VOKERA
LINEA MAX HE FLR STANDING - (Heat Exchanger)
Appliance Code: 47-094-79

Appliance Diagram


Heat Exchanger diagram for Vokera Linea MAX HE FLR StandingClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1   PIPE
Vokera part no. 10024130		 £19.95
1   COMBUSTION CHAMBER
Vokera part no. 10026406
2 Part number 5316, Rear Insulation Panel for Combustion Chamber REAR INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5316		 £18.05
2 Part number 01005246, Main Heat Exchanger rep 2378 & 1914 MAIN HEAT EXCHANGER REP 2378 & 1914
Vokera part no. 01005246		 £259.35
2 Part number 2378, NOW USE 01005246 HEAT EXCHANGER NOW USE 01005246 HEAT EXCHANGER
Vokera part no. 2378
3 Part number 5271, Side Insulation Panel for Combustion Chamber SIDE INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5271		 £9.50
3 Part number 10021041, Flow Pipe FLOW PIPE
Vokera part no. 10021041		 £20.90
4 Part number 5315, Front Insulation Panel for Combustion Chamber FRONT INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5315		 £17.10
4 Part number 01005411, Condensing unit CONDENSING UNIT
Vokera part no. 01005411		 £459.80
5 Part number 10024136, Retarder RETARDER
Vokera part no. 10024136		 £71.25
5   HOOD ASSEMBLY
Vokera part no. 10024125		 £41.80
6 Part number 10024035, Fan FAN
Vokera part no. 10024035		 £182.40
6 Part number 10024129, Short Pipe from Condense Unit SHORT PIPE FROM CONDENSE UNIT
Vokera part no. 10024129		 £27.55
7   PIPE
Vokera part no. 10027896		 £13.30
7 Part number 01005405, NOW USE 20030209 Venturi/pressure tube kit NOW USE 20030209 VENTURI/PRESSURE TUBE KIT
Vokera part no. 01005405
7 Part number 20030209, Venturi kit (Repl 01005405) VENTURI KIT (REPL 01005405)
Vokera part no. 20030209		 £24.70
8 Part number 10024126, Clamp CLAMP
Vokera part no. 10024126		 £19.95
8 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023		 £0.48
9 Part number 5041, Washer WASHER
Vokera part no. 5041		 £0.19
9 Part number 10024137, Fan flue connection FAN FLUE CONNECTION
Vokera part no. 10024137		 £38.95
10 Part number 10026933, Block with combustion analysis check BLOCK WITH COMBUSTION ANALYSIS CHECK
Vokera part no. 10026933		 £9.50
10 Part number 6898, O Ring O RING
Vokera part no. 6898		 £1.05
11   WASHER
Vokera part no. 10023699		 £0.57
11 Part number 8086, Brass Cap BRASS CAP
Vokera part no. 8086		 £2.57
12 Part number 10020889, Air Pressure Switch AIR PRESSURE SWITCH
Vokera part no. 10020889		 £43.70
12 Part number 10024141, O ring O RING
Vokera part no. 10024141		 £16.15
13 Part number 10024142, O ring O RING
Vokera part no. 10024142		 £0.67
14 Part number 10024143, O ring O RING
Vokera part no. 10024143		 £11.40
15 Part number 01005292, Connections kit CONNECTIONS KIT
Vokera part no. 01005292		 £31.35
16 Part number 10024710, Limit thermostat LIMIT THERMOSTAT
Vokera part no. 10024710		 £12.35
17 Part number 10027352, Thermistor/NTC Sensor (20004978) THERMISTOR/NTC SENSOR (20004978)
Vokera part no. 10027352		 £14.25
18 Part number 10027540, Condense Unit Washer CONDENSE UNIT WASHER
Vokera part no. 10027540		 £9.50
