VOKERA
MYNUTE 25 A REV 8 (02/2013),
MYNUTE 25 A REV 8 LPG (02/2013) - (Hydraulics 1)
Appliance Code: 41-094-60 REV 8

Appliance Diagram


Hydraulics 1 diagram for Vokera Mynute 25 A Rev 8 (02/2013)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

6 Part number 10024641, By-pass casing BY-PASS CASING
Vokera part no. 10024641
£14.95
7 Part number 1552, Valve For DHW Bypass VALVE FOR DHW BYPASS
Vokera part no. 1552
£7.77
9 Part number 10027768, Heating manifold & Cartridge HEATING MANIFOLD & CARTRIDGE
Vokera part no. 10027768
£64.72
10 Part number 10025305, 3 way valve cartridge (1ST VERSION) 3 WAY VALVE CARTRIDGE (1ST VERSION)
Vokera part no. 10025305
£67.91
12 Part number 10025450, Fixing fork wrench FIXING FORK WRENCH
Vokera part no. 10025450
£15.13
22 Part number 20044364, Safety valve Rep 10025055 & 20034917 & 20043820 SAFETY VALVE REP 10025055 & 20034917 & 20043820
Vokera part no. 20044364
£22.49
27 Part number 1789, Heating Cock 22mm (Washers are 5237) HEATING COCK 22MM (WASHERS ARE 5237)
Vokera part no. 1789
£24.62
47 Part number 10024643, Cover for by-pass assembly COVER FOR BY-PASS ASSEMBLY
Vokera part no. 10024643
£10.94
48 Part number 10024646, Discharge Valve with O ring (10025064) & Washer (10025066) DISCHARGE VALVE WITH O RING (10025064) & WASHER (10025066)
Vokera part no. 10024646
£7.85
63 Part number 20025755, Copper Pipe from Safety Valve COPPER PIPE FROM SAFETY VALVE
Vokera part no. 20025755
£10.93
201 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026
£0.39
266 Part number 5237, Washer 28mm WASHER 28MM
Vokera part no. 5237
£0.88
288 Part number 6898, O Ring O RING
Vokera part no. 6898
£1.03
290 Part number 10027757, Locking Pin LOCKING PIN
Vokera part no. 10027757
£0.77
290 Part number 2165, NOW USE 10027757 LOCKING PIN NOW USE 10027757 LOCKING PIN
Vokera part no. 2165

343 Part number 2216, Manifold Plug MANIFOLD PLUG
Vokera part no. 2216
£3.01
432 Part number 10024958, Locking Pin LOCKING PIN
Vokera part no. 10024958
£0.98
435 Part number 10025059, Connection CONNECTION
Vokera part no. 10025059
£11.53
436 Part number 10025062, Locking Pin LOCKING PIN
Vokera part no. 10025062
£2.26
440   AUTOMATIC BY-PASS PLUG
Vokera part no. 10024645
£4.76
441 Part number 10025063, Locking Pin LOCKING PIN
Vokera part no. 10025063
£0.98
442 Part number 10025065, O ring O RING
Vokera part no. 10025065
£1.91
443 Part number 10025064, O ring O RING
Vokera part no. 10025064
£5.30
444 Part number 10025066, Washer WASHER
Vokera part no. 10025066
£3.27
