VOKERA
PROCOMBI CT 29 REV O (03/2011) - (Hydraulics 1 Heatexchanger)
Appliance Code: 47-364-05

Appliance Diagram


Hydraulics 1 Heatexchanger diagram for Vokera Procombi CT 29 Rev O (03/2011)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 8037, Domestic Heat Exchanger DOMESTIC HEAT EXCHANGER
Vokera part no. 8037		 £137.98
2 Part number 10030114, NOW USE 10024640 Connection NOW USE 10024640 CONNECTION
Vokera part no. 10030114
2 Part number 10024640, Connection CONNECTION
Vokera part no. 10024640		 £11.50
4 Part number 10025056, Non return valve NON RETURN VALVE
Vokera part no. 10025056		 £5.11
7 Part number 2047, Heating bypass valve HEATING BYPASS VALVE
Vokera part no. 2047		 £6.21
8 Part number 10026193, Pipe PIPE
Vokera part no. 10026193		 £16.98
9   VALVE WITH CARTRIDGE
Vokera part no. 20017599		 £85.57
10 Part number 20043594, 3 way valve cartridge Rep 20017597 3 WAY VALVE CARTRIDGE REP 20017597
Vokera part no. 20043594		 £44.96
11 Part number 20017594, Actuator/Motorised valve ACTUATOR/MOTORISED VALVE
Vokera part no. 20017594		 £59.42
13 Part number 20017598, Square Locking Pin (COMPACT VERSION) SQUARE LOCKING PIN (COMPACT VERSION)
Vokera part no. 20017598		 £1.44
22 Part number 10025055, NOW USE 20044364 Safety valve TP NOW USE 20044364 SAFETY VALVE TP
Vokera part no. 10025055
22 Part number 20044364, Safety valve Rep 10025055 & 20034917 & 20043820 SAFETY VALVE REP 10025055 & 20034917 & 20043820
Vokera part no. 20044364		 £22.49
24 Part number 10024987, Flow governor 10 Litres Per Minute (Blue) FLOW GOVERNOR 10 LITRES PER MINUTE (BLUE)
Vokera part no. 10024987		 £6.41
25   PIPE
Vokera part no. 10026423		 £16.98
26 Part number 20013968, DHW ACTUATOR DHW ACTUATOR
Vokera part no. 20013968		 £22.81
27 Part number 1592, 3/4" Heat water cock 3/4" HEAT WATER COCK
Vokera part no. 1592		 £16.13
28 Part number 20025758, Copper Pipe (L Shape) COPPER PIPE (L SHAPE)
Vokera part no. 20025758		 £8.94
29 Part number 20025756, Copper Tail 15mm COPPER TAIL 15MM
Vokera part no. 20025756		 £6.90
30 Part number 20035394, COCK COCK
Vokera part no. 20035394		 £17.73
37   PIPE
Vokera part no. 20017591		 £39.25
47 Part number 10024643, Cover for by-pass assembly COVER FOR BY-PASS ASSEMBLY
Vokera part no. 10024643		 £10.94
48 Part number 10024646, Discharge Valve with O ring (10025064) & Washer (10025066) DISCHARGE VALVE WITH O RING (10025064) & WASHER (10025066)
Vokera part no. 10024646		 £7.85
58 Part number 20025757, Copper Tail 22mm COPPER TAIL 22MM
Vokera part no. 20025757		 £8.07
63   PIPE
Vokera part no. 20036120		 £10.53
65   PIPE
Vokera part no. 10026422		 £16.98
200 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023		 £0.43
201 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026		 £0.39
288 Part number 6898, O Ring O RING
Vokera part no. 6898		 £1.03
290 Part number 10027757, Locking Pin LOCKING PIN
Vokera part no. 10027757		 £0.77
290 Part number 2165, NOW USE 10027757 LOCKING PIN NOW USE 10027757 LOCKING PIN
Vokera part no. 2165
432 Part number 10024958, Locking Pin LOCKING PIN
Vokera part no. 10024958		 £0.98
433 Part number 10024986, Locking Pin LOCKING PIN
Vokera part no. 10024986		 £0.98
434 Part number 10024985, Nipple NIPPLE
Vokera part no. 10024985		 £11.88
435 Part number 10025059, Connection CONNECTION
Vokera part no. 10025059		 £11.53
436 Part number 10025062, Locking Pin LOCKING PIN
Vokera part no. 10025062		 £2.26
438 Part number 10024988, O ring O RING
Vokera part no. 10024988		 £0.81
439 Part number 10025067, O ring O RING
Vokera part no. 10025067		 £2.61
441 Part number 10025063, Locking Pin LOCKING PIN
Vokera part no. 10025063		 £0.98
442 Part number 10025065, O ring O RING
Vokera part no. 10025065		 £1.91
443 Part number 10025064, O ring O RING
Vokera part no. 10025064		 £5.30
444 Part number 10025066, Washer WASHER
Vokera part no. 10025066		 £3.27
521 Part number 10027351, Thermistor/NTC Sensor THERMISTOR/NTC SENSOR
Vokera part no. 10027351		 £7.96
619 Part number 20003181, Water pressure switch - Replaced 10028141 WATER PRESSURE SWITCH - REPLACED 10028141
Vokera part no. 20003181		 £9.83
700 Part number 20017596, CN4 to Motorised Valve CN4 TO MOTORISED VALVE
Vokera part no. 20017596		 £36.90
