VALOR GAS FIRE
TROPIC TREND 2 - BROWN - (Exploded View 2)
Appliance Code: 35-810-10

Appliance Diagram


Exploded View 2 diagram for Valor Gas Fire Tropic Trend 2 - BrownClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE TROPIC TREND 2 USERS
Valor Gas Fire part no. 0526259

0   OBSOLETE TEMPLATE
Valor Gas Fire part no. 0526289

0   OBSOLETE TROPIC TREND 2 INSTALLERS
Valor Gas Fire part no. 0526249

0   OBSOLETE TERMINAL GUARD
Valor Gas Fire part no. 0516539

1   OBSOLETE HEAT EXCHANGER & BURNER UNIT
Valor Gas Fire part no. 0526119

2   OBSOLETE BURNER FIXING BRKT AS
Valor Gas Fire part no. 0526129

3   OBSOLETE M4X8 POZI PAN T/T NP
Valor Gas Fire part no. 0551119

4   OBSOLETE FRONT COVER HEAT EXCHANGER
Valor Gas Fire part no. 0526139

5   OBSOLETE TOP & BTM H/EXCHANGER GASKET
Valor Gas Fire part no. 0513039

6   GASKET-HT.EXCH. SIDES
Valor Gas Fire part no. 0513049
8   OBSOLETE INJECTOR & CARRIER ASSY
Valor Gas Fire part no. 0526149

9   OBSOLETE INJECTOR
Valor Gas Fire part no. 0526159

9   OBSOLETE WASHER
Valor Gas Fire part no. 0534249

10   OBSOLETE CASE LOCATION BRKT
Valor Gas Fire part no. 0526539

10   LOCK NUT
Valor Gas Fire part no. 0502739
10 Part number 0513429, OBSOLETE GAS TAP OBSOLETE GAS TAP
Valor Gas Fire part no. 0513429

11   OBSOLETE INJECTOR CARRIER
Valor Gas Fire part no. 0523019

12   OBSOLETE BURNER
Valor Gas Fire part no. 0526169

13 Part number 0502649, NOW USE 633988 M5X10 POZI PAN HD SCREW BLACK NOW USE 633988 M5X10 POZI PAN HD SCREW BLACK
Valor Gas Fire part no. 0502649

13   SCREW M5X10 PAN.POZ.BLACK
Valor Gas Fire part no. 633988
14   OBSOLETE SPIRE FIX
Valor Gas Fire part no. 0511329

15   OBSOLETE INSPECTION WINDOW FRAME
Valor Gas Fire part no. 0526179

16   OBSOLETE THERMOCOUPLE
Valor Gas Fire part no. 0526189

16   OBSOLETE WASHER
Valor Gas Fire part no. 0526579

17 Part number 0547759, OBSOLETE LOCKNUT OBSOLETE LOCKNUT
Valor Gas Fire part no. 0547759

18   OBSOLETE ELECTRODE
Valor Gas Fire part no. 0526199

19   OBSOLETE M4X6MM PAN MS POZI SC
Valor Gas Fire part no. 0516629

20   OBSOLETE WINDOW GLASS
Valor Gas Fire part no. 0526209

21   OBSOLETE WINDOW GASKET
Valor Gas Fire part no. 0526219

22   OBSOLETE SCREW
Valor Gas Fire part no. 0513059

23   OBSOLETE INLET PIPE
Valor Gas Fire part no. 0513439

24   OBSOLETE INLET PIPE BRACKET
Valor Gas Fire part no. 0513449

25   SCREW
Valor Gas Fire part no. 0534719
26   OBSOLETE FLUE SEAL
Valor Gas Fire part no. 0513299

27   OBSOLETE L/H SIDE BAFFLE
Valor Gas Fire part no. 0513229

28   OBSOLETE COOLER PLATE
Valor Gas Fire part no. 0513259

29 Part number 0534629, SCREW SCREW
Valor Gas Fire part no. 0534629
30   OBSOLETE FRONT BAFFLE
Valor Gas Fire part no. 0526229

32   OBSOLETE ELECTRODE LEAD
Valor Gas Fire part no. 0513199

33   OBSOLETE CASE UNIT ASSY - BROWN
Valor Gas Fire part no. 0526239

33   OBSOLETE CASE UNIT ASSY - GREY
Valor Gas Fire part no. 0526269

34   OBSOLETE PIEZO NUT AND LEAD
Valor Gas Fire part no. 0518269

35   8X3/8 S/DR C/BSCREW
Valor Gas Fire part no. 0513479
36   OBSOLETE CONTROL KNOB
Valor Gas Fire part no. 0518279

36   OBSOLETE KNOB & CLIP ASSEMBLY
Valor Gas Fire part no. 0513279

37   OBSOLETE FLUE PIPE ASSEMBLY PACK
Valor Gas Fire part no. 0513289

38   OBSOLETE 12X2 RD HD SLOT ZP WD/SCREW
Valor Gas Fire part no. 0549759

39   OBSOLETE FOR NO.12X2 SCREW RAWLPLUG
Valor Gas Fire part no. 0549769

40   OBSOLETE ADAPTER
Valor Gas Fire part no. 0534349
