VOKERA
OPTION 24 - (Hydraulics Components 2)
Appliance Code: 47-094-32

Appliance Diagram


Hydraulics Components 2 diagram for Vokera Option 24Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 2204, NOW USE 20187349 8 Litre Expansion Vessel NOW USE 20187349 8 LITRE EXPANSION VESSEL
Vokera part no. 2204

1   EXPANSION VESSEL - REPLACED 20138102 AND 2204
Vokera part no. 20187349
£97.14
2 Part number 10023603, Flexible Expansion Pipe FLEXIBLE EXPANSION PIPE
Vokera part no. 10023603
£21.23
3 Part number 10022002, Flexible Pipe FLEXIBLE PIPE
Vokera part no. 10022002
£20.21
4 Part number 10022000, Pipe - Replaces 2218 PIPE - REPLACES 2218
Vokera part no. 10022000
£21.97
5 Part number 2258, High Limit Thermostat HIGH LIMIT THERMOSTAT
Vokera part no. 2258
£8.97
6 Part number 10027352, Thermistor/NTC Sensor (20004978) THERMISTOR/NTC SENSOR (20004978)
Vokera part no. 10027352
£13.58
7 Part number 10020612, Pipe PIPE
Vokera part no. 10020612
£27.80
8 Part number 10022349, DHW Actuator replaces 10020330 DHW ACTUATOR REPLACES 10020330
Vokera part no. 10022349
£33.95
9 Part number 10020714, Pipe PIPE
Vokera part no. 10020714
£17.19
10 Part number 8009, Flow governor (Blue) FLOW GOVERNOR (BLUE)
Vokera part no. 8009
£3.53
11 Part number 2310, Main Heat Exchanger MAIN HEAT EXCHANGER
Vokera part no. 2310
£259.95
12 Part number 5079, Screw SCREW
Vokera part no. 5079
£0.35
13   LOCK NUT
Vokera part no. 4274

14 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026
£0.39
15 Part number 2165, NOW USE 10027757 LOCKING PIN NOW USE 10027757 LOCKING PIN
Vokera part no. 2165

15 Part number 10027757, Locking Pin LOCKING PIN
Vokera part no. 10027757
£0.77
16 Part number 2223, Locking Pin LOCKING PIN
Vokera part no. 2223
£3.76
17 Part number 6898, O Ring O RING
Vokera part no. 6898
£1.03
19 Part number 5041, Washer WASHER
Vokera part no. 5041
£0.19
20 Part number 2226, Rubber Seal RUBBER SEAL
Vokera part no. 2226
£3.63
