VALOR GAS FIRE
UNIGAS DELUXE BF - (Fire Front)
Appliance Code: 32-810-26

Appliance Diagram


Fire Front diagram for Valor Gas Fire Unigas Deluxe BFClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE TAPPING SCREW ISO NO. 8AB X 13 RECESSED PAN HEAD
Valor Gas Fire part no. 080215704

0 Part number 080215717, NOW USE 062583 Taptite Screw M5 x 10 Recessed Pan He NOW USE 062583 TAPTITE SCREW M5 X 10 RECESSED PAN HE
Valor Gas Fire part no. 080215717

0   OBSOLETE MACHINE SCREW M5 X 12 RECESSED PAN HEAD - MILD
Valor Gas Fire part no. 080215612

0   OBSOLETE SHAKEPROOF WASHER 3/16IN WHIT
Valor Gas Fire part no. 8129216

0   OBSOLETE LOCKNUT 1/4IN BSP ST PAINTED
Valor Gas Fire part no. 8129238

0   OBSOLETE NUT 3/16IN WHIT HEX STEEL ZP
Valor Gas Fire part no. 8129230

0   OBSOLETE M3.X 6 SCREW
Valor Gas Fire part no. 0547299

0   OBSOLETE SCREW
Valor Gas Fire part no. 0533329

0   TAPTITE M4X6MM POZI ZP SCREW
Valor Gas Fire part no. 0516349
0   OBSOLETE NO.6X3/8 PAN POZI ZPS
Valor Gas Fire part no. 0514929

0   OBSOLETE WASHER
Valor Gas Fire part no. 0515509

0   OBSOLETE M4 M/S HEX STD PRESSE
Valor Gas Fire part no. 0516959

0   OBSOLETE TAPPING SCREW ISO NO. 6AB X 9.5 RECESSED FLANGE
Valor Gas Fire part no. 80180706

0   OBSOLETE TAPPING SCREW ISO NO. 8AB X 9.5 RECESSED PAN HEAD
Valor Gas Fire part no. 80132297

0   OBSOLETE M4X10 POZI PAN ZP SCR
Valor Gas Fire part no. 0549219

0   OBSOLETE SCREW 3/16BSW X 1.1/4IN. HEXAGON/SLOTTED HEAD -
Valor Gas Fire part no. 8132217

0   OBSOLETE SCREW 3/16IN X 3/8IN SLOTTED MUSH HD
Valor Gas Fire part no. 8132207

0   OBSOLETE WOOD SCREW NO 8 X 1/2IN
Valor Gas Fire part no. 8257300

0   OBSOLETE THUMB SCREW M5 X 12
Valor Gas Fire part no. 8180606

0   OBSOLETE 3/8IN BSP LOCKNUT
Valor Gas Fire part no. 8180805

0   OBSOLETE SCREW 3/16BSW X 3/8IN. HEXAGON HEAD - STAINLESS
Valor Gas Fire part no. 8132290

0   OBSOLETE SCREW 3/16IN WHIT X 3/4IN SLTD RD HD STAINLESS
Valor Gas Fire part no. 8132289

0   OBSOLETE BOLT 3/16BSW X 2IN. HEXAGON HEAD - MILD STEEL
Valor Gas Fire part no. 8132286

0   OBSOLETE SCREW 3/16IN WHIT X 3/8IN POZI PAN STAINLESS
Valor Gas Fire part no. 8132288

0   OBSOLETE WASHER
Valor Gas Fire part no. 8508500

0   OBSOLETE SCREW NO 6 X 1/4IN POZI FLANGE STAINLESS
Valor Gas Fire part no. 8132234

0   OBSOLETE S/P M4 TYPE 12/INT ZP WASHER
Valor Gas Fire part no. 0552239

0   SCR-TF-M5X10MM PN HD PZ S ZNPD
Valor Gas Fire part no. 062583
1   OBSOLETE OUTER CASE ASSEMBLY - COMPLETE - DE LUXE 'S' ONLY
Valor Gas Fire part no. 4408900

1   OBSOLETE FRONT CASE ASSEMBLY - COMPLETE
Valor Gas Fire part no. 4405700

2   OBSOLETE TOP CASE FRAME - DE LUXE 'S' ONLY
Valor Gas Fire part no. 1405910

2   OBSOLETE TOP CASE FRAME
Valor Gas Fire part no. 0522519

3   OBSOLETE WOOD SIDE - RH
Valor Gas Fire part no. 8604900

3   OBSOLETE WOOD SIDE - RH
Valor Gas Fire part no. 8588600

4   OBSOLETE WOOD SIDE - LH - DE LUXE 'S' ONLY
Valor Gas Fire part no. 8605000

4   OBSOLETE WOOD SIDE - LH
Valor Gas Fire part no. 8588500

5   OBSOLETE HOOD AND GRILLE ASSEMBLY - DE LUXE 'S' ONLY
Valor Gas Fire part no. 2408900

5   OBSOLETE HOOD AND GRILLE ASSEMBLY
Valor Gas Fire part no. 0520389

6   OBSOLETE FIRE GUARD
Valor Gas Fire part no. 8589700

19   OBSOLETE BACK PANEL
Valor Gas Fire part no. 2404700

20   OBSOLETE MOUNTING BRACKET - RH
Valor Gas Fire part no. 1405200

21   OBSOLETE MOUNTING BRACKET - LH
Valor Gas Fire part no. 1405100

22   OBSOLETE REMOVABLE TOP
Valor Gas Fire part no. 1406400

23   OBSOLETE CASE LOCATING BRACKET - LH
Valor Gas Fire part no. 7591600

24   OBSOLETE WALL SHIELD
Valor Gas Fire part no. 7591300

25   OBSOLETE HEAT SHIELD
Valor Gas Fire part no. 7593100

26   OBSOLETE HEAT EXCHANGER ASSEMBLY
Valor Gas Fire part no. 0507299

27   OBSOLETE RADIANT BOX ASSEMBLY
Valor Gas Fire part no. 0507329

28   OBSOLETE FRONT AIR GUIDE BAR
Valor Gas Fire part no. 7509900

29   OBSOLETE RADIANT SUPPORT BRACKET
Valor Gas Fire part no. 0519669

30   OBSOLETE BURNER SUPPORT BRACKET
Valor Gas Fire part no. 0518579

31   OBSOLETE SIDE CLOSURE BRACKET
Valor Gas Fire part no. 7508000

32   OBSOLETE SIDE CHEEKS
Valor Gas Fire part no. 8502300

33   OBSOLETE RADIANT ASSY
Valor Gas Fire part no. 0521099

34   OBSOLETE WINDOW ASSY
Valor Gas Fire part no. 0507459

34   OBSOLETE WINDOW REPLACEMENT KIT
Valor Gas Fire part no. 0508189

34   WASHER
Valor Gas Fire part no. 0533589
34   OBSOLETE GASKET - WINDOW TOP
Valor Gas Fire part no. 0508239

34   OBSOLETE STUD
Valor Gas Fire part no. 0508259

34   OBSOLETE WINDOW GASKET - SIDES
Valor Gas Fire part no. 0508249

34   OBSOLETE NUT
Valor Gas Fire part no. 0512849

35   OBSOLETE INLET AIR SPIGOT
Valor Gas Fire part no. 8502800

36   OBSOLETE SPIGOT GASKET
Valor Gas Fire part no. 8502500

37   OBSOLETE AIR DUCT ASSY
Valor Gas Fire part no. 0508119

38   OBSOLETE SEAL RING
Valor Gas Fire part no. 0521109

39   OBSOLETE CLAMPING BAND
Valor Gas Fire part no. 8507800

40   OBSOLETE HOSE CLIP 4X
Valor Gas Fire part no. 8503100

41   OBSOLETE SUPPORT - REMOVABLE TOP
Valor Gas Fire part no. 7590900

42   OBSOLETE CASE FIXING BRACKET
Valor Gas Fire part no. 7587300

43   OBSOLETE TAP AND PIEZO BRACKET
Valor Gas Fire part no. 0521889

44   OBSOLETE BLACK PIEZO
Valor Gas Fire part no. 0507309

45   OBSOLETE PIEZO PLATE
Valor Gas Fire part no. 0507339

46   OBSOLETE MICROSWITCH JUNKERS 8747 2002
Valor Gas Fire part no. 0518929

46   OBSOLETE CONTROL TRIM
Valor Gas Fire part no. 8594900

46   OBSOLETE GAS TAP
Valor Gas Fire part no. 0507349

46   OBSOLETE NO.6AB X 5/8 PZ PN BL
Valor Gas Fire part no. 0557389

47   OBSOLETE CONTROL KNOB
Valor Gas Fire part no. 0510779

47   OBSOLETE CONTROL KNOB - BRAILLE
Valor Gas Fire part no. 8594035

47   OBSOLETE CONTROL KNOB - ARTHRITIC
Valor Gas Fire part no. 0508179

49   OBSOLETE THERMOCOUPLE
Valor Gas Fire part no. 0520309

50   OBSOLETE PIPE TAP TO FILTER
Valor Gas Fire part no. 0522499

51   OBSOLETE FILTER - HARPER WYMAN IG-4320-99 - COMPLETE
Valor Gas Fire part no. 8596100

52   OBSOLETE PIPE FILTER TO BURNER - COMPLETE WITH NUTS
Valor Gas Fire part no. 8505300

53   OBSOLETE PIPE TAP TO BURNER - COMPLETE WITH NUTS
Valor Gas Fire part no. 8589600

54   OBSOLETE PIPE SUPPLY TO TAP
Valor Gas Fire part no. 8588400

55   OBSOLETE PIPE CLAMP
Valor Gas Fire part no. 70587400

56   OBSOLETE ELBOW INLET
Valor Gas Fire part no. 8592000

57   OBSOLETE RESTRICTOR INLET 2.4 DIA
Valor Gas Fire part no. 8116503

58   OBSOLETE ELBOW & PRESSURE TEST POINT
Valor Gas Fire part no. 0507369

59   OBSOLETE PRESSURE TEST NIPPLE - 1/8IN BSP TAPER THREAD
Valor Gas Fire part no. 080031400

60   OBSOLETE BURNER BRAY AB2935 C/W JETS
Valor Gas Fire part no. 0510839

61   OBSOLETE INJECTOR - BRAY 10 SIZE 440
Valor Gas Fire part no. 8126420

62   OBSOLETE PILOT INJECTOR HOUSING - BRAY AB 5080
Valor Gas Fire part no. 8603210

62   OBSOLETE PILOT PORT
Valor Gas Fire part no. 0530499

62   OBSOLETE INJECTOR
Valor Gas Fire part no. 0508749

63   OBSOLETE GASKET
Valor Gas Fire part no. 0522569

64   OBSOLETE ELECTRODE KIGASS E6596
Valor Gas Fire part no. 0518589

65   OBSOLETE LEAD FOR ELECTRODE
Valor Gas Fire part no. 0523359

66   OBSOLETE EARTH FOR ELECTRODE
Valor Gas Fire part no. 8595300

67   OBSOLETE 8 SEALING RING
Valor Gas Fire part no. 0514959

68   OBSOLETE SEALING RING 172 I/D
Valor Gas Fire part no. 8595500

69   OBSOLETE FLUE PIPE ASSEMBLY COMPLETE
Valor Gas Fire part no. 0507359

70   OBSOLETE SEALING RING TERMINAL
Valor Gas Fire part no. 8503600

71   OBSOLETE TERMINAL
Valor Gas Fire part no. 0521119

72   OBSOLETE TERMINAL GUARD
Valor Gas Fire part no. 0516539

73   OBSOLETE INSTALLATION AND SERVICING INSTRUCTIONS
Valor Gas Fire part no. 8181510

73   OBSOLETE INSTALLATION AND SERVICING INSTRUCTIONS
Valor Gas Fire part no. 8181521

74   OBSOLETE USERS INSTRUCTIONS
Valor Gas Fire part no. 8181621

74   OBSOLETE USERS INSTRUCTIONS
Valor Gas Fire part no. 8181610
