VOKERA
LINEA 28 MARK 2 (AFTER SER # REF 164370001) - (Expansion Vessel And Frame)
Appliance Code: 47-094-28 MK 2

Appliance Diagram


Expansion Vessel And Frame diagram for Vokera Linea 28 Mark 2 (After Ser # Ref 164370001)Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

1 Part number 1830, 8 Litre Expansion Vessel (Inc pipe) 8 LITRE EXPANSION VESSEL (INC PIPE)
Vokera part no. 1830		 £106.11
2 Part number 1850, Expansion Vessel Pipe EXPANSION VESSEL PIPE
Vokera part no. 1850		 £10.19
3 Part number 2916, Distribution Manifold DISTRIBUTION MANIFOLD
Vokera part no. 2916
4 Part number 8460, Pipe PIPE
Vokera part no. 8460		 £15.91
5 Part number 1488, Flow Switch / Actuator FLOW SWITCH / ACTUATOR
Vokera part no. 1488		 £34.80
6   BLANKING PLUG HEATING MANIFOLD
Vokera part no. 4612
7 Part number 1786, C-Water inlet valve/Stop Cock - Stands alone C-WATER INLET VALVE/STOP COCK - STANDS ALONE
Vokera part no. 1786		 £23.93
8 Part number 1794, Flexible Pipe/Filling Loop FLEXIBLE PIPE/FILLING LOOP
Vokera part no. 1794		 £29.28
9 Part number 10020871, Non-Return/Double-Check Valve NON-RETURN/DOUBLE-CHECK VALVE
Vokera part no. 10020871		 £22.40
10 Part number 1790, Connection Rep 088128 CONNECTION REP 088128
Vokera part no. 1790		 £15.87
11 Part number 1788, Heating Flow Cock/Service Valve HEATING FLOW COCK/SERVICE VALVE
Vokera part no. 1788		 £25.75
12 Part number 1789, Heating Cock 22mm (Washers are 5237) HEATING COCK 22MM (WASHERS ARE 5237)
Vokera part no. 1789		 £24.62
13 Part number 10023643, S.Valve outlet tail repl 1792 S.VALVE OUTLET TAIL REPL 1792
Vokera part no. 10023643		 £18.87
14 Part number 1793, Brass Nut Rep 088131` BRASS NUT REP 088131`
Vokera part no. 1793		 £7.27
15 Part number 10020216, Cover Assembly COVER ASSEMBLY
Vokera part no. 10020216
16 Part number 1749, Water Stop Cock WATER STOP COCK
Vokera part no. 1749		 £25.78
18   FIXING JIG SUPPORT
Vokera part no. 10020525
19 Part number 1817, Hanging bracket - Replaced 10024384 HANGING BRACKET - REPLACED 10024384
Vokera part no. 1817		 £8.39
20   SELF TAPPING SCREW
Vokera part no. 5078
21 Part number 5079, Screw SCREW
Vokera part no. 5079		 £0.35
22 Part number 5208, Washer WASHER
Vokera part no. 5208		 £0.21
23 Part number 5203, Plastic Washer PLASTIC WASHER
Vokera part no. 5203		 £0.21
24   SCREW
Vokera part no. 5124		 £0.30
25 Part number 5042, Washer WASHER
Vokera part no. 5042		 £0.25
26   LOCK NUT
Vokera part no. 4274
27 Part number 5236, Washer WASHER
Vokera part no. 5236		 £0.69
28 Part number 1820, Clip CLIP
Vokera part no. 1820		 £0.94
29   OLIVE (LARGE)
Vokera part no. 1822		 £0.65
30 Part number 1824, Nut (Large) NUT (LARGE)
Vokera part no. 1824		 £1.60
32 Part number 1823, Nut (Small) NUT (SMALL)
Vokera part no. 1823		 £1.60
33   OLIVE (SMALL)
Vokera part no. 1821		 £0.54
34 Part number 1890, Clip CLIP
Vokera part no. 1890		 £0.80
