VOKERA
20/80 RS FLOWMATIC - (Assembly12)
Appliance Code: 47-094-07

Appliance Diagram


Assembly12 diagram for Vokera 20/80 RS FlowmaticClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0 Part number T0002, 3 Port Valve Service Kit 3 PORT VALVE SERVICE KIT
Vokera part no. T0002		 £52.84
1 Part number 0226, Diaphragm (6 Screw) DIAPHRAGM (6 SCREW)
Vokera part no. 0226		 £7.16
2 Part number 0139, 3 Way Valve Tail Plate 3 WAY VALVE TAIL PLATE
Vokera part no. 0139		 £25.46
3 Part number 0159, 3 Way Valve Head Shaft 3 WAY VALVE HEAD SHAFT
Vokera part no. 0159		 £34.00
4 Part number 0184, Extension Shaft EXTENSION SHAFT
Vokera part no. 0184		 £34.07
5 Part number 0216, Front Seal FRONT SEAL
Vokera part no. 0216		 £4.84
6   OBSOLETE CLAMP SCREW 3 PORT VALVE TO MANIFOLD
Vokera part no. 0217
7 Part number 0218, Retaining Ring RETAINING RING
Vokera part no. 0218		 £5.75
8 Part number 0219, Shuttle SHUTTLE
Vokera part no. 0219		 £20.16
9   SCREW
Vokera part no. 0220
10   WASHER
Vokera part no. 0221		 £0.96
20 Part number 0309, Front Seal FRONT SEAL
Vokera part no. 0309		 £13.22
21 Part number 0341, Fibre Washer FIBRE WASHER
Vokera part no. 0341		 £2.06
22 Part number 0349, O-RING O-RING
Vokera part no. 0349		 £0.39
23   BY PASS PLUG
Vokera part no. 0364
24   BY PASS SPRING
Vokera part no. 0365
26   DOMESTIC WATER FLOW REGULATING SCREW
Vokera part no. 0367
27   WASHER
Vokera part no. 0371		 £1.47
28   ALUMINIUM WASHER
Vokera part no. 0373
29   VENTURI
Vokera part no. 0381		 £2.97
30 Part number 0394, NG Spring NG SPRING
Vokera part no. 0394		 £2.27
31   GAS VALVE SOLENOID 220/240V
Vokera part no. 0402
32 Part number 0536, Nylon Plate NYLON PLATE
Vokera part no. 0536		 £10.88
33   AUTO BY-PASS RETAINING CAP
Vokera part no. 0549
34   OBSOLETE WASHER
Vokera part no. 0551
35   SPRING FOR AUTO BY-PASS (LARGE)
Vokera part no. 0552
36   OBSOLETE AUTO BY-PASS BOBBIN
Vokera part no. 0553
37   O-RING
Vokera part no. 0554		 £0.44
38 Part number 0555, Spring SPRING
Vokera part no. 0555		 £1.18
39 Part number 0556, By-pass Bearer Plate BY-PASS BEARER PLATE
Vokera part no. 0556		 £4.41
40 Part number 0557, Diaphragm DIAPHRAGM
Vokera part no. 0557		 £6.08
41   OBSOLETE NUT
Vokera part no. 0599
42   SCREWS FOR DOMESTIC MANIFOLD
Vokera part no. 0114
43 Part number 0113, Screw SCREW
Vokera part no. 0113
44   OBSOLETE WHITE CASE
Vokera part no. 0603
45 Part number 3139, Sight Glass SIGHT GLASS
Vokera part no. 3139		 £5.84
46   AUTO BY-PASS CONNECTING TUBE
Vokera part no. 3183
47 Part number 3207, 3 Port Valve 3 PORT VALVE
Vokera part no. 3207		 £135.81
48   DISTRIBUTION MANIFOLD WITH AUTO BY-PASS
Vokera part no. 3208
49 Part number 3212, Heating Thermostat HEATING THERMOSTAT
Vokera part no. 3212
50   O-RING FOR PUMP UNION
Vokera part no. 3740
51 Part number 4007, Sight Glass Retaining Ring SIGHT GLASS RETAINING RING
Vokera part no. 4007		 £0.76
52 Part number 4026, 3/4" BSP Locknut 3/4" BSP LOCKNUT
Vokera part no. 4026		 £1.38
53   NOW USE 6493 RESISTOR
Vokera part no. 4028
53 Part number 6493, Resistor Replaced 4028 RESISTOR REPLACED 4028
Vokera part no. 6493		 £15.89
54   RUBBER RING FOR 4018
Vokera part no. 4036
55   SEAL
Vokera part no. 4039
56   NUT
Vokera part no. 4061
57   15MM OLIVE
Vokera part no. 4062
58   NUT (FOR F/R VALVES 4539)
Vokera part no. 4064
59   22MM OLIVE (FLOW AND RETURN VALVES)
Vokera part no. 4065
60   HOT WATER OUTLET NUT AND TAIL
Vokera part no. 4095
62   PUMP UNION NUT
Vokera part no. 4114
63 Part number 4148, Triple Microswitch TRIPLE MICROSWITCH
Vokera part no. 4148		 £29.97
64 Part number 4174, Boiler Hanging Bracket BOILER HANGING BRACKET
Vokera part no. 4174
65   OBSOLETE PUMP CABLE
Vokera part no. 4220
66 Part number 4250, Safety Valve (Screw Fit) SAFETY VALVE (SCREW FIT)
Vokera part no. 4250		 £13.37
67 Part number 4254, Automatic Air Vent AUTOMATIC AIR VENT
Vokera part no. 4254		 £11.99
68 Part number 4302, Microswitch MICROSWITCH
Vokera part no. 4302		 £17.36
69   CYLINDER VENTING PLUG
Vokera part no. 4321
70   SINGLE MICRO SWITCH COVER
Vokera part no. 4332
71 Part number 4492, Expansion Vessel EXPANSION VESSEL
Vokera part no. 4492		 £92.84
72   HEATING FLOW PIPE WITH UNION
Vokera part no. 4496
73 Part number 4518, Domestic Expansion Vessel DOMESTIC EXPANSION VESSEL
Vokera part no. 4518
74   GAS CONNECTING BARREL
Vokera part no. 4535
75 Part number 4539, FLOW RETURN VALVE FLOW RETURN VALVE
Vokera part no. 4539
77   COCK
Vokera part no. 4541
78   CONNECTION FOR DOM EXP VESSEL
Vokera part no. 4544		 £3.48
79 Part number 4549, Domestic Heat Exchanger DOMESTIC HEAT EXCHANGER
Vokera part no. 4549
80   EXPANSION VESSEL FIXING BRACKET
Vokera part no. 4581
81 Part number 4640, Gas Valve GAS VALVE
Vokera part no. 4640		 £206.90
82   TAIL PLATE SEAL
Vokera part no. 4723
83   ELEC. MAGNETIC COMP. + SPRING + CORE
Vokera part no. 4751
84 Part number 4807, Lock Nut LOCK NUT
Vokera part no. 4807		 £0.43
85 Part number 4891, Pilot Jet NG.27 PILOT JET NG.27
Vokera part no. 4891		 £0.89
87 Part number 4961, Thermocouple THERMOCOUPLE
Vokera part no. 4961		 £9.45
88 Part number 4962, Domestic Distribution Manifold DOMESTIC DISTRIBUTION MANIFOLD
Vokera part no. 4962
89   DOMESTIC HEAT EXCHANGER RETURN PIPE
Vokera part no. 4965
90   EARTH TERMINAL TAG
Vokera part no. 4975
91   SWITCH
Vokera part no. 4981
92 Part number 5023, 3/4" Fibre Washer 3/4" FIBRE WASHER
Vokera part no. 5023		 £0.43
93 Part number 5025, WASHER WASHER
Vokera part no. 5025		 £0.92
94 Part number 5026, 1/2" Fibre Washer 1/2" FIBRE WASHER
Vokera part no. 5026		 £0.39
95   PUMP WASHER
Vokera part no. 5036		 £0.96
96 Part number 5038, Washer WASHER
Vokera part no. 5038		 £0.44
97   WASHER
Vokera part no. 5039		 £0.44
98 Part number 5041, Washer WASHER
Vokera part no. 5041		 £0.19
99 Part number 5049, Gasket GASKET
Vokera part no. 5049		 £0.55
100 Part number 5070, Fibre Washer FIBRE WASHER
Vokera part no. 5070		 £0.30
101 Part number 5071, Fibre Washer FIBRE WASHER
Vokera part no. 5071		 £0.25
102 Part number 5072, Fibre Washer FIBRE WASHER
Vokera part no. 5072		 £0.64
103 Part number 5079, Screw SCREW
Vokera part no. 5079		 £0.35
104   SCREW
Vokera part no. 5080		 £0.21
105   SCREW M4 X 8
Vokera part no. 5086
106   MACHINE SCREW 10MM L X 5MM 0
Vokera part no. 5092
108   SCREW
Vokera part no. 5124		 £0.30
109 Part number 5128, Edge Clip EDGE CLIP
Vokera part no. 5128		 £0.21
110   MACHINE SCREWS FOR MOUNTING THERMOSTAT
Vokera part no. 5129
111   SCREW
Vokera part no. 5131
112   HEXAGON M4 NUT (BRASS)
Vokera part no. 5132
113   TOOTHED LOCK WASHER OD 8MM ID 4MM
Vokera part no. 5133
114   EARTH CONNECTOR
Vokera part no. 5134
115 Part number 5151, Edge Clip EDGE CLIP
Vokera part no. 5151		 £0.19
116   OBSOLETE SELF-TAPPING SCREW 10MM L X 4MM 0
Vokera part no. 5165
117 Part number 5170, Screw SCREW
Vokera part no. 5170		 £0.44
118   SCREW
Vokera part no. 5171
119   SCREW
Vokera part no. 5176		 £0.30
120   FRAME
Vokera part no. 5251
121   DOOR PANEL
Vokera part no. 5254
122   CASE REINFORCEMENT R/H
Vokera part no. 5255
123   CASE REINFORCEMENT L/H
Vokera part no. 5256
125   CONTROL PANEL SUPPORT BRACKET (R/H)
Vokera part no. 5259
126   GUARD
Vokera part no. 5261
127 Part number 5262, Temperature Gauge TEMPERATURE GAUGE
Vokera part no. 5262
128 Part number 5263, Pressure Gauge PRESSURE GAUGE
Vokera part no. 5263		 £21.86
129   THERMOSTAT KNOB
Vokera part no. 5264
130 Part number 5269, Front Insulation Panel for Combustion Chamber FRONT INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5269		 £15.98
131 Part number 5270, Rear Insulation Panel for Combustion Chamber REAR INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5270		 £15.98
132 Part number 5271, Side Insulation Panel for Combustion Chamber SIDE INSULATION PANEL FOR COMBUSTION CHAMBER
Vokera part no. 5271		 £9.55
133 Part number 5275, Spring For Control Panel SPRING FOR CONTROL PANEL
Vokera part no. 5275
134 Part number 5279, Gas Valve Support GAS VALVE SUPPORT
Vokera part no. 5279		 £2.33
135   ON/OFF SWITCH
Vokera part no. 5284
136   OBSOLETE PLASTIC COVER
Vokera part no. 5285
137 Part number 10020104, Burner (replaces 5295) BURNER (REPLACES 5295)
Vokera part no. 10020104		 £97.36
137 Part number 5295, NOW USE 10020104 BURNER NOW USE 10020104 BURNER
Vokera part no. 5295
138   GROMMET
Vokera part no. 5298
139 Part number 5301, Spindle SPINDLE
Vokera part no. 5301		 £3.27
140   PLASTIC BUSH
Vokera part no. 5303
141   PLASTIC BUSH
Vokera part no. 5304		 £1.36
142   PLASTIC PLATE
Vokera part no. 5305
143 Part number 5309, Spark Electrode SPARK ELECTRODE
Vokera part no. 5309		 £7.96
144   COVER FOR PCB
Vokera part no. 5329
145   SELF ADHESIVE ALUM SHEET
Vokera part no. 5333
146   EXPANSION PIPE
Vokera part no. 5335
147 Part number 5351, Heat Exchanger HEAT EXCHANGER
Vokera part no. 5351		 £225.47
148   GAS VALVE KNOB
Vokera part no. 5366
149   CABLE CLAMP
Vokera part no. 5371
150 Part number 5394, Domestic Thermostat DOMESTIC THERMOSTAT
Vokera part no. 5394
151 Part number 4888, H/l Stat (replaces 6399) H/L STAT (REPLACES 6399)
Vokera part no. 4888		 £41.49
152   OBSOLETE FRONT PANEL SUPPORT (RIGHT)
Vokera part no. 5397
153   OBSOLETE PLASTIC TRADE MARK LABEL VOKERA (WHITE)
Vokera part no. 5636
154   OBSOLETE GAS VALVE SUPPORT
Vokera part no. 5796
155 Part number 5797, Circuit Board CIRCUIT BOARD
Vokera part no. 5797		 £135.81
156 Part number 5800, Piezo Ignitor PIEZO IGNITOR
Vokera part no. 5800		 £14.69
157   OBSOLETE AIR CHAMBER
Vokera part no. 5871
158   SIDE PANEL
Vokera part no. 5903
159   FRONT PANEL
Vokera part no. 5904
160 Part number 5905, Combustion Chamber seal (1 metre) COMBUSTION CHAMBER SEAL (1 METRE)
Vokera part no. 5905		 £2.37
161 Part number 5906, Hood Assembly HOOD ASSEMBLY
Vokera part no. 5906		 £35.02
162 Part number 5908, Combustion Chamber Front (Metal) COMBUSTION CHAMBER FRONT (METAL)
Vokera part no. 5908		 £9.71
163 Part number 5910, Fan Assembly FAN ASSEMBLY
Vokera part no. 5910		 £106.11
164 Part number 5912, Fan Gasket FAN GASKET
Vokera part no. 5912		 £12.52
165   FLUE CONNECTION
Vokera part no. 5913		 £8.81
166   TUBE
Vokera part no. 5915
167 Part number 5916, NOW USE 7315 Maintenance Clip (small) NOW USE 7315 MAINTENANCE CLIP (SMALL)
Vokera part no. 5916
167 Part number 7315, Clamp CLAMP
Vokera part no. 7315		 £1.61
168 Part number 5917, NOW USE 7317 Seal For Maintenance Clip (small) NOW USE 7317 SEAL FOR MAINTENANCE CLIP (SMALL)
Vokera part no. 5917
168 Part number 7317, Washer WASHER
Vokera part no. 7317		 £1.31
170   OBSOLETE MAINTENANCE CLIP (LARGE)
Vokera part no. 5919
171   OBSOLETE SEAL FOR MAINTENANCE CLIP (LARGE)
Vokera part no. 5920
172 Part number 5921, Venturi VENTURI
Vokera part no. 5921
173   AIR FLANGE
Vokera part no. 5922
174   AIR DEFLECTOR
Vokera part no. 5923
175   AIR BAFFLE
Vokera part no. 5924
176 Part number 5925, OBSOLETE Pressure Differential Switch Housing OBSOLETE PRESSURE DIFFERENTIAL SWITCH HOUSING
Vokera part no. 5925
177 Part number 5926, Pressure Switch PRESSURE SWITCH
Vokera part no. 5926		 £64.38
178   SEAL
Vokera part no. 5927		 £4.47
179   OBSOLETE GROMMET
Vokera part no. 5928
180   RETURN PIPE AND AIR SEPARATOR
Vokera part no. 5931
181   FLOW PIPE
Vokera part no. 5932
182   ALUMINIUM PIPE
Vokera part no. 5938
183 Part number 5944, NOW USE 1457 Silicone Tube NOW USE 1457 SILICONE TUBE
Vokera part no. 5944
183 Part number 1457, Silicone tube (1 Metre) SILICONE TUBE (1 METRE)
Vokera part no. 1457		 £2.12
184   GAS CONNECTION PIPE
Vokera part no. 5945
185   COVER
Vokera part no. 5948
186   AIR BAFFLE
Vokera part no. 5949		 £2.04
187   PIPE FIXING BRACKET
Vokera part no. 5973
188 Part number 6027, Combustion Chamber COMBUSTION CHAMBER
Vokera part no. 6027		 £22.28
189   NOW USE 20109067 PUMP 25-50
Vokera part no. 6090
189   ERP PUMP - REPLACED 6090 AND 6110
Vokera part no. 20109067		 £141.00
190   LEAD FOR PIEZO
Vokera part no. 6151
191   REAR PLASTIC DOOR
Vokera part no. 6160
195   RIVET
Vokera part no. 5093
196   RIVET
Vokera part no. 5094
197 Part number 5172, Burner Plate BURNER PLATE
Vokera part no. 5172		 £0.29
198   CLIP
Vokera part no. 3412		 £0.96
199 Part number 4888, H/l Stat (replaces 6399) H/L STAT (REPLACES 6399)
Vokera part no. 4888		 £41.49
199   NOW USE 4888 HIGH LIMIT THERMOSTAT
Vokera part no. 4978
200 Part number 5280, Pilot Assembly PILOT ASSEMBLY
Vokera part no. 5280		 £14.76
201   SELF TAPPING SCREW
Vokera part no. 5169
202 Part number 5929, Pipe PIPE
Vokera part no. 5929
203   PCB
Vokera part no. 6759
204 Part number 5441, High-limit Thermostat HIGH-LIMIT THERMOSTAT
Vokera part no. 5441		 £7.30
205 Part number 5472, Thermostat Clip THERMOSTAT CLIP
Vokera part no. 5472		 £1.34


Heating spares made simple this website is secured by Geotrust

 HSP K J Plumbing Factors

Copyright ©2020 >Heating Spare Parts - All Rights Reserved

Site Map | About Us | Parts Lists & Diagrams | Privacy Policy | Terms & Conditions

Facebook Twitter
