VOKERA
SYNERGY 29 NG REV 4 (03/2007) - (Hydraulics 1)
Appliance Code: 2350763

Appliance Diagram


Hydraulics 1 diagram for Vokera Synergy 29 NG Rev 4 (03/2007)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

3 Part number 10028141, NOW USE 20003181 Water Pressure switch NOW USE 20003181 WATER PRESSURE SWITCH
Vokera part no. 10028141

3 Part number 20003181, Water pressure switch - Replaced 10028141 WATER PRESSURE SWITCH - REPLACED 10028141
Vokera part no. 20003181
£9.83
7 Part number 1552, Valve For DHW Bypass VALVE FOR DHW BYPASS
Vokera part no. 1552
£7.77
9   HEATING DISTRIBUTION MANIFOLD
Vokera part no. 10021821
£91.25
22 Part number 1806, NOW USE 2907 Safety Valve (Push Fit) NOW USE 2907 SAFETY VALVE (PUSH FIT)
Vokera part no. 1806

22 Part number 2907, Safety valve Replaced 8433 (Push Fit) SAFETY VALVE REPLACED 8433 (PUSH FIT)
Vokera part no. 2907
£14.33
27 Part number 1789, Heating Cock 22mm (Washers are 5237) HEATING COCK 22MM (WASHERS ARE 5237)
Vokera part no. 1789
£24.62
31 Part number 01005137, Venting Plugs Kit VENTING PLUGS KIT
Vokera part no. 01005137
£9.76
63 Part number 10020898, Safety Valve Outlet Tail SAFETY VALVE OUTLET TAIL
Vokera part no. 10020898
£11.05
265 Part number 5236, Washer WASHER
Vokera part no. 5236
£0.69
266 Part number 5237, Washer 28mm WASHER 28MM
Vokera part no. 5237
£0.88
353 Part number 1824, Nut (Large) NUT (LARGE)
Vokera part no. 1824
£1.60
400   HYDRAULIC CONTROL CABLE
Vokera part no. 10024740
£18.57
