VOKERA
EXCEL 80E UPTO SNS N5/002184 AND N5/052641 - (Assembly15)
Appliance Code: 47-094-13

Appliance Diagram


Assembly15 diagram for Vokera Excel 80E Upto SNS N5/002184 And N5/052641Click the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   WIRING HARNESS EXCELL 80/96E - OLD
Vokera part no. 7602
0 Part number T0001, Service Kit SERVICE KIT
Vokera part no. T0001		 £54.80
1   SCREW
Vokera part no. 5080		 £0.21
2 Part number 5151, Edge Clip EDGE CLIP
Vokera part no. 5151		 £0.19
3 Part number 5917, NOW USE 7317 Seal For Maintenance Clip (small) NOW USE 7317 SEAL FOR MAINTENANCE CLIP (SMALL)
Vokera part no. 5917
3 Part number 7317, Washer WASHER
Vokera part no. 7317		 £1.31
4   OBSOLETE SEAL FOR MAINTENANCE CLIP (LARGE)
Vokera part no. 5920
5 Part number 7315, Clamp CLAMP
Vokera part no. 7315		 £1.61
5 Part number 5916, NOW USE 7315 Maintenance Clip (small) NOW USE 7315 MAINTENANCE CLIP (SMALL)
Vokera part no. 5916
6   OBSOLETE MAINTENANCE CLIP (LARGE)
Vokera part no. 5919
8   COVER
Vokera part no. 5948
9 Part number 5926, Pressure Switch PRESSURE SWITCH
Vokera part no. 5926		 £64.38
10 Part number 5925, OBSOLETE Pressure Differential Switch Housing OBSOLETE PRESSURE DIFFERENTIAL SWITCH HOUSING
Vokera part no. 5925
11 Part number 5128, Edge Clip EDGE CLIP
Vokera part no. 5128		 £0.21
12 Part number 5079, Screw SCREW
Vokera part no. 5079		 £0.35
13   SEAL
Vokera part no. 5927		 £4.47
14   AIR DEFLECTOR
Vokera part no. 5923
15   RIVET
Vokera part no. 5094
16 Part number 5944, NOW USE 1457 Silicone Tube NOW USE 1457 SILICONE TUBE
Vokera part no. 5944
16 Part number 1457, Silicone tube (1 Metre) SILICONE TUBE (1 METRE)
Vokera part no. 1457		 £2.12
17   OBSOLETE AIR CHAMBER
Vokera part no. 7244
18   OBSOLETE GROMMET
Vokera part no. 5928
19   TUBE
Vokera part no. 5915
20 Part number 5921, Venturi VENTURI
Vokera part no. 5921
21   FAN TO FLUE CONNECTOR
Vokera part no. 5914
22   SCREW
Vokera part no. 5176		 £0.30
23 Part number 5911, Fan Assembly FAN ASSEMBLY
Vokera part no. 5911		 £127.40
24 Part number 5912, Fan Gasket FAN GASKET
Vokera part no. 5912		 £12.52
25   HOOD ASSEMBLY
Vokera part no. 5907		 £36.82
26 Part number 5316, Rear Insulation Panel for Combustion Chamber REAR INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5316		 £15.98
27 Part number 5271, Side Insulation Panel for Combustion Chamber SIDE INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5271		 £9.55
28 Part number 6028, Combustion Chamber COMBUSTION CHAMBER
Vokera part no. 6028		 £22.81
29   AIR BAFFLE
Vokera part no. 5951
30 Part number 5315, Front Insulation Panel for Combustion Chamber FRONT INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5315		 £15.04
31 Part number 5909, Combustion Chamber Front (Metal) COMBUSTION CHAMBER FRONT (METAL)
Vokera part no. 5909		 £10.93
32 Part number 4807, Lock Nut LOCK NUT
Vokera part no. 4807		 £0.43
33 Part number 5356, Heat Exchanger HEAT EXCHANGER
Vokera part no. 5356		 £264.20
34 Part number 5279, Gas Valve Support GAS VALVE SUPPORT
Vokera part no. 5279		 £2.33
35   AIR BAFFLE
Vokera part no. 5950
36   RIVET
Vokera part no. 5093
37 Part number 7099, Water Supply Stop Cock WATER SUPPLY STOP COCK
Vokera part no. 7099		 £14.77
38 Part number 5070, Fibre Washer FIBRE WASHER
Vokera part no. 5070		 £0.30
39 Part number 7100, 3/4" Flow/Return Valve 90 Deg 3/4" FLOW/RETURN VALVE 90 DEG
Vokera part no. 7100		 £27.65
40   VALVE COVER
Vokera part no. 7216
41   VALVE COVER RETAINING LUGS
Vokera part no. 7172
42 Part number 7204, Expansion vessel 8L EXPANSION VESSEL 8L
Vokera part no. 7204		 £107.16
43   MAIN FRAME
Vokera part no. 7201
44 Part number 5071, Fibre Washer FIBRE WASHER
Vokera part no. 5071		 £0.25
45   HOT WATER OUTLET NUT AND TAIL
Vokera part no. 4095
46 Part number 7098, Gas Cock GAS COCK
Vokera part no. 7098		 £25.56
47 Part number 5905, Combustion Chamber seal (1 metre) COMBUSTION CHAMBER SEAL (1 METRE)
Vokera part no. 5905		 £2.37
48   SIDE PANEL
Vokera part no. 5903
49   FRONT PANEL
Vokera part no. 5904
50 Part number 5072, Fibre Washer FIBRE WASHER
Vokera part no. 5072		 £0.64
51 Part number 3139, Sight Glass SIGHT GLASS
Vokera part no. 3139		 £5.84
52 Part number 4007, Sight Glass Retaining Ring SIGHT GLASS RETAINING RING
Vokera part no. 4007		 £0.76
53 Part number 5351, Heat Exchanger HEAT EXCHANGER
Vokera part no. 5351		 £225.47
54   SELF TAPPING HEX HEAD 3.9 X L0MM LONG STEEL
Vokera part no. 5180
55   CABLE CLAMP
Vokera part no. 5371
56   SCREW
Vokera part no. 5171
57   MAIN BURNER N.G. POLIDORO - SPECIAL
Vokera part no. 7095
58   MAIN BURNER L.P.G. POLIDORO - SPECIAL
Vokera part no. 7206
59   MAIN BURNER
Vokera part no. 7096
62 Part number 8308, Spark Electrode SPARK ELECTRODE
Vokera part no. 8308		 £17.74
63   SELF TAPPING SCREW
Vokera part no. 5169
64   GAS CONNECTING BARREL
Vokera part no. 7230
65 Part number 5049, Gasket GASKET
Vokera part no. 5049		 £0.55
66   GAS CONNECTING BARREL
Vokera part no. 7094
67   MACHINE SCREW 10MM L X 5MM 0
Vokera part no. 5092
68 Part number 5640, Spark Electrode & Lead SPARK ELECTRODE & LEAD
Vokera part no. 5640		 £15.75
69 Part number 7260, Gas Valve GAS VALVE
Vokera part no. 7260		 £197.35
70   OPERATOR FOR HONEYWELL VR 4605AA 1003 1
Vokera part no. 0680
71 Part number 0394, NG Spring NG SPRING
Vokera part no. 0394		 £2.27
72   SPRING FOR GAS REGULATOR L.P.G.
Vokera part no. 6920
73   MODULATOR
Vokera part no. 6901
73   MODULATOR KIT
Vokera part no. 01005043
74   SOLENOID FOR HONEYWELL VR 4605AA 1003 1
Vokera part no. 0681
75 Part number 4254, Automatic Air Vent AUTOMATIC AIR VENT
Vokera part no. 4254		 £11.99
76 Part number 6025, NOW USE 20192664 15/50 excel complete pump assy NOW USE 20192664 15/50 EXCEL COMPLETE PUMP ASSY
Vokera part no. 6025
76   ERP PUMP - REPLACED 6025
Vokera part no. 20192664		 £227.37
77 Part number 6897, Pump Washer PUMP WASHER
Vokera part no. 6897		 £0.72
78 Part number 6896, Nut NUT
Vokera part no. 6896		 £10.09
79   MACHINE SCREW CHEESEHEAD M4X6MML BRASS
Vokera part no. 5186
80 Part number 6898, O Ring O RING
Vokera part no. 6898		 £1.03
81 Part number 7221, Pump Cable PUMP CABLE
Vokera part no. 7221		 £8.58
82   INLET PIPE
Vokera part no. 6912		 £16.98
83 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023		 £0.43
84 Part number 5929, Pipe PIPE
Vokera part no. 5929
85 Part number 5323, Washer WASHER
Vokera part no. 5323		 £0.39
86 Part number 5322, Screw M5x45 SCREW M5X45
Vokera part no. 5322		 £1.45
87 Part number 5930, Pipe PIPE
Vokera part no. 5930
88 Part number 4518, Domestic Expansion Vessel DOMESTIC EXPANSION VESSEL
Vokera part no. 4518
89 Part number 4026, 3/4" BSP Locknut 3/4" BSP LOCKNUT
Vokera part no. 4026		 £1.38
90   SELF ADHESIVE ALUM SHEET
Vokera part no. 5333
91   AIR CHAMBER
Vokera part no. 7261
92   PIPE
Vokera part no. 7233		 £18.04
93   EXPANSION PIPE
Vokera part no. 7207		 £12.29
94 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026		 £0.39
95   MAINS PIPE CONNECTING NIPPLE
Vokera part no. 6914
96   FIBRE WASHER
Vokera part no. 5195		 £0.39
97   LOCKNUT 1/2
Vokera part no. 6208
98 Part number 7236, NTC Sensor Rep 105922 NTC SENSOR REP 105922
Vokera part no. 7236		 £10.16
99   FLOW PIPE
Vokera part no. 7266
101   OUTLET PIPE
Vokera part no. 6913		 £16.98
102 Part number 7140, Domestic Heat Exchanger DOMESTIC HEAT EXCHANGER
Vokera part no. 7140		 £171.08
103 Part number 7141, Domestic Heat Exchanger DOMESTIC HEAT EXCHANGER
Vokera part no. 7141		 £184.95
104   FIBRE WASHER
Vokera part no. 5192		 £2.63
105   SCREW BRASS CHEESEHEAD M5 X 5MM LONG
Vokera part no. 5188
106 Part number 7132, Domestic Manifold Top DOMESTIC MANIFOLD TOP
Vokera part no. 7132		 £132.19
107   MACHINE SCREW HEX HEAD M6 X 13
Vokera part no. 5183		 £1.08
108   O-RING
Vokera part no. 6894		 £1.06
109   BAR
Vokera part no. 7076
110 Part number 8436, By-Pass Spring BY-PASS SPRING
Vokera part no. 8436		 £1.90
110   NOW USE 8436 SPRING
Vokera part no. 6863
111 Part number 6855, Nut (Rear of Flow Manifold) NUT (REAR OF FLOW MANIFOLD)
Vokera part no. 6855		 £9.17
112 Part number 6851, Htng flow & return manifold (body only) HTNG FLOW & RETURN MANIFOLD (BODY ONLY)
Vokera part no. 6851
113 Part number 5203, Plastic Washer PLASTIC WASHER
Vokera part no. 5203		 £0.21
114   SCREW
Vokera part no. 5124		 £0.30
115 Part number 6862, Spring SPRING
Vokera part no. 6862		 £2.98
116 Part number 6895, O-RING O-RING
Vokera part no. 6895		 £2.48
117 Part number 6866, NOW USE 2910 3 PORT VALVE BOBBIN NOW USE 2910 3 PORT VALVE BOBBIN
Vokera part no. 6866
117 Part number 2910, 3 Port Valve Bobbin 3 PORT VALVE BOBBIN
Vokera part no. 2910		 £3.49
118 Part number 5042, Washer WASHER
Vokera part no. 5042		 £0.25
119   BLANKING PLUG HEATING MANIFOLD
Vokera part no. 4612
120 Part number 6887, Push Rod PUSH ROD
Vokera part no. 6887		 £2.12
121 Part number 6870, Washer WASHER
Vokera part no. 6870		 £1.33
122 Part number 7135, O-RING O-RING
Vokera part no. 7135		 £1.29
123 Part number 7134, Seating Plate SEATING PLATE
Vokera part no. 7134		 £4.81
124   FRONT COVER (3 PORT VALVE)
Vokera part no. 7133
125 Part number 6891, Nut NUT
Vokera part no. 6891		 £19.10
126 Part number 6879, Spring SPRING
Vokera part no. 6879		 £0.96
127 Part number 7131, Domestic By-Pass DOMESTIC BY-PASS
Vokera part no. 7131		 £3.15
128 Part number 7130, By-Pass Retaining Nut BY-PASS RETAINING NUT
Vokera part no. 7130		 £3.38
129 Part number 6882, Diaphragm DIAPHRAGM
Vokera part no. 6882		 £5.94
130 Part number 6883, Bearer Plate BEARER PLATE
Vokera part no. 6883		 £3.66
131   PUSH ROD
Vokera part no. 6890		 £9.02
132   NOW USE 8438 SPRING
Vokera part no. 6884
132   SPRING
Vokera part no. 8438		 £1.70
133 Part number 6876, Front Plate FRONT PLATE
Vokera part no. 6876
134 Part number 5041, Washer WASHER
Vokera part no. 5041		 £0.19
135 Part number 6919, Front Seal FRONT SEAL
Vokera part no. 6919		 £4.94
136 Part number 6853, Flow Manifold Cover FLOW MANIFOLD COVER
Vokera part no. 6853
137 Part number 5184, Machine Screw Hex Head M4 x 12 MACHINE SCREW HEX HEAD M4 X 12
Vokera part no. 5184		 £0.96
138   FRONT PANEL
Vokera part no. 7211
139 Part number 6860, Front Seal FRONT SEAL
Vokera part no. 6860		 £7.85
140 Part number 6872, Diaphragm DIAPHRAGM
Vokera part no. 6872		 £2.54
141   BY-PASS SEATING
Vokera part no. 6858
142 Part number 6873, NOW USE 8435 BOBBIN BY PASS NOW USE 8435 BOBBIN BY PASS
Vokera part no. 6873
142 Part number 8435, By-Pass Bobbin BY-PASS BOBBIN
Vokera part no. 8435
143   FULCRUM ARM
Vokera part no. 6854
144   SCREW
Vokera part no. 6874		 £1.65
145   NOW USE 8441 FULCRUM ARM DISC
Vokera part no. 6871
145   SEATING
Vokera part no. 8441		 £4.72
146   SPRING
Vokera part no. 8437		 £1.92
146   NOW USE 8437 SPRING
Vokera part no. 6864
147 Part number 6859, Nut NUT
Vokera part no. 6859		 £2.92
148 Part number 7139, Non Return Valve NON RETURN VALVE
Vokera part no. 7139		 £7.52
149 Part number 6893, NOW USE 1489 FILTER NOW USE 1489 FILTER
Vokera part no. 6893
149 Part number 1489, Water filter WATER FILTER
Vokera part no. 1489		 £2.73
150   VENTURI
Vokera part no. 6886		 £5.67
151   LOCKING SLEEVE
Vokera part no. 6877
152   BLANKING PLUG
Vokera part no. 6878
153 Part number 6867, Bearer Plate BEARER PLATE
Vokera part no. 6867		 £3.26
154 Part number 6888, Push Rod PUSH ROD
Vokera part no. 6888		 £3.85
155 Part number 6865, Spring SPRING
Vokera part no. 6865		 £2.45
156   TUBE SCREW
Vokera part no. 6856
157 Part number 6857, Safety Valve Sleeve SAFETY VALVE SLEEVE
Vokera part no. 6857		 £6.31
158 Part number 4250, Safety Valve (Screw Fit) SAFETY VALVE (SCREW FIT)
Vokera part no. 4250		 £13.37
159   OBSOLETE FULCRUM ARM NYLON M4 NUT
Vokera part no. 5185
160   TOOTHED LOCK WASHER OD 8MM ID 4MM
Vokera part no. 5133
161   MACHINE SCREW HEX HEAD M4X25MML BRASS
Vokera part no. 5197
162   OBSOLETE CONTROL PANEL SUPPORT BRACKET (LEFT)
Vokera part no. 7208
163   HEXAGON M4 NUT (BRASS)
Vokera part no. 5132
164   GROMMET
Vokera part no. 5298
165   L.E.D PLUG AND LEAD
Vokera part no. 7243		 £13.87
166   SCREW M4 X 8
Vokera part no. 5086
167 Part number 7097, Ignition Control PCB IGNITION CONTROL PCB
Vokera part no. 7097		 £242.91
169   CLOCK BLANKING PLATE
Vokera part no. 6676
170   BRIDGE
Vokera part no. 7232		 £0.50
171 Part number 5170, Screw SCREW
Vokera part no. 5170		 £0.44
172   CASE REINFORCEMENT R/H
Vokera part no. 5255
173 Part number 5168, Rivet RIVET
Vokera part no. 5168		 £0.06
174   PLASTIC BUSH
Vokera part no. 5304		 £1.36
175   FRONT CONTROL PANEL
Vokera part no. 7237
176   CASE REINFORCEMENT L/H
Vokera part no. 5256
177 Part number 5275, Spring For Control Panel SPRING FOR CONTROL PANEL
Vokera part no. 5275
178 Part number 5301, Spindle SPINDLE
Vokera part no. 5301		 £3.27
179   CONTROL PANEL SUPPORT BRACKET (RIGHT)
Vokera part no. 7209
180   OBSOLETE
Vokera part no. 7210
181 Part number 3409, High Limit Stat HIGH LIMIT STAT
Vokera part no. 3409		 £21.43
182   BLANKING PLUG
Vokera part no. 7238
183 Part number 6903, Screw SCREW
Vokera part no. 6903		 £1.50
184 Part number 7239, Pressure/Temp Gauge PRESSURE/TEMP GAUGE
Vokera part no. 7239		 £37.68
185   CLIP
Vokera part no. 3412		 £0.96
186 Part number 7240, Control Knob CONTROL KNOB
Vokera part no. 7240
187   OBSOLETE PLASTIC TRADE MARK LABEL VOKERA (WHITE)
Vokera part no. 5636
188   REAR PLASTIC DOOR
Vokera part no. 6160
190   DOOR PANEL
Vokera part no. 5254
192   PLASTIC BUSH
Vokera part no. 5303
193   OBSOLETE MAINS WATER INLET PIPE (OPTIONAL)
Vokera part no. 7612
194 Part number 5906, Hood Assembly HOOD ASSEMBLY
Vokera part no. 5906		 £35.02
195   FIBRE WASHER - SPECIAL
Vokera part no. 5067
196 Part number 5270, Rear Insulation Panel for Combustion Chamber REAR INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5270		 £15.98
197 Part number 6027, Combustion Chamber COMBUSTION CHAMBER
Vokera part no. 6027		 £22.28
198   AIR BAFFLE
Vokera part no. 5949		 £2.04
199 Part number 5269, Front Insulation Panel for Combustion Chamber FRONT INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5269		 £15.98
200 Part number 5908, Combustion Chamber Front (Metal) COMBUSTION CHAMBER FRONT (METAL)
Vokera part no. 5908		 £9.71
201   SCREW
Vokera part no. 5081		 £0.24
202   FLUE CONNECTION
Vokera part no. 5913		 £8.81
203 Part number 5910, Fan Assembly FAN ASSEMBLY
Vokera part no. 5910		 £106.11
206   OBSOLETE SELF-TAPPING SCREW 10MM L X 4MM 0
Vokera part no. 5165
207   AIR BAFFLE
Vokera part no. 5924
208   SIDE PANEL
Vokera part no. 7212
209 Part number 4174, Boiler Hanging Bracket BOILER HANGING BRACKET
Vokera part no. 4174
210   DHW MICROSWITCH COVER
Vokera part no. 0659
211 Part number 0658, Microswitch MICROSWITCH
Vokera part no. 0658		 £18.51
212   FLOW MICROSWITCH COVER
Vokera part no. 0652
213 Part number 0628, Microswitch MICROSWITCH
Vokera part no. 0628
216   DRIP COVER
Vokera part no. 8306
217   SELF TAPPING SCREW
Vokera part no. 5082
218 Part number 6985, Venturi (Positive) VENTURI (POSITIVE)
Vokera part no. 6985		 £4.88
219   AIR FLANGE
Vokera part no. 5922
220 Part number 0963, NOW USE 01005272 PRESSURE SWITCH NOW USE 01005272 PRESSURE SWITCH
Vokera part no. 0963
220 Part number 01005272, Air Pressure Switch Rep 7070/8195/9232 AIR PRESSURE SWITCH REP 7070/8195/9232
Vokera part no. 01005272		 £58.89


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
