VALOR GAS FIRE
HOMEFLAME HIGHLIGHT BLACK CASE COALFUEL EFFECTS - (Controls)
Appliance Code: 32-811-13

Appliance Diagram


Controls diagram for Valor Gas Fire Homeflame Highlight Black Case Coalfuel EffectsClick the diagram to open it on a new page

You can then pinch & zoom to adjust the size.

0   OBSOLETE USERS INSTRUCTIONS
Valor Gas Fire part no. 0526009
0   OBSOLETE INSTALLATION INSTRUCTIONS
Valor Gas Fire part no. 0525999
1   OBSOLETE FLUE BAFFLE RIVETED
Valor Gas Fire part no. 0525369
2   OBSOLETE DEFLECTOR
Valor Gas Fire part no. 0525379
3   OBSOLETE ASSEMBLY = BACK PANEL
Valor Gas Fire part no. 0525389
7   OBSOLETE REAR LEG
Valor Gas Fire part no. 0525399
9   OBSOLETE COVER STRIP - HEAT EX
Valor Gas Fire part no. 0526109
9   OBSOLETE HEAT EXCHANGER ASSY
Valor Gas Fire part no. 0520449
10   OBSOLETE SPACER
Valor Gas Fire part no. 0547059
11   OBSOLETE SCREW
Valor Gas Fire part no. 0533579
12 Part number 0532279, NUT NUT
Valor Gas Fire part no. 0532279
12 Part number 635506, NUT M5 FULL BRASS NUT M5 FULL BRASS
Valor Gas Fire part no. 635506
14   OBSOLETE HEAT EXCHANGER GASKET
Valor Gas Fire part no. 0547919
15   OBSOLETE COLLECTOR BOX PACK
Valor Gas Fire part no. 0550499
16   OBSOLETE COLLECTOR BOX BAFFLE
Valor Gas Fire part no. 0549959
17   OBSOLETE SPACER
Valor Gas Fire part no. 0547069
18   OBSOLETE SCREW
Valor Gas Fire part no. 0533869
21   OBSOLETE RADIANT BOX
Valor Gas Fire part no. 0525409
22   OBSOLETE GASKET
Valor Gas Fire part no. 0547089
23   OBSOLETE NO8X3/8 SELF TAP SCREW
Valor Gas Fire part no. 0536809
24   OBSOLETE RADIANT BOX BASE R.H. ASSMBLY
Valor Gas Fire part no. 0525419
25   OBSOLETE RADIANT BOX BASE - LH
Valor Gas Fire part no. 0525429
27   OBSOLETE MOUNTING BRACKET ASSEMBLY R.H.
Valor Gas Fire part no. 0525439
28   OBSOLETE MOUNTING BRKT ASSY LH
Valor Gas Fire part no. 0525449
31   OBSOLETE SPACER
Valor Gas Fire part no. 0525459
32   OBSOLETE SCREW
Valor Gas Fire part no. 0509689
35   OBSOLETE CAP FOOT ADJUSTING S
Valor Gas Fire part no. 0526549
35   OBSOLETE LEVELLING SCREW
Valor Gas Fire part no. 0535979
36   OBSOLETE NUT
Valor Gas Fire part no. 0532259
37   OBSOLETE REAR COAL BED SUPPORT
Valor Gas Fire part no. 0525469
39   OBSOLETE REAR LOG SUPPORT
Valor Gas Fire part no. 0525479
41   OBSOLETE FRONT LOG SUPPORT
Valor Gas Fire part no. 0522859
43   OBSOLETE ACCESS PANEL RAD BOX
Valor Gas Fire part no. 0525489
44   OBSOLETE M5X10MM ST/ST POZI SC
Valor Gas Fire part no. 0513799
45   OBSOLETE CONTROL & MANIFOLD UN
Valor Gas Fire part no. 0525499
46   OBSOLETE CROSS LIGHTING BRACKET
Valor Gas Fire part no. 0525509
47   OBSOLETE INJ CARRIER BRACKET
Valor Gas Fire part no. 0525519
49   OBSOLETE MOUNTING BRACKET INJECTOR
Valor Gas Fire part no. 0525529
53   OBSOLETE REGULATOR
Valor Gas Fire part no. 0508199
54   OBSOLETE GOVERNOR BRKT
Valor Gas Fire part no. 0522929
55   OBSOLETE NO.6 X 1/4 POZI ZP S
Valor Gas Fire part no. 0548609
57   OBSOLETE TEST POINT ASS
Valor Gas Fire part no. 0525539
58   OBSOLETE GAS TAP BRACKET
Valor Gas Fire part no. 0525549
60   OBSOLETE GAS TAP
Valor Gas Fire part no. 0525559
61   OBSOLETE PIEZO GENERATOR
Valor Gas Fire part no. 0525569
62   LOCK NUT
Valor Gas Fire part no. 0502739
63   OBSOLETE PIPE ASS. TAP TO PILOT
Valor Gas Fire part no. 0525579
64   OBSOLETE PILOT INJ. & CARRIER ASSEMBLY
Valor Gas Fire part no. 0525589
65   OBSOLETE INJECTOR CARRIER
Valor Gas Fire part no. 0522959
66   OBSOLETE LOCKNUT
Valor Gas Fire part no. 0524149
67   OBSOLETE CROSS LIGHTING BURNER ASSY
Valor Gas Fire part no. 0522979
68   OBSOLETE SCREW
Valor Gas Fire part no. 0513349
69   OBSOLETE ELECTRODE
Valor Gas Fire part no. 0525599
70   OBSOLETE M 3.5 X 6 NICKEL PLATE SCREW
Valor Gas Fire part no. 0543639
71 Part number 0522999, THERMOCOUPLE THERMOCOUPLE
Valor Gas Fire part no. 0522999
72 Part number 0547759, OBSOLETE LOCKNUT OBSOLETE LOCKNUT
Valor Gas Fire part no. 0547759
73   OBSOLETE PIPE ASS. TAP/REAR BU
Valor Gas Fire part no. 0525609
74   OBSOLETE LOWER CAT.77 SIZE 240
Valor Gas Fire part no. 0550349
75   OBSOLETE INJECTOR CARRIER
Valor Gas Fire part no. 0523019
76   OBSOLETE PIPE ASS. TAP/FRONT BU
Valor Gas Fire part no. 0525619
77   OBSOLETE INJECTOR
Valor Gas Fire part no. 0520709
79   OBSOLETE PIPE ASS.PRESTEST PCE
Valor Gas Fire part no. 0525629
83   OBSOLETE AIR GUIDE BAR
Valor Gas Fire part no. 0525639
85   OBSOLETE REAR BURNER & AIR SHUTT
Valor Gas Fire part no. 0525649
87   OBSOLETE FRONT BURNER & AIR SHUTTER
Valor Gas Fire part no. 0525669
89 Part number 0502649, NOW USE 633988 M5X10 POZI PAN HD SCREW BLACK NOW USE 633988 M5X10 POZI PAN HD SCREW BLACK
Valor Gas Fire part no. 0502649
89   SCREW M5X10 PAN.POZ.BLACK
Valor Gas Fire part no. 633988
90   OBSOLETE INLET PIPE ASS
Valor Gas Fire part no. 0525689
91   PIPE FIXING BRACKET
Valor Gas Fire part no. 0535639
93 Part number 0532519, ELBOW ELBOW
Valor Gas Fire part no. 0532519
94   OBSOLETE GLASS FRAME ASSEMBLY
Valor Gas Fire part no. 0525699
95   WINDOW LOCATION SCREW
Valor Gas Fire part no. 0522219
96   OBSOLETE OUTER CASE UNIT (CHAR
Valor Gas Fire part no. 0525709
96   OBSOLETE OUTER CASE UNIT (BROWN
Valor Gas Fire part no. 0525719
97   OBSOLETE CASE BACK - BROWN
Valor Gas Fire part no. 0525739
97   OBSOLETE CASE BACK - BLACK
Valor Gas Fire part no. 0525729
98   OBSOLETE HOOD UNIT (CHARCOAL)
Valor Gas Fire part no. 0525749
98   OBSOLETE HOOD UNIT (BROWN)
Valor Gas Fire part no. 0525759
99   OBSOLETE HEAT SHIELD HOOD TOP
Valor Gas Fire part no. 0525769
100 Part number 0534629, SCREW SCREW
Valor Gas Fire part no. 0534629
102   OBSOLETE RH CASING SIDE - BROWN
Valor Gas Fire part no. 0525789
102   OBSOLETE RH CASING SIDE ASSY - CHARCOAL
Valor Gas Fire part no. 0525779
103   OBSOLETE LH CASING SIDE - CHARCOAL
Valor Gas Fire part no. 0525799
103   OBSOLETE LH CASING SIDE - BROW
Valor Gas Fire part no. 0525809
104   OBSOLETE HEAT SHIELD HOOD FRONT
Valor Gas Fire part no. 0525819
107   OBSOLETE HEARTH ASSEMBLY BROWN
Valor Gas Fire part no. 0525839
107   OBSOLETE HEARTH ASSEMBLY CHARCOAL
Valor Gas Fire part no. 0525829
108   OBSOLETE FENDER SIDE AND IRONS
Valor Gas Fire part no. 0549029
109   SCREW
Valor Gas Fire part no. 0534719
110   OBSOLETE WASHER
Valor Gas Fire part no. 0515509
112   OBSOLETE SECURING LWR FR PANEL SCREW
Valor Gas Fire part no. 0549109
113   OBSOLETE CONTROL BEZEL
Valor Gas Fire part no. 0525859
113   OBSOLETE CONTROL BEZEL
Valor Gas Fire part no. 0525849
114   OBSOLETE KNURLED SCREW
Valor Gas Fire part no. 0525869
115   OBSOLETE CONTROL KNOB AND CLIP
Valor Gas Fire part no. 0525879
115   OBSOLETE CONTROL KNOB AND CLIP
Valor Gas Fire part no. 0525889
116   OBSOLETE WINDOW TRIM ASS
Valor Gas Fire part no. 0525899
117   OBSOLETE FULL PACK COALS
Valor Gas Fire part no. 0525909
118 Part number 0525919, OBSOLETE COAL BED A OBSOLETE COAL BED A
Valor Gas Fire part no. 0525919
119   OBSOLETE PACK COAL OVERLAYS
Valor Gas Fire part no. 0525929
120   OBSOLETE CLOSURE PLATE
Valor Gas Fire part no. 0525939
121 Part number 0535419, OBSOLETE FLUE SPIGOT OBSOLETE FLUE SPIGOT
Valor Gas Fire part no. 0535419
123 Part number 0525949, SMOKE MATCH HOLDER SMOKE MATCH HOLDER
Valor Gas Fire part no. 0525949
124   OBSOLETE LOG PACK
Valor Gas Fire part no. 0525959
125   OBSOLETE LOG FRONT
Valor Gas Fire part no. 0525969
126   OBSOLETE LOG REAR
Valor Gas Fire part no. 0525979
127   LOG CROSS
Valor Gas Fire part no. 0525989
