Complete 3 WAY HTG MANIFOLD WITH CARTRIDGE (10026508) & MOTORISED VALVE (20024841) COMPLETE
Vokera part no. 20034037		 £79.05
11 Part number 10025304, Actuator/Motorised valve (1ST VERSION) ACTUATOR/MOTORISED VALVE (1ST VERSION)
Vokera part no. 10025304		 £65.02
11 Part number 20017594, Actuator/Motorised valve ACTUATOR/MOTORISED VALVE
Vokera part no. 20017594		 £59.42
11 Part number 20024841, 3-Way Valve Motor (ORANGE LABEL) 3-WAY VALVE MOTOR (ORANGE LABEL)
Vokera part no. 20024841		 £34.32
12 Part number 10025450, Fixing fork wrench FIXING FORK WRENCH
Vokera part no. 10025450		 £15.13
13 Part number 10025449, Curved Locking Pin (1ST VERSION) CURVED LOCKING PIN (1ST VERSION)
Vokera part no. 10025449		 £2.39
13 Part number 20017598, Square Locking Pin (COMPACT VERSION) SQUARE LOCKING PIN (COMPACT VERSION)
Vokera part no. 20017598		 £1.44
22 Part number 20044364, Safety valve Rep 10025055 & 20034917 & 20043820 SAFETY VALVE REP 10025055 & 20034917 & 20043820
Vokera part no. 20044364		 £22.49
24 Part number 10024987, Flow governor 10 Litres Per Minute (Blue) FLOW GOVERNOR 10 LITRES PER MINUTE (BLUE)
Vokera part no. 10024987		 £6.41
24 Part number 10026044, Flow governor 9 Litres Per Minute (Orange) FLOW GOVERNOR 9 LITRES PER MINUTE (ORANGE)
Vokera part no. 10026044		 £5.30
24   FLOW GOVERNOR 11 LITRES PER MINUTE (BEIGE)
Vokera part no. 10026045		 £5.30
25   PIPE
Vokera part no. 10025839		 £17.46
26 Part number 10022349, DHW Actuator replaces 10020330 DHW ACTUATOR REPLACES 10020330
Vokera part no. 10022349		 £33.95
27 Part number 1789, Heating Cock 22mm (Washers are 5237) HEATING COCK 22MM (WASHERS ARE 5237)
Vokera part no. 1789		 £24.62
28 Part number 1790, Connection Rep 088128 CONNECTION REP 088128
Vokera part no. 1790		 £15.87
30 Part number 10023567, C-Water inlet valve/Stop Cock - Screws into non return valve C-WATER INLET VALVE/STOP COCK - SCREWS INTO NON RETURN VALVE
Vokera part no. 10023567		 £32.55
33 Part number 20007057, Heat exchanger jacket (Rep 1807) HEAT EXCHANGER JACKET (REP 1807)
Vokera part no. 20007057		 £3.39
34 Part number 10023566, Heating Flow Cock/Service Valve HEATING FLOW COCK/SERVICE VALVE
Vokera part no. 10023566		 £33.01
35 Part number 10023570, Flexible Pipe/Filling Loop FLEXIBLE PIPE/FILLING LOOP
Vokera part no. 10023570		 £24.49
37 Part number 10025840, Pipe PIPE
Vokera part no. 10025840		 £12.94
47 Part number 10024643, Cover for by-pass assembly COVER FOR BY-PASS ASSEMBLY
Vokera part no. 10024643		 £10.94
48 Part number 10024646, Discharge Valve with O ring (10025064) & Washer (10025066) DISCHARGE VALVE WITH O RING (10025064) & WASHER (10025066)
Vokera part no. 10024646		 £7.85
61 Part number 10023569, Non-Return/Double-Check Valve NON-RETURN/DOUBLE-CHECK VALVE
Vokera part no. 10023569		 £22.61
62 Part number 10023568, Supply Inlet Valve SUPPLY INLET VALVE
Vokera part no. 10023568		 £22.94
63   PIPE
Vokera part no. 10026228		 £20.16
201 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026		 £0.39
265 Part number 5236, Washer WASHER
Vokera part no. 5236		 £0.69
266 Part number 5237, Washer 28mm WASHER 28MM
Vokera part no. 5237		 £0.88
288 Part number 6898, O Ring O RING
Vokera part no. 6898		 £1.03
290 Part number 10027757, Locking Pin LOCKING PIN
Vokera part no. 10027757		 £0.77
290 Part number 2165, NOW USE 10027757 LOCKING PIN NOW USE 10027757 LOCKING PIN
Vokera part no. 2165
351 Part number 1823, Nut (Small) NUT (SMALL)
Vokera part no. 1823		 £1.60
353 Part number 1824, Nut (Large) NUT (LARGE)
Vokera part no. 1824		 £1.60
366 Part number 1820, Clip CLIP
Vokera part no. 1820		 £0.94
432 Part number 10024958, Locking Pin LOCKING PIN
Vokera part no. 10024958		 £0.98
433 Part number 10024986, Locking Pin LOCKING PIN
Vokera part no. 10024986		 £0.98
434 Part number 10024985, Nipple NIPPLE
Vokera part no. 10024985		 £11.88
435 Part number 10025059, Connection CONNECTION
Vokera part no. 10025059		 £11.53
436 Part number 10025062, Locking Pin LOCKING PIN
Vokera part no. 10025062		 £2.26
438 Part number 10024988, O ring O RING
Vokera part no. 10024988		 £0.81
439 Part number 10025067, O ring O RING
Vokera part no. 10025067		 £2.61
441 Part number 10025063, Locking Pin LOCKING PIN
Vokera part no. 10025063		 £0.98
442 Part number 10025065, O ring O RING
Vokera part no. 10025065		 £1.91
443 Part number 10025064, O ring O RING
Vokera part no. 10025064		 £5.30
444 Part number 10025066, Washer WASHER
Vokera part no. 10025066		 £3.27
521 Part number 10027351, Thermistor/NTC Sensor THERMISTOR/NTC SENSOR
Vokera part no. 10027351		 £7.96
600   WIRING CN5 TO PUMP & 3 WAY MOTOR
Vokera part no. 10028633		 £36.76
600   CN5 TO PUMP & 3 WAY VALVE MOTOR
Vokera part no. 20022564		 £28.86
